QUICK START GUIDE

WMR100 ADVANCED WEATHER STATION
with Wireless Sensor Set and Mounting Package
UNPACK
A
Make sure that you have all of the parts shown here before
the installation of the Advanced Weather Station.
MAIN UNIT
RAIN GAUGE
WMR100 Base
6V Adapter
1.5V AA Batteries
USB Cable
POLE MOUNT
INTEGRATED WIND GAUGE
Wind Vane
Wind Sensor
Wind Direction
Stem
Indicator
1.5V AA Batteries
Screws (Type B)
B
1
Install 4 AA batteries located
underneath the base unit.
Filter
Rain Collector
Screws (Type C)
C
1.5V AA Batteries
Washers
Support Base
Pole Sections
Round
Cone-Shaped End
U-Shaped Bolts
1
Slide wind direction indicator onto wind sensor and align
Metal Pins
Tension Strings
the screw holes. After aligning the holes, use a Type B
screw to secure.
2
Attach the wind speed vane on the top of the wind sensor,
align the holes, and use a Type B screw to secure.
3
When installing outside, rotate the NORTH Indicator
reference line to the "north" and align the wind indicator
Rectangular
Screws (Type A)
in the same direction.
Base Legs
SET-UP MAIN UNIT
1
2
2
Install power plug into the base station
and insert the AV adapter into the wall
outlet.
SET-UP INTEGRATED WIND SENSOR
2
4
1
3
4
Rotate the battery cover counter-clockwise and slide cover off
to expose the battery compartment. Insert 4 AA batteries.
5
Press the RESET button.
6
Rotate the battery cover clockwise and slide cover on to close
the battery compartment.
7
On the base station, press the SEARCH button to initiate a
wireless sensor search.
3
Press the RESET button.
5
6
7
9
8
Wind Speed: Gently rotate the wind vane and confirm a
numerical reading on the base unit (
Indicator: Move the direction of the wind indicator and verify the
icon moves in the same (
9
To test the temperature reading, press the SELECT button on
the black rotating dial until the selected area icon ( ) is on the
second level (
to channel 1 and verify a numeric reading.
3
8
). Wind Direction
).
) of the LCD display. Rotate the dial clockwise
