- Page 1 RACLE UDIO ELPHI MARK V turntable WNER’S MANUAL by Oracle Audio Technologies inc.
-
Page 2: Table Of Contents
! Total accuracy of your source system can only be achieved through minute details of turntable suspension calibration, tone arm installation and cartridge alignment. 3 - 4 5 - 6 - 7... -
Page 3: Pack And Unpack Your Delphi
All the accessories are positionned strategically in the packaging to prevent them from coming loose and possibly damaging the turntable during shipping. IMPORTANT ! When shipping the turntable position each item in its allocated section. - The following items are located in the upper section of packaging. -
Page 4: Adjust The Plinth Assembly
Locate the bearing assembly in the lower section of the packaging. mounting screws. Locate the tool kit in the lower section and select the appropriate allen key... 9/64th Lift the subchassis straight up and mount the bearing assembly from underneath (ground lug side). -
Page 5: Precisely Align The Phono Cartridge
Important ! If you are planning to cut your own mounting board, remember that the cutting of the arm board can sometimes be troublesome as well as being a potential hazard. The use of an adequate tooling is important to both accuracy and safety. Use stainless steel or aluminum screws to mount the cartridge for maximum rigidity. - Page 6 changing the position of the spring in its holder. The color coding is visible from the inside at the wider end of the spring. Note 2: The reference to clockwise or counter-clockwise is determined by viewing the spring from above, unless otherwise mentionned. Note 3: By hand the spring can only be rotated counterclockwise in its holder but, using needle nose pliers, it can be held near the tip at the wider end.
- Page 7 Place the subchassis over the suspension modules. Install the platter without the drive belt. Locate the suspension gauge in the documentation envelope. Punch the suspension gauge out of the card. Do not consider "A", nor 1 & 2, they were used on the earlier models. Place the gauge on the acrylic base with the "B"...
-
Page 8: Dress The Phono Lead
If the loop is too long, the lead could come in contact with the table below the turntable. If it is too short, it will keep the suspension system from moving freely. In both cases, this would be detrimental to the sound. -
Page 9: Remove The Platter With The Drive Belt Installed
Lifting the platter without looking after the drive belt could possibly damage it..connect the power supply Plug the power supply output to the turntable input receptacle located to the rear of the turntable. Plug the input cord to an AC outlet. -
Page 10: Attach The Ground Lead
What to do ..if the turntable does not start and the speed indicating light does not go on Check: - AC connection to the wall outlet. -
Page 11: For Maintenance
Check: - drive belt - motor connection plug for a broken wire - drive module for a broken wire - defective drive module ... if the platter is not parallel with the plinth Check: - suspension calibration using the suspension gauge Note: If a relatively important change occured in one particular suspension module, it could be the sign of an improperly seated spring of sorbothane ring. - Page 12 You are now ready for the real and only purpose of all this... to sit down and relax, to just listen and enjoy beautiful music. The people at Oracle Audio Technologies inc. 6136 boulevard Bertrand Fabi, suite 101 Rock Forest. Quebec. Canada...
