Oregon Scientific Pedometer with Pulse Meter PE326PM User Manual

GETTING STARTED
INSULATION TAPE
Before using the device, pull out the insulation
tape underneath the battery cover.
NOTE The unit will not work until the tape is
Pedometer with Pulse Meter
pulled out.
Model: PE326PM
BATTERIES
USER MANUAL
INTRODUCTION
Thank you for selecting an Oregon Scientific™
pedometer (PE326PM).
Keep this manual handy as you use your new
product. It contains practical step-by-step
instructions as well as technical specifications and
warnings you should know about. To change the batteries:
1. Gently press and pull the battery
compartment door.
KEY FEATURES
2. Insert 2 x LR44 size 1.5V batteries or
equivalent.
FRONT VIEW
3. Replace the battery compartment door.
NOTE Protect the environment by taking
exhausted batteries to authorized disposal
stations.
Shows when batteries are low.
To open the cover:
Holding the pedometer upright, grasp the clip with
one hand and press the COVER RELEASE
button with the other.
1. Pulse meter: Insert finger to measure pulse
rate
2. COVER RELEASE: Press to open CLOCK
protective cover
1. Press MODE until the STEP mode is
3. Battery compartment
displayed.
2. Press and hold MODE for two seconds. The
INTERIOR
12-hour value will flash. Press RESET /
to select between 12 hour and 24 hour
format.
2. Press MODE, the "hour" digits will flash.
3. Press RESET /
1. MODE: Toggles between STEP, DIST /
and hold to increase the value rapidly.
TIMER and CAL / TIMER
4. Press MODE to confirm the change and
2. ST / SP: Starts / Stops timer
move on to the next setting.
3. : Turns backlight on
5. Repeat 3, 4 to complete setting minute and
4. Motion Sensitivity switch: Increases or
second values.
decreases unit sensitivity
5. LCD
ADJUSTING THE SETTINGS
6. : Press to enter PULSE mode
DISTANCE AND CALORIES
7. RESET / : Resets display mode values to
zero, increases value in settings
Total distance = steps taken x average step
8. Belt clip
length. Measuring distance correctly depends on
setting the correct average length of individual
stride.
LCD
Precise calories expended calculations require
taking into account many factors. The PE326PM
uses body weight and the number of steps taken
to give a good estimate.
To set stride length and body weight:
1. In DIST / TIMER or CAL / TIMER mode
press and hold MODE for two seconds to
1. Displays when in PULSE mode
enter STRIDE / WEIGHT display. The stride
2. Displays when batteries are low
numbers will flash.
3. Displays when calories are shown
4. Displays when timer is running
5. AM / PM for 12 hour format
6. Indicating mode displayed:
•
STEP displays the number of steps taken
and the clock
•
DIST / TIMER displays the distance
traveled and the count-up timer
•
CAL / TIMER displays the approximate 2. Press RESET /
stride is selected (30 to 150cm or 11 to 60
number of calories expended and the count-
inches).
up timer
7. Distance in Km or Mile 3. Press MODE, the weight numbers will flash.
8. Weight in Kg or Lbs
4. Press RESET /
9. Displays when in Timer Mode
setting is reached (30-150kg or 65-340lbs).
10. Stride in Cm or Inches
5. Press MODE to confirm and exit.
TIP Individual stride-length varies. Input an
appropriate length for an average stride. To
determine length of stride walk 10 paces and
divide distance traveled by 10.
NOTE To make the unit more or less sensitive to
motion, reposition the motion sensitivity switch. To
determine the proper amount of motion sensitivity,
experiment with different settings.
MOTION SENSITIVITY
Follow these important procedures to adjust
the Motion Sensitivity and ensure accurate
readings:
1. Correctly position and attached the unit to a
belt or waistband.
2. Reset step counter to zero.
3. Walk at a normal pace; take at least 100
steps.
4. Adjust sensitivity switch if walking speed
changes. Repeat steps 2-4 until accurate
reading is obtained.
The following conditions may cause incorrect
reading of steps taken:
1. Uneven walking pace, such as walking in
crowded areas or on uneven floor.
2. Frequent up and down movements, such as
standing up and/or sitting down; running,
to alter hour value. Press
jumping, going up and down stairs etc.
USING THE PEDOMETER
COUNT-UP TIMER
The count-up timer will start from zero and count
to a maximum time of 99 hours, 59 minutes, and
59 seconds (99:59'59")
1. In DIST / TIMER or CAL / TIMER mode
press ST / SP to start the timer.
2. Press ST / SP again to stop the timer.
To reset the timer to zero, press RESET /
DIST / TIMER or CAL / TIMER mode.
TO VIEW VALUES
To view steps taken, distance traveled and
calories expended:
Press MODE to enter the desired mode.
To reset the values, press RESET / in STEP
until the desired length of
mode.
NOTE The total distance and calories expended
will be cleared along with the total steps.
until desired weight
MEASURING PULSE RATE
The built-in Pulse meter provides an easy way to
measure your pulse rate while working out.
A person's pulse rate indicates the number of The contents of this user manual and technical
times that the heart beats within a given amount specifications are subject to change without
of time. This unit attempts to calculate further notice. Images not drawn to scale. The
approximately how many times a heart will beat in manufacturer and its suppliers hold no
one minute. responsibility to you or any other person for any
damage expenses, lost profits or any other claim
Insert your finger loosely into the Pulse meter on that arose by using this product.
the outside of the unit.
SPECIFICATIONS
TYPE
Operating
modes
Real time clock
Step counter
Distance
traveled
Count up timer
1. Press to enter PULSE mode. The
symbol will flash while pulse is measured.
Stride distance
Calorie
Weight range
Pulse range
Operating temp
Storage temp
Batteries
2. The pedometer will return to previous mode
Battery life
a few seconds after finger is removed.
Product size
Alternatively, press to exit PULSE mode.
(L x W x H)
Weight
PULSE RATE TROUBLESHOOTING
ABOUT OREGON SCIENTIFIC
If you cannot get a reading or think yours is not
correct, follow these tips to ensure accurate
Visit our website (www.oregonscientific.com) to
measurements:
learn more about Oregon Scientific products such
•
Cold fingertips and chill air can affect the
as digital cameras; MP3 players; children's
measurement. You may need to warm your
electronic learning products and games;
hands before you start.
projection clocks; health and fitness gear; weather
•
The sensor is sensitive to light sources.
stations; and digital and conference phones. The
Cover the entire sensor area with your
website also includes contact information for our
fingertip to block all light.
Customer Care department in case you need to
•
Gently touch the pulse sensor; do not press
reach us, as well as frequently asked questions
hard.
and customer downloads.
•
Keep still and calm during measurement.
Moving about can affect the reading.
We hope you will find all the information you need
on our website, however if you're in the US and
Wait the proper amount of time: measurements
would like to contact the Oregon Scientific
can take 6-12 seconds depending on the stability
Customer Care department directly, please visit:
of the signals received.
www2.oregonscientific.com/service/default.asp
FITNESS TIPS OR
To keep fit, it generally takes a person weighing
Call 1-800-853-8883.
60kg to walk 10,000 steps to burn approximately
300 calories. The following diagram will give you
For international inquiries, please visit:
some basic reference to the calorie consumption
www2.oregonscientific.com/about/international.as
for people of various weights.
p
EU-DECLARATION OF CONFORMITY
Hereby, Oregon Scientific, declares that this
pedometer (model PE326PM) is in compliance
with the essential requirements and other relevant
provisions of EMC directive 89 / 336 / CE and
LVD directive 73 / 23 / EC.
WARNINGS
A copy of the signed and dated Declaration of
This product is designed to give you years of
service if handled properly. Observe the following Conformity is available on request via our Oregon
Scientific Customer Service.
guidelines:
•
Clean the unit with a slightly damp cloth and
mild detergent.
•
Never immerse the unit in water. This can
cause electrical shock and damage the unit.
•
Do not subject the main unit to extreme
force, shock, or fluctuations in temperature
or humidity.
in
•
Do not tamper with the internal
components. Doing so will terminate the
unit's warranty and may cause damage.
The unit contains no user-serviceable parts.
•
Do not mix new and old batteries or
batteries of different types.
•
Do not use rechargeable batteries with this
product.
•
Remove the batteries if storing this product
for a long period of time.
•
Do not scratch the LCD.
•
Read this instruction manual thoroughly
before operating the unit.
•
Do not dispose this product as unsorted
municipal waste. Collection of such waste
separately for special treatment is
necessary.
DESCRIPTION
STEP, DIST / TIMER, CAL /
TIMER
12 hour / 24 hour option with
hour / minute / second
display
0 to 99,999 steps
0 to 999.99 km
(0 to 999.99 miles)
99 hours, 59 minutes, 59
seconds
30 to 150 cm
(11 to 60 inches)
0.1 to 9999.9 kcal
30 to 150 kg (60 to 340 lbs)
40 to 206 bpm
-10 to 40 °C (14 to 104 °F)
-20 to 60 °C (-4 to 140 °F)
2 x LR44 1.5V
1 year
64 x 33 x 40 mm
(2.52 x 1.30 x 1.58 inches)
33.0 g (1.16 ounces)
