Orion XTReme 400 Owner's Manual

2 channel amplifier
Hide thumbs


Advertisement

1
A mp Model
4ohm P ower
XTR-400
100 watts
XTR-800
200 watts
1. Power LED - when lit indicates the amplifier is on
2. Output Configuration Switches - determine the output
config. of the amplifier
3. Independent Gain Controls - continuously adjust from
200 mV to 5Vrms for full power output
4. RCA Inputs - accepts RCA input from a source unit
5. Aux RCA Outputs- extra connection for more amplifiers
6. Aux RCA Output Control - determines output of RCA
outputs
7. Low Pass Freq. Control - adjusts freq. of LP x-over
8. Low Pass X-over Activation Switch- turns x-over on / off
9. High Pass Q adjust - adjusts the "Q" of the HP x-over
10. High Pass x10 switch - selects the freq. range of the
11. High Pass Freq. Control - freq. adjust of HP x-over
12. High Pass X-over Activation Switch - turns x-over on/off
2
3
4
L owes t R ec ommend
F us e S ize
Impedanc e in S tereo
2 ohms
(2) 20 amp
2 ohms
(2) 30 amp
Owners Manual: (revis ed)
XT R eme 400 / 800 2 channel amplifier
HP x-over
6
9
10
5
7
8
F requency
T HD
S /N
R es pons e
6hz to 50K hz
<0.1%
100dB
6hz to 50K hz
100dB
<0.1%
11
12
Dimens ions L x W x H
12" x 10.25" x 2.25"
+/- 0.5dB
18" x 10.25" x 2.25"
+/- 0.5dB

Advertisement

Table of Contents
loading

  Also See for Orion XTReme 400

  Related Manuals for Orion XTReme 400

This manual is also suitable for:

Xtreme 800
