Owner's Manual
Oricom C1000
1.8 GHz DECT Wireless Conference Phone
TABLE OF CONTENTS
IMPORTANT SAFETY INFORMATION ...............................................................4
GETTING STARTED ...........................................................................................7
Contents Of Pack ....................................................................................7
Oricom C1000 DECT Wireless Conference Phone .................................8
LCD Display on the POD.......................................................................10
Phone Key.............................................................................................11
Basic Steps For Installation ...................................................................12
Charging the POD .................................................................................12
To Ensure Better Performance ..............................................................12
BASIC OPERATIONS ........................................................................................13
Standby .................................................................................................13
Answering Calls.....................................................................................13
Making Calls..........................................................................................14
Traditional Dialing.....................................................................14
Predialing .................................................................................15
Redialing ...............................................................................................16
Traditional Dialing.....................................................................16
Predialing .................................................................................16
Phonebook Dialing ................................................................................18
Traditional Dialing.....................................................................18
Predialing .................................................................................20
Services Dialing.....................................................................................21
Service Centre Quick Access ................................................................22
Things you can do during a call.............................................................23
Adjust Speaker Volume ............................................................23
Mute Call ..................................................................................23
Change Dial Tone.....................................................................24
Send Flash Signal ....................................................................24
Dialing Extra Digits ...................................................................24
Dialing from Phonebook Record ...............................................25
Displaying User Phone Number................................................26
Ringer Volume.......................................................................................27
Adjusting Ringer Volume ..........................................................27
Ringer On/Off Shortcut .............................................................27
Storing Numbers in the Phonebook.......................................................28
2
Advertisement
Table of Contents
Summary of Contents for Oricom C1000 1.8 GHz
-
Page 1: Table Of Contents
1.8 GHz DECT Wireless Conference Phone TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION ...4 GETTING STARTED ...7 Contents Of Pack ...7 Oricom C1000 DECT Wireless Conference Phone ...8 LCD Display on the POD...10 Phone Key...11 Basic Steps For Installation ...12 Charging the POD ...12 To Ensure Better Performance ...12... - Page 2 Programming...29 Start Programming ...29 Ringer Melody ...30 Recall Duration ...31 Users Phone Number ...32 Network Services Number ...33 Service Centre Number ...34 Returning to factory Default Setting ...35 Additional Features ...36 Call Recording ...36 Out of Range Warning ...36 Paging ...36 Low Battery ...37 QUICK REFERENCE GUIDE ...38 TROUBLE SHOOTING ...40...
- Page 3 • Do not use your telephone during an electrical storm thunderstorm as it is possible to get an electric shock. Refer to information contained in Telstra White pages directory. • Do not use this product to report a gas leak in the vicinity of the leak. •...
-
Page 4: Getting Started
User’s Guide If any of these items are missing, please contact the dealer were you purchased this product. Oricom C1000 DECT Wireless Conference Phone Clear / Number During dialing/programming, press to clear previous digit; or press and hold to delete the entire string of numbers. -
Page 5: Lcd Display On The Pod
Base Page button Press to page POD if you want to find the misplaced POD. In Use LED Flashes during incoming call and steadily lit when the phone is in use. Record Jack For call recording. Power LED Steadily lit when power is connected to the base. -
Page 6: Phone Key
Phone Key Key Function Phone Book Service Recall Redial / Program Clear / Number Down Phone On/Off Mute Ringer On/Off Dial Tone Pause Basic Steps For Installation 1. Set up the base and POD on a flat, stable surface. 2. Connect the output plug of the base adaptor to the bottom of the base unit and the adaptor to the main wall outlet. -
Page 7: Basic Operations
BASIC OPERATIONS Standby • When the phone is not in use, the POWER LED on the base is turned on and the LCD on the POD displays your phone number, if programmed. Answering Calls When there is an incoming call, the GREEN LEDs on the base and the POD blink and the icon flashes on the display. -
Page 8: Predialing
Making Calls Predialing The phone number is entered before the phone line is seized. The phone number can be verified before you place the call. • Enter the phone number. Digits are displayed. • Press CLEAR key to clear previous digit during number entry. -
Page 9: Predialing
Redialing • Call timer and talk time remaining counter are displayed accordingly. • Press PHONE key again to end the call. Note: If the last dialed number has more than 18 digits, only the last 18 digits shall be displayed. The Scroll icon shall turn on. It can hold up to 44 digits in the last dialed number. -
Page 10: Predialing
Phonebook Dialing Note: If no phonebook record is selected after PHONEBOOK key has been pressed, i. Press CLEAR key to exit phonebook selection and to return to the call and talk timers. ii. Pressing “* “ , “#”, PHONEBOOK, and SERVICE keys will have no effect. iii. -
Page 11: Services Dialing
Services Dialing Services’ dialing allows you to call network service (e.g. conference services) by a single key press. Refer to the programming section for how to enter or edit the services phone number. • Press SERVICE key in Standby to seize the line. -
Page 12: Things You Can Do During A Call
Things you can do during a call You can do the following during a call, a. Adjust speaker volume; b. Mute call; c. Change dial tone; d. Send Recall signal; e. Dial extra digits; Dial from phonebook record; g. Display user phone number. Adjust Speaker Volume 16 different levels of speaker volume can be selected. -
Page 13: Dialing From Phonebook Record
Things you can do during a call Dialing from Phonebook Record You can dial any phonebook number when you are talking on the phone. Phone book dialing can be used as many times as you like during a call. • Press PHONEBOOK key. (The phonebook icon turns on.) •... -
Page 14: Ringer Volume
Ringer Volume The POD has six ringer volume levels for selection (including OFF). The ringer volume can be adjusted or turned on/off when the phone is ringing or during Standby. Adjusting Ringer Volume • Press UP/DOWN keys to adjust the ringer volume. (The volume bars shall display and change accordingly. -
Page 15: Start Programming
Programming You can program the ringer melody, dialing mode, Recall duration, user phone number, network service number, and service centre number. You can also reset all settings back to the factory defaults. Start Programming • Press and hold PROGRAM key during Standby. -
Page 16: Recall Duration
Programming Recall Duration • Press and hold PROGRAM key during Standby. • Press “3” to select recall duration programming. (The default setting 100ms duration is displayed.) • Press PROGRAM key to select Recall duration programming. (The current selection flashes.) • Press “1” to “4” to select duration 1 to duration 4 respectively. -
Page 17: Network Services Number
Programming Network Services Number • Press and hold PROGRAM key during Standby. • Press “5” to select network services number programming. (The LCD displays the current number if available; otherwise a blank screen will be displayed.) • Press PROGRAM key to select service number programming. -
Page 18: Returning To Factory Default Setting
Programming Returning to factory Default Setting • Press and hold PROGRAM key during Standby. • Press and hold “9” to return the phone to the factory default settings. (The display will show “888888888888888888”.) • Press PROGRAM key to confirm the selection. •... -
Page 19: Low Battery
Additional Features Low Battery • During standby, the battery icon will become empty and starts flashing when the battery is low. • During phone mode, the LED’s on the POD flashes RED quickly every minute and the empty battery icon flashes when the battery is low. -
Page 20: Trouble Shooting
QUICK REFERENCE GUIDE Program Network • Press and hold → Press 5 → Services Number to erase digit or enter new number → Press Program Service • Press and hold → Press 6 → Centre Number to erase digit or enter new number → Press Set Default Setting •... -
Page 21: Wall - Mounting
If the product is then found to be faulty you will be asked to return it directly to us with a copy of the purchase receipt. Australia Oricom International Pty Ltd PO Box 5681 South Windsor, NSW 2756 Customer support Email: support@oricom.com.au...
