Summary of Contents for Outlaw 200 M-Block
- Page 1 Model 200 M-Block Power Amplifier Owner’s Manual ®...
-
Page 2: Installation Location
Outlaw Audio is not responsible for damage to any speaker system or other component that is caused by using products whose power rating is lower than that of the amplifier. -
Page 3: Table Of Contents
11 The Outlaw Audio 30-Day Satisfaction Guarantee 11 Outlaw Audio Limited Warranty The contents of this manual are Copyright © 2003 by Outlaw Audio, LLC and may not be duplicated or reproduced by any means, whether physical, electronic or otherwise without prior written consent from Outlaw Audio. -
Page 4: Front Panel And Rear Panel
Trigger Input Jack Connect this jack to the trigger output jack of a compatible product such as an Outlaw Audio Processor or Receiver that is capable of providing a 6-volt to 35-volt control signal at turn-on. When the Trigger Mode switch is set to the 12 Volt position, the Model 200 will turn on when the control signal is present. -
Page 5: Installation And Configuration
If the fuse blows repeatedly, discontinue use of the product and contact Outlaw Audio Customer Service for further assistance. AC Power Cord Receptacle Connect the AC power cord supplied with the unit to this receptacle, and connect the power cord plug to an AC outlet. -
Page 6: Model 200 Connection Diagram
(20mm) of insulation from the end of each wire and carefully twist the strands of each conductor together. Be careful not to cut the individual strands or twist them off; for optimal performance, all strands must be used. Outlaw Audio ������� �� ��� �������... -
Page 7: Audio Signal Connections
ON to place the Model is set to the right, in the “12V” position, should be turned ON to place the Model 200 in and return to the Standby Mode To prevent unintended operation, remember to turn the Model 200 M-Block Power Amplifier Operation... -
Page 8: Care And Maintenance
After checking all speaker connections, turn the unit back on. If it continues to turn off, check your speakers to verify that they are operating properly. If all other potential sources of trouble check out properly, contact Outlaw Audio for further assistance and information. -
Page 9: A Few Words About Hum And Noise
In some cases, the use of an approved AC Power Isolation Transformer of sufficient capacity may solve this problem. Owner’s Manual A Few Words About Hum and Noise 60Hz AC Ground Loop AC Line AC Ground Model 200 M-Block Power Amplifier AC Line... -
Page 10: Specifications
Jensen VB-1BB. If the hum persists after all of the above suggestions have been tried, contact the Outlaw Audio customer service department for assistance. Outlaw Audio Specifications Power Output 200 watts @ 8 ohms, 20 Hz 20 kHz, <0.05% THD... -
Page 11: Owner's Manual
This will ensure that your problem is discussed with a service technician who will determine if there is a quick solution to your problem. Outlaw Audio shall not be liable for, or in anyway responsible for, inci- dental or consequential damages of any kind. Some states do not allow limitations on how long an implied warranty lasts and/or do not allow the exclusion of incidental or consequential damages.
