Outback Power Systems Sealed FX Specification Sheet

M-series rugged marine power electronics

Advertisement

Quick Links

M-Series
Rugged Marine Power Electronics
OutBack M-Series inverter/chargers provide true sinewave power output,
and intelligent battery charging. They are modularly expandable to your
power needs providing a complete power conversion solution. They incorpo-
rate a DC to AC inverter, battery charger, and an AC transfer switch, which
combines 30 amp pass through and neutral/ground switching.
All OutBack inverter/chargers produce virtually distortion free sinewave AC
power for onboard electronics like sensitive home theater equipment and
microwaves with minimal RF interference. Industry leading surge power
starts heavy loads like air conditioning. Power factor corrected battery charging gets the most out of your
shore cord and generator while maximizing the life and performance of your batteries. Ultra fast AC
transfer switch with neutral/ground switching seamlessly transfers shore cord current without dropping
loads. Modular expandability is achieved through networked communications, allowing your inverter
system to grow with your power consumption needs.
The Sealed OutBack M-Series inverter/charger is the most rugged design in the world. Conformal coated
circuit boards, powder coated die-cast aluminum chassis resist corrosion. No other inverter/charger can
operate in extreme climate conditions, such as highly corrosive salt air, and achieve the same level of
reliability and performance as the sealed M-Series.
The Vented OutBack M-Series has the same proven technology and conformal coated circuit boards as
the sealed version but offered in a vented chassis for higher power output. The fully screened "bug-proof "
openings keep the power conversion components cool in very hot environments even when operated at
high power for extended periods in more protected environments.
The OutBack M-Series inverter is the superior choice when you need a reliable, powerful, modular, and
true sinewave inverter/charger.
Sealed FX
Water Resistant
True Sinewave AC Output
Intelligent Battery Charging
Modular System
High Surge Capability
Easy to Use
"Mount Anywhere" Design
Corrosion Resistant
Circuit Boards
High Efficiency
Neutral/Ground Switching
Networked Communications
Silent Operation
Standard 2 Year Warranty
Optional 5 Year Warranty

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sealed FX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Outback Power Systems Sealed FX

  • Page 1 The OutBack M-Series inverter is the superior choice when you need a reliable, powerful, modular, and true sinewave inverter/charger. Sealed FX Water Resistant True Sinewave AC Output Intelligent Battery Charging...
  • Page 2 M-Series Specifications Sealed Models FX2012MT Nominal DC Input Voltage 12 VDC Continuous Power Rating at 25° C 2000 VA AC Voltage/Frequency 120 VAC 60 Hz Continuous AC RMS Output at 25° C 17.0 amps AC Idle Power Full ≈ 20 Watts Search 2.6 Watts Typical Efficiency...
