OWI AMP-IC6 Specification Sheet

AMPLIFIED SPEAKER:
IN CEILING
OWI Incorporated
®
17141 Kingsview Avenue, Carson, CA 90746 USA
Tel: 310.515.1900
Toll Free: 800.638.1694
Fax: 310.515.1606
Web: www.owi-inc.com
E-mail: info@owi-inc.com

GENERAL SPECIFICATIONS

MODEL NUMBER:

POWER:

FREQUENCY RESPONSE:

THD:
S/N:
INPUT CONFIGURATION:
MINIMUM COMMON
MODE REJECTION:
AT LOAD IMPEDANCE:
MINIMUM POWER
SUPPLY VOLTAGE:
MAXIMUM SUPPLY
VOLTAGE:
MAXIMUM CURRENT
PROTECTED:
SHORT CIRCUIT
PROTECTED:
ONE WIRE TO GROUND
PROTECTED:
MINIMUM LOAD
IMPEDANCE:
INPUT LOAD IMPEDANCE:
MAXIMUM NUMBER OF
AMPLIFIERS ON ONE LINE:

WARRANTY:

ARCHITECTS AND ENGINEERS
SPECIFICATIONS / TECHNICAL DATA
AMP-IC6
25 Watts
50 Hz - 15 kHz. HF is optimized
to enhance frequency response
of the speaker.
<.1%
>90 dB
Differential
40 dB
4 Ohms (2 speakers in parallel)
8 Volts
14 Volts
Yes
Yes
Yes
3.2 Ohm
10K Ohm
4
1 Year
