PAC HFS Connecting Manual

MODEL # HFS MODEL # HFS
Speaker Level Audio Switcher for the Speaker Level Audio Switcher for the
Motorola IHF1000 Bluetooth Phone Kit Motorola IHF1000 Bluetooth Phone Kit
Connections With The Zo1 Harness
Introduction
Thank you for purchasing the PAC HFS Bluetooth phone kit integration module. The HFS was designed to seam-
lessly integrate the Motorola IHF1000 Bluetooth phone kit into your vehicle's audio system. The HFS is completely
If your Motorola IHF1000 Bluetooth phone kit came equipped with the ZO1 harness, you will not be able to plug the
Plug-n-Play and does not require any cutting or splicing of wires when used with the Motorola Z02 harness. The
HFS directly into the Motorola harness. In this case you will need to make some wire connections.
vehicle specific harnesses plugs directly into the vehicle's audio system. When the IHF1000 is activated by either
an incoming or outgoing call, the HFS will automatically mute the audio system and uses the front speakers to

Wiring Connections

provide the audio for the hands free conversation. The HFS is a speaker level audio switcher that is designed for
1. Cut off the white 8 pin connector from the P-M2UP harness.
non- amplified audio systems and is not recommended for some factory amplified audio systems.
2. Cut off the 2 pin connector for the speaker.
3. Connect the BLACK wire from the speaker plug to the PURPLE wire on the P-M2UP harness.

Installation

4. Connect the YELLOW wire from the speaker plug to the GREY wire on the P-M2UP harness.
5. Connect the RED wire from the ZO1 harness to the RED wire on the P-M2UP harness.
Important Note: The IHF1000 you are installing will have one of two different style main harnesses. Installation will
6. Connect the GREEN wire from the ZO1 harness to the GREEN wire on the P-M2UP harness.
vary depending upon harness style. The harness that comes with the IHF1000 will have a sticker on it with a part
7. Connect the BLACK wire from the ZO1 harness to the BLACK wire on the P-M2UP harness.
number. The last three characters of the part number will be either ZO1 or ZO2. The HFS is designed to be Plug-n-
8. Connect the YELLOW wire from the ZO1 harness to the YELLOW wire on the P-M2UP harness.
Play compatible with the ZO2 harness. If your IHF1000 comes with a ZO1 harness, you will be required to make
wire connections from the HFS to the ZO1 harness. Please follow the appropriate instructions below for your
particular situation.
CAUTION!!!! Make certain that you have the radios security code if the radio has one. The radio may require the
security code to operate after being plugged in.

Connections with the ZO2 harness

Connection at Radio.
Note: All connections to the vehicle for power and audio are made with the vehicle specific harness for HFS. Do not
1. Remove the factory harness from the radio.
connect any wires from the IHF1000 directly to the vehicle. All connections will be made between the IHF1000
2. Plug the factory Harness into the Vehicle side of the PAC harness.
harnesses and the P-M2UP harness. You will need to mount the UIM and the Microphone that comes with the
3. Plug the Radio side of the harness into the factory radio.
IHF1000. These components plug directly into both the ZO1 and ZO2 Motorola harnesses.
4. Connect the 18 pin connector from the vehicle specific harness to the Vehicle Interface side of the HFS.
5. Connect the 16 pin connector on the P-M2UP into the Phone Interface side of the HFS.
CAUTION!!!!
Make certain that you have the radios security code if the radio has one. The radio may require the
security code to operate after being plugged in.
Connection at Radio.
1. Unplug the factory harness from the radio.
2. Plug the factory Harness into the Vehicle side of the PAC harness.
3. Plug the Radio side of the harness into the factory radio.
Back of Radio
4. Connect the 18 pin connector from the vehicle specific harness to the Vehicle Interface side of the HFS.
5. Connect the 16 pin connector on the P-M2UP into the Phone Interface side of the HFS.
6. Connect the 8 pin connector to the Motorola ZO2 harness
Back of Radio
Vehicle Specific CelFi™Harness
Radio Side
Vehicle Side
Vehicle Specific Harness
18 Pin vehicle connector
Radio Side
Vehicle Side
18 Pin vehicle connector
Factory Radio Harness
Make wire connections Here
HFS
Hands Free Switcher
Bluetooth Phone Kit
Integration Module Factory Radio Harness
P-M2UP
www.pac-audio.com
HFS
Hands Free Switcher
Bluetooth Phone Kit
Integration Module
P-M2UP
www.pac-audio.com
Pacific Accessory Corpo- Pacific Accessory Corpo-
IHF 1000
IHF 1000
Pacific Accessory Corporation
1340 Ritchey St.
Santa Ana, CA 92705
techsupport@pac-audio.com
www.pac-audio.com • Ph: 866-931-8021
© 2009 Pacific Accessory Corporation
