Kenwood KAC-819 Service Manual page 7

∗
New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohane Parts No. werden nicht geliefert.
A N
Ref. No. Parts No.
d e
d w
R93 RD14DB2H100J
R95 RD14DB2H100J
R96 RD14DB2H471J
R131-133 RD14DB2H100J
R160 RD14DB2H102J
R169 RS14KB3D122J
R193 RS14KB3D122J
R224,225 RD14DB2H4R7J
VR1 R31-0209-05
VR2 R31-0215-05
VR3 R32-0030-05
K1 S76-0804-05
S1 ,2 S31-2630-05
D1 -23 1SS133
D24 RD20JS(B)
D25 FML22S∗A
D26 FML22R∗A
D27 ,28 1SS133
D29 RD7.5JS(B)
D30 RD15JS(B)
D31 1N5406-M
D32 -34 1SS133
D35 ,36 RD16JS(B2)
D37 ,38 1SS133
D40 1SS133
IC1 UPC4574C
IC2 NJM4565D
IC3 UPC494C
IC4 UPC1237HA
Q1 ,2 2SA992(F,E)
Q3 ,4 2SC2631(Q,R)
Q5 2SA1123(Q,R)
Q6 2SC4137(V,W)
Q7 ,8 2SC2235
Q9 ,10 2SA965
Q11 ,12 2SC5101LB*5
Q13 ,14 2SA1909LB*5
Q15 2SC1845(F,E)
Q16 2SA992(F,E)
Q17 2SC1627A
Q18 2SA817A
Q19 2SC1627A
Q20 2SA817A
Q21 ,22 2SC945(A)(Q,P)
Q23 2SA733(A)(Q,P)
Q24 2SC1845(F,E)
Q25 ,26 2SA992(F,E)
Q27 ,28 2SC1845(F,E)
Q29 2SC945(A)(Q,P)
Q30 ,31 2SA733(A)(Q,P)
Q32 2SC945(A)(Q,P)
Q33 -36 IRFIZ48N
Q37 ,38 2SC945(A)(Q,P)
PARTS LIST
Description
SMALL-RD 10 J 1/2W
SMALL-RD 10 J 1/2W
SMALL-RD 470 J 1/2W
SMALL-RD 10 J 1/2W
SMALL-RD 1.0K J 1/2W
FL-PROOF RS 1.2K J 2W
FL-PROOF RS 1.2K J 2W
SMALL-RD 4.7 J 1/2W
VARIABLE RESISTOR
VARIABLE RESISTOR
SEMI FIXED VARIABLE RESISTOR
MAGNETIC RELAY
SLIDE SWITCH
DIODE
ZENER DIODE
DIODE
DIODE
DIODE
ZENER DIODE
ZENER DIODE
DIODE
DIODE
ZENER DIODE
DIODE
DIODE
IC(OP AMP X4)
ANALOGUE IC
IC(SWITCHING REGULATOR)
IC(POWER AMP)
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
FET
TRANSISTOR
A N
Des-
Ref. No. Parts No.
d e
tina-
d w
tion
Q39 2SA817A
Q40 DTA124ESA
Q41 2SA992(F,E)
Q44 2SA817A
Q45 2SC945(A)(Q,P)
Q46 2SA733(A)(Q,P)
TH1 PTH9M04BD222T POSITIVE RESIISTOR
TH2 PTH9L04BD222TS POSITIVE RESIISTOR
KAC-819
Description
TRANSISTOR
DIGITAL TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
indicates safety critical components.
Des-
tina-
tion
9
