- Page 1 subwoofer HCCA HCCA Cone Cone Replacement Replacement 10.2 10.4 10.2 10.4 12.2 12.4 12.2 12.4 15.2 15.4 15.2 15.4...
-
Page 2: Table Of Contents
2. Have all components of the recone kit ready for installation before disassembling the woofer - do not leave the speaker gap (disassembled) and exposed for any length of time. This could result in foreign contamination which will affect woofer life and performance. -
Page 3: Re-Cone Kit
Allen wrench. To get access the basket may need to be turned on its side. 2. Place the speaker facing up and remove the Edge Clamping Ring. There are 8 Allen head bolts on the 10 & 12" models and 12 on the 15" model that clamp the surround edge to the basket. - Page 4 Steel needles (shown inserted) 6. Turn the speaker on its magnet with the cone facing up and align the pins so that they are all touching the pole piece (toward the center not the outside edge) and symmetrically arranged.
- Page 5 (Do Not Remove Basket from Magnet) 8. Return the speaker to its back and thread the Spider Ring bolts through the basket and into the Spider Ring. Make sure to use a small amount of thread locker (BLUE) on the threads. Do not tighten completely. The spider ring should be able to move freely (about 1mm in all directions).
- Page 6 If everything seems OK, then proceed to next step. 14. Install your speaker back in its enclosure. Connect the speaker to your system and adjust your system so you are listening to the subwoofer only. Start at a very low volume and listen for any mechanical rubbing sounds.
-
Page 7: Alternate Step 7-For 10" Woofers
ALTERNATE STEP 7—FOR 10" WOOFERS Note: Only the step for the 10” Woofers is given. 7. CAREFULLY lower the new re-cone assembly (moving parts) into the basket by tilting the voice coil (shown below) while making sure that all of the pins are inside the voice coil former (refer to the illustration at step 7 previously shown). - Page 8 Basket Re-Cone Assembly Spider Ring Terminal Block Voice Coil Terminal Block Basket Opening...
-
Page 9: Hcca Woofer Re-Cone Assembly
HCCA WOOFER RE-CONE ASSEMBLY Part Description Allen head screw Edge Clamping Ring Re-cone assembly Motor & Basket Assembly 1 set Allen head screw Steel needle Quantity 8 pieces (12 pieces 15” woofers) 1 piece 1 set 8 pieces 8 pieces... - Page 10 In such states, the exclusion or limitations stated herein may not apply to you. You may have specific legal or other rights which vary from state to state. p/n 920-0034 01-07 For more information on Orion products please visit us at www.orioncaraudio.com © 2007 Directed Electronics, All rights reserved. G27902.04.07.09.12.14 01-07...
