- Page 1 Model 7100 Seven-Channel Power Amplifier Owner’s Manual ®...
-
Page 2: Please Read First
Outlaw Audio is not responsible for damage to any speaker system or other component that is caused by using products whose power rating is lower than that of the amplifier. -
Page 3: Table Of Contents
11 The Outlaw Audio 30-Day Satisfaction Guarantee 11 Outlaw Audio Limited Warranty The contents of this manual are Copyright © 2003 by Outlaw Audio, LLC, and may not be duplicated or reproduced by any means, whether physical, electronic or otherwise without prior written consent from Outlaw Audio. -
Page 4: Rear Panel
Use the REMOTE TRIGGER jack to connect to a compatible processor or other product with a 3-32 VDC output. (page 8) Speaker Outputs Use the OUTPUT binding posts to connect the amplifier to your speakers. (page 5) Outlaw Audio OUTLAW AUDIO U.S.A INPUT... -
Page 5: Connecting Your Amplifier
If you do not know the polarity of your speaker, consult the speaker’s manufacturer for further information. Model 7100 Seven-Channel Power Amplifier Owner’s Manual Connecting Your Amplifier... -
Page 6: Model 7100 Rear Panel Connections
Owner’s Manual Model 7100 Rear Panel Connections Model 7100 Rear Panel Connections � INPUT SURROUND RIGHT OUTPUT � � � � � � Outlaw Audio � OUTLAW NORTON MASSACHUSETTS AUDIO U.S.A INPUT INPUT INPUT INPUT SURROUND LEFT REAR RIGHT REAR LEFT... -
Page 7: Power Control Connections
This is also normal. To turn off your amplifier, simply turn off the unit that feeds the amplifier it’s audio signals. The 7100 will automatically go into a stand by mode in a few moments. -
Page 8: Troubleshooting Guide
If you follow the instructions in this manual you should enjoy many years of trouble free operation and, of course, high quality listening enjoyment. The Outlaw 7100 does not contain any user serviceable parts. If you suspect a problem that may require service assistance, contact us at customerservice@ outlawaudio.com, or by phone at 866-688-5292. -
Page 9: Potential Ground Loops In A Complex A/V System
Jensen VB-1BB. If the hum persists after all of the above suggestions have been tried, contact the Outlaw Audio customer service department for assistance. Set-top Box Coax Cable Cables Owner’s Manual... -
Page 10: Model 7100 Specifications
Owner’s Manual Specifications Model 7100 Specifications Power Output 7 x 100 watts @ 8 ohms, FTC: 20 - 20kHz, 0.05% THD, All Channels Driven, 7 x 165 watts @ 4 ohms, FTC: 20 - 20kHz, 0.05% THD, All Channels Driven Frequency Response 20Hz. -
Page 11: The Outlaw Audio 30-Day Satisfaction Guarantee
Outlaw Audio Limited Warranty This warranty protects the owner of the Outlaw 7100 Power Amplifier (the PRODUCT) for five (5) years from the date of purchase. This warranty covers all defects in material and workmanship with the following specific exceptions. - Page 12 Outlaw Audio, LLC P.O. Box 975 Easton, MA 02334 866-Outlaws (sales) 866-Outlaw A (support) Fax: 508-286-4120 printed in U.S.A.
