Summary of Contents for Oreck STEAM 75
- Page 1 Steam 75 User’s ® Guide ® Important! Read this manual carefully, and keep for future reference.
- Page 2 Click Visit The Steam 75 is practical for any surface with the exception of those surfaces that are extremely heat sensitive. We recommend NOT using it on fine silks, delicate materials such as velour, some very thin plastics, unsealed hardwood, ceilings, drywall, and exterior paint of automobiles, electronics or items using electricty.
-
Page 3: Table Of Contents
Safety ........4 General Warnings ......4 Grounded Plug . -
Page 4: Safety
General Warnings IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this steam cleaner WARNING! To reduce the risk of fire, electric shock, or injury when using an electrical appliance, basic precautions should always be followed, including the following: • Do not leave appliance unattended when plugged in. Unplug from outlet when not in use and before servicing. - Page 5 • Do not operate without water in the water tank. • Do not fill the water tank with anything other than water or Oreck Fresh Air Steam Mop Essence. Never put additives ®...
-
Page 6: Grounded Plug
Grounded Plug This appliance must be grounded. If it should malfunction or break down, grounding provides a safe path of least resistance for electrical current, reducing the risk of electrical shock. The cord for this appliance has an equipment-grounding conductor and a grounding plug. -
Page 7: Parts
Product Components & Accessories Front View 1. Handle 2. Power cord 3. Water tank 4. Hard water filter 5. Steam tank/power indicator 6. Swivel floor head 7. Bonnet... - Page 8 Back View 7. Steam trigger 8. Upper cord clip 9. Lower cord clip Accessories 10. Microfiber cleaning pad 11. Carpet glider 12. Measuring cup...
-
Page 9: Features
1. Hard Water Filter The Hard Water Filter protects internal hoses and the Swivel Floor Head from mineral build-up due to harmful hard water. 2. Swivel Floor Head The Swivel Floor Head provides flexibility and ease of movement when using the steam cleaner. 3. -
Page 10: Assembly
WARNING! Do not plug the steam cleaner into an electrical outlet during assembly. 1. Insert the handle into the body. Line up the holes in both the body and handle. 2. Insert the large screw and fasten. 3. Insert the body into the floor head. -
Page 11: Use
Before you begin Cleaning WARNING! Do not plug the steam cleaner into an electrical outlet during assembly. 1. Remove the water tank. 2. Remove the cap on the water tank. 3. Using the measuring jug, fill the water tank. The water tank can hold 17 fl. -
Page 12: Attaching The Microfiber Cleaning Pad
3. When refreshing carpet, place the Carpet Glider on the Microfiber Cleaning Pad. The Steam 75 is practical for any surface with the exception of those surfaces that are extremely heat sensitive. We recommend NOT using... -
Page 13: Cleaning Hard Floors And Refreshing Carpets
Steam Cleaning Hard Floors and Refreshing Carpets WARNING! To reduce the risk of personal injury, unplug cord from electrical outlet and let the unit/accessories cool down completely before handling. • Do not leave the steam cleaner in one spot on any surface for an extended period of time with a damp or wet microfiber cleaning pad attached. - Page 14 1. Ensure the proper accessory is attached to the floor head. Hard Floors: Microfiber cleaning pad Carpet: Microfiber cleaning pad and carpet glider. 2. Plug the power cord into a polarized electrical outlet. Wait for the Steam tank/ power indicator to turn green. 3.
-
Page 15: Clean-Up After Use
Clean Up after Use WARNING! To reduce the risk of personal injury, unplug cord from electrical outlet and let the unit/accessories cool down completely before handling. Empty the Water Tank 1. Remove the water tank. 2. Over a sink, turn the cap counter- 3. -
Page 16: Remove The Microfiber Cleaning Pad
Remove the Microfiber Cleaning Pad WARNING! To reduce the risk of personal injury, unplug cord from electrical outlet and let the unit/accessories cool down completely before handling. Cleaning the Microfiber Cleaning Pad Never use bleach or fabric softener when washing the microfiber cleaning pad. -
Page 17: Maintenance
• The condition of the hard water filter affects the perfor- mance of the steam cleaner. The interval between filter replacement depends on the hard water conditions and the level of usage. Replacing the Hard Water Filter The hard water filter will help filter minerals that reduce the effectiveness of the steam cleaner. -
Page 18: Troubleshooting
Service problems that appear to be major can often be solved easily. You can be your own troubleshooter by reviewing this shooting guide. All other servicing should be done by an Oreck authorized service center. Cleaner will not run Steam is not... -
Page 19: Replacement Parts
To order, call our customer service group or visit our website. Please have your model number from the data label on the bottom of the unit. Item Hard Water Filter Pack of (4) Microfiber Replacement Bonnets Number Replacement Parts STEAMFLTR75 STEAMKIT75... -
Page 20: Warranty
Oreck or an Oreck Authorized Retail Dealer.) Steam Cleaner Oreck will repair or replace, free of charge, to the original purchaser, any part that is found to be defective in material or workmanship within one (1) year of the date of purchase. This limited warranty applies to normal domestic use. - Page 24 © 2010 Oreck Holdings, LLC. All rights reserved. All marks, text, logo’s, product configurations and registered trademarks are owned and used under the authority of Oreck Holdings, LLC 53543-01 REV A 08/10 ECN R-10093...
