Summary of Contents for DAPAudio CORE CDMP-750
- Page 1 MANUAL ENGLISH CDMP-750 Ordercode: D1155 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
CDMP-750 Table of contents Warning ....................................2 Unpacking Instructions ..............................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Features ..................................5 Overview ..................................5 Frontside..................................7 Backside .................................. -
Page 3: Warning
CDMP-750 Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have arrived in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged while shipping or the carton itself shows signs of mishandling. -
Page 4: Operating Determinations
CDMP-750 IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the system. Never let the power cord come into contact with other cables! Handle the power cord and all connections with the mains with particular caution! ... -
Page 5: Return Procedure
CDMP-750 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the... -
Page 6: Description Of The Device
CDMP-750 Description of the device Features The CDMP-750 is a professional DJ CD/MP3 Player from DAP Audio. • LCD display with blue backlight • Pitch control +/- 8/16/100% • Electronic anti shock buffer (15 seconds) • Seamless loop function • Beat related auto loop function •... - Page 7 CDMP-750 Fig. 02 USB port Memory C button CD/ USB button Reloop/ Exit Edit encoder Memory D button Folder button Reverse button Prog. button Eject button Relay button FX on/off button Search LED FX select button Scratch LED Title button Jogmode button Time button Jog wheel...
-
Page 8: Frontside
CDMP-750 Frontside Backside Fig. 03 Disc Slot Digital out Line out L/R Remote jack Relay jack Power switch Power cord Installation Remove all packing materials from the CD Player. Check if all the foam and plastic padding is removed. Connect all cables. Always disconnect from electric mains power supply before cleaning or servicing. -
Page 9: Functions
CDMP-750 Functions Names and Functions Below is a description of the control functions. 01) USB port Use this port to connect a USB stick or an external hard disk. The USB port is only active when you’re in USB mode. Note: The CDMP-750 can handle a maximum of 2 Tbyte, 999 folders and 999 files. - Page 10 CDMP-750 15) LCD Display Fig. 04 TOTAL TRACK: Shows the current track number or the folder number while selecting folders. : Indicates that the unit is in playback mode : Indicates that the unit is in pause mode CUE: indicates that a cue point has been memorized. CD: Indicates that the unit is in CD mode.
- Page 11 CDMP-750 playback, so stop playback before pressing the button. Ordercode: D1155...
- Page 12 CDMP-750 25) FX On/Off button This button allows you to toggle the effect processor on or off. Press the Relay (06) button to switch between gain and parameter. Once gain is selected, the button will light up and show the gain value on the LCD display (15) will show the gain value blinking.
- Page 13 CDMP-750 37) Master tempo button Allows you to toggle the master tempo mode on or off. When master tempo mode is active, the button will light up in red. While master tempo mode is active, the pitch fader allows you to shift the pitch of the song played back while the tempo of the song stays the stays unchanged.
-
Page 14: Operations
CDMP-750 Operations Loading a CD Hold the disc by the edges and Press it gently in the Disc Slot (39). The Disc will now be loaded automatically. Unloading a CD 01) The disc can't be ejected during playback. Stop the playback first. 02) Press the Eject (24) button. -
Page 15: Stop Playback
CDMP-750 Stop playback There are two ways to stop playback: 01) Press the Play/Pause (13) button during playback mode to pause at that point. 02) Press the Cue (11) button during playback to return to the cue point and enter pause mode. Fig. -
Page 16: Frame Search
CDMP-750 Frame search Frame search is a function for monitoring the sound at a certain section of the disc and manually changing the position. Searching is used to set a starting point with precision. 01) Turn the Jog wheel (10) while in pause mode or cue mode to begin searching. The sound for one revolution of the disc is output repeatedly. -
Page 17: Program Play
CDMP-750 Program play 01) Press the Play/Pause (13) button to enter the pause mode. 02) Press the Prog. (05) button, the player will enter the program mode. 03) Select the desired track by rotating the Edit encoder (03), confirm by pressing the track encoder. The selected track will be added to the program sequence. -
Page 18: Creating A Hot Loop
CDMP-750 Creating a hot loop Creating a hot loop is the action of “storing” the current loop in one of the four hot loop memories. 01) If you already have made a loop, skip steps 1 – 3 and proceed to step 4. Otherwise, you have to make a loop first and go to the next step. -
Page 19: Maintenance
CDMP-750 Maintenance The DAP Audio-CD-Player CDMP-750 requires almost no maintenance. However, the unit should be kept clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. Keep connections clean. -
Page 20: Product Specifications
CDMP-750 Product Specifications Quantization: 1 bit linear/Channel, 3 Beam Laser Oversampling rate: 8 Times Sampling Frequency: 44.1 kHz Frequency response: 20 Hz to 20 kHz ±2db T.H.D. + NOISE: < 0,03% S/N ratio (IHF-A): > 75 dB Dynamic range: > 75 dB Output level: 1,0 Volts R.M.S. -
Page 21: Dimensions
CDMP-750 Dimensions Ordercode: D1155... -
Page 22: Notes
CDMP-750 Notes Ordercode: D1155... - Page 23 CDMP-750 Ordercode: D1155...
- Page 24 CDMP-750 Ordercode: D1155...
- Page 25 ©2015 DAP Audio...
