User Manual
3.5" SBC with Intel® Celeron® M CPU with VGA/LVDS/TTL,
GbE, USB 2.0 and Audio
Quick Installation Guide
Package Contents
WAFER-8523 package includes the following items:
1 x WAFER-8523 Single Board Computer
1 x SATA cable
1 x Audio cable
1 x KB/MS Y cable
1 x USB cable
1 x Mini Jumper Pack
1 x Utility CD
1 x QIG (Quick Installation Guide)
WAFER-8523
Version 1.0
Nov. 12, 2008
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Related Manuals for IEI Technology WAFER-8523
Summary of Contents for IEI Technology WAFER-8523
-
Page 1: Quick Installation Guide
WAFER-8523 Quick Installation Guide Version 1.0 Nov. 12, 2008 Package Contents WAFER-8523 package includes the following items: 1 x WAFER-8523 Single Board Computer 1 x SATA cable 1 x Audio cable 1 x KB/MS Y cable 1 x USB cable... - Page 2 Specifications CPU: On board Intel® Celeron® M 600MHz 512K cache / 1.0GHz zero cache processor with a 400MHz FSB System Chipset: Intel 852GME+ICH4 BIOS: AMI Flash BIOS System memory: 1x 200-Pin DDR SO-DIMM SDRAM 200/ 266MHz up to 1GB Ethernet: One Realtek RTL8110SC GbE chipset I/O Interface: 1 x SATA by IDE to SATA chip ULI-JMICRON JM20330...
-
Page 3: Ordering Information
Dimension: 146 mm x 102 mm Weight: GW: 670g; NW: 240g Ordering Information WAFER-8523-600-R10: 3.5" SBC with ULV Intel® Celeron® 600MHz 512K cache CPU with VGA/LVDS/TTL, LAN, USB 2.0 and Audio WAFER-8523-1GZ-R10: 3.5" SBC with ULV Intel® Celeron® 1GHz zero cache CPU with VGA/LVDS/TTL, LAN, USB 2.0 and Audio... - Page 4 JP5: Select RS-232 or RS-485/RS-422 on COM2 DESCRIPTION RS-232 (Default) RS-422 RS-485 Table of Connectors LABEL FUNCTION FAN Connector ATX Power Control Connector Power Button Connector LCD Panel Inverter Connector Main Power Input Connector PC104 -5V/-12V Power Input Connector CN13 Infrared Interface Connector CN15 +3V Battery Connector...
- Page 5 CN4: ATX Power Control Connector CN1: FAN Connector AT Mode: Short 2-3 (Default) PIN NO. DESCRIPTION ATX Mode: Use PS_ON & 5VSB cable FANIO PIN NO. DESCRIPTION +12V +5VSBY PS_ON# CN7: Power Button Connector PIN NO. DESCRIPTION CN5: LCD Panel Inverter Connector PWBTN# PIN NO.
- Page 6 CN9 : Serial ATA HDD Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION CN12 : Internal Serial Port Connector (COM2) (RS-232/422/485) PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA CARRIER DATA SET READY DETECT (DCD#) (DSR#) RECEIVE DATA (RXD) REQUEST TO SEND (RTS#) TRANSMIT DATA CLEAR TO SEND...
- Page 7 CN22: VGA DB 15-pin Female Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION GREEN BLUE CRT_PLUG# DDCDAT HSYNC VSYNC DDCCLK CN21: External Serial Port Connector (COM1)(RS-232) PIN NO. DESCRIPTION DATA CARRIER DETECT (DCD#) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) DATA TERMINAL READY (DTR#) (GND) DATA SET READY...
- Page 8 CN2: TTL LCD Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCD_VCC LCD_VCC LCD_VCC LCD_VCC TFT_B0 TFT_B1 TFT_B2 TFT_B3 TFT_B4 TFT_B5 TFT_B6 TFT_B7 TFT_G0 TFT_G1 TFT_G2 TFT_G3 TFT_G4 TFT_G5 TFT_G6 TFT_G7 TFT_R0 TFT_R1 TFT_R2 TFT_R3 TFT_R4 TFT_R5 TFT_R6 TFT_R7 FPCLK TFT_VS FPDEN TFT_HS LCD_EN...
- Page 9 CN24 : CF Card Interface Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION CD1# CE2# VS1# IOR# IOW# CSEL# VS2# RESET# WAIT# INPACK# REG# BVD2 BVD1 IOCS16# CD2# GND2 CN11: Internal USB Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) VCC (+5V) DATA- DATA-...
- Page 10 CN10: PC/104 Connector (ISA-Bus) PIN Description PIN Description PIN Description PIN Description IOCHCK# RESET SBHE# D2 MEMCS16# VCC5 LA23 IOCS16# IRQ9 LA22 IRQ10 LA21 IRQ11 DRQ2 LA20 IRQ12 -12V SA19 IRQ15 OWS# SA18 IRQ14 +12V SA17 DACK0# A10 IOCHRDY B10 MEMR# DRQ0# B11 SMEMW# C11...
- Page 11 Board Layout: Jumper and Connector Locations...
