Table of Contents
Precautions .......................................................................................... 2
About the Product ................................................................................. 3
Package Overview ............................................................................... 4
Product Overview ................................................................................. 6
Connecting the Projection Display ........................................................ 9
Powering On/Off the Projection Display................................................ 11
Adjusting the Image Size ...................................................................... 13
User Controls
User Controls ....................................................................................... 14
OSD Menus .......................................................................................... 16
Troubleshooting .................................................................................... 22
Maintenance ......................................................................................... 25
Specifications ....................................................................................... 28
Compatibility Modes ............................................................................. 29
English
1
Advertisement
Table of Contents
Related Manuals for Optoma Optoma EP615H
Summary of Contents for Optoma Optoma EP615H
-
Page 1: Table Of Contents
Table of Contents Usage Notice Precautions ... 2 Introduction About the Product ... 3 Package Overview ... 4 Installation Product Overview ... 6 Connecting the Projection Display ... 9 Powering On/Off the Projection Display... 11 Adjusting the Image Size ... 13 User Controls User Controls ... -
Page 2: Usage Notice
English Usage Notice Do not look into the lens. The bright light may hurt your eyes. Warning- To reduce the risk of fire or electric shock, do not expose this Warning- product to rain or moisture. Please do not open or disassemble the product as this may cause Warning- electric shock. -
Page 3: Introduction About The Product
Introduction About the Product This product, designed with a high-powered UHP lamp, is an XGA data/video portable projection display. The outstanding feature of it are listed as follows: 8.9 lbs. (4.0 kgs) lightweight compact design True XGA, 1024 x 768 addressable pixels With SXGA compression and VGA/SVGA resizing Mac / NEC PC-98 / FM Towns compatible NTSC / NTSC4.43/ PAL/ PAL-M / PAM-N / SECAM compatible... -
Page 4: Package Overview
English Package Overview This projection display comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. LCD Projection Display Power Cord VGA Cable S-Video Cable RCA Audio/ Video Cable Audio-in Cable for Computer User’s Manual... - Page 5 English Remote Mouse Package Remote Receiver Cable Wireless Remote Battery x 3 Mouse Set PC PS/2 PC PS/2 Mouse Adapter Remote Adapter Remote Adapter Mouse Adapter...
-
Page 6: Installation Product Overview
English Installation Product Overview M Main Unit Speakers Carrying Handle Elevator Releasing Button Elevator Foot Air Filter * There are two elevator releasing buttons and elevator feet on both sides. * There are also two remote control receivers on the front and the rear side. Panel Controls 100-240V 50-60Hz 2.5A... -
Page 7: Connection Ports
M Connection Ports Audio Input for Computer Composite Video Connector S-Video Connector M Panel Controls Four Directional Select Keys Enter English Remote Mouse Connector Audio Output Connector Audio Input Connector Monitor Loop-Through Connector Computer 1 Input Connector Power Connector 100-240V 50-60Hz 2.5A Computer 2 Input Connector... - Page 8 English M Remote Mouse Keystone Power On/Standby Freeze/Clear Source Selection Zoom Out / Zoom In Four Directional Select Keys Menu Enter/Pointer Volume Mouse Left Button Down Right Mouse Button / Backlight Function Left Mouse Button Joy Stick (Mouse Cursor Function)
-
Page 9: Connecting The Projection Display
Connecting the Projection Display Remote Receiver Cable RCA Audio Video Cable S-Video Cable VGA Cable Audio Cable Audio Cable Monitor Cable 100-240V 50-60Hz 2.5A English Power Cord... - Page 10 English w Connecting the Remote Mouse Follow regular setup procedures. Make sure you have a 100% compatible Microsoft Mouse and a Microsoft Mouse driver installed. Setting Up Procedure: 1. Turn off your computer. 2. Unplug the mouse from your computer.* 3.
-
Page 11: Powering On/Off The Projection Display
Powering On the Projection Display. 1. Remove the lens cover 2. Plug the power cord into the back of the projector and plug it into the electrical outlet. The “POWER/STANDBY” LED indicator will flash green. 3. Turn on the lamp by pressing “ POWER/STANDBY” button. - Page 12 English Adjusting the image size M Adjust the height of projected image Q Raise the projection display to the desired angle and then press the elevator release buttons to release the elevator foot. R Fine-tune the height by manually turnig each foot. (Refer to the following figures below) Screen Elevator Foot...
-
Page 13: Adjusting The Image Size
M Adjusting the Image Size [ ] Maximum ( ) Minimum [27”] (20”) 27” Max. Screen Min. 20” (inch) Distance(ft.) 3.8’ 20” Screen Size ) inch W x H 16 x 12 *The graph is for user’s reference only. Focus the image You may adjust zoom ring to zoom in/out 1.3 times of the image size. -
Page 14: User Controls
English User Controls User Control Overview There are two ways for you to control the functions: panel control and remote control. M Panel Controls M Remote Control Power On/ StandBy Source Selection FourDirectional Select Keys On-Screen Menus Mouse Left Button Down Left Mouse Button Joystick (Mouse Cursor Function) - Page 15 Press “Menu” to open the on-screen display (OSD) menus and to switch among different menus. " To exit OSD, press the “Freeze/CLR” button or select the “ Exit Menu” icon and press “Enter” button. The projector saves any changes you made automatically. Source Press “Source” to choose between video and computer sources.
-
Page 16: Osd Menus
OSD will be the “Computer OSD”. In Video source, the OSD will be the “ Video OSD”. The projector will detect the source automatically. To open the OSD menus, press the “Menu” button on the Remote Control or Panel "... -
Page 17: Image Adjustment
Auto-Image " The projector automatically adjusts tracking, frequency and vertical and horizontal position for most computers. * The image options are available only for computer sources. The projector can sets these options automatically for video sources. Audio Volume "... -
Page 18: Video Mode
When you select this function, the projector turns the image upside down for ceiling-mounted projection. Rear-Ceiling " When you select this function, the projector reverses and turns the image upside down at same time. You can project from behind a translucent screen with ceiling mounted projection. Video Mode: Language Language "... -
Page 19: Keystone Correction
Press the left key to decrease the amount of color in the image. Press the right key to increase the amount of color in the image. Keystone Correction " Adjusts image distortion caused by tilting the projector. Audio Volume "... - Page 20 Rear-Ceiling " When you select this function, the projector reverses and turns the image upside down at same time. You can project from behind a translucent screen with ceiling mounted projection. " You can select this function to fit your DVD aspect ratio type.
- Page 21 Lamp Lamp Warning " Choose this function to show or hide the warning message when the lamp changing warning message is displayed. Lamp Reset " Reset the lamp setting only when the lamp changing is done. Exit Menu Exit Menu "...
-
Page 22: Appendices
Ensure all the cables and power connections are correctly and securely connected " as described in the “Installation” section. If the projector is plugged into a power strip, make sure the power strip is turned on. " Ensure the pins of connectors are not crooked or broken. - Page 23 Check and reconfigure the display mode of your graphic card to make it compatible " with the product. Problem: Image is out of focus Adjust the Focus Ring on the projector lens. " Make sure the projection screen is between the required distance (1.2m - 11m) from the "...
- Page 24 English Problem: The screen is outstretched when displaying 16:9 DVD The projector itself will automatically detect 16:9 DVD and adjust the aspect ratio by digitization to full screen with 4:3 default setting. If the projection display is still outstretched, you will also need to adjust the aspect ratio by referring to the following: Please select 4:3 aspect ratio type on your DVD player if you are playing a 16:9 DVD.
-
Page 25: Maintenance
Maintenance M Cleaning the Air Filter Cleaning Procedure: " 1. Turn off the power. 2. Remove the air filter cover. 3. Remove the air filter from the filter cover. 4. Clean the air filter with a vacuum cleaner. 5. Place the air filter back in position. Make sure the air filter is fully inserted. Do not clean the filter with water. -
Page 26: Changing The Lamp
English M Changing the lamp The projection display will detect the lamp life itself. It will show you a warning message when the lamp is used over working hours. When you see this message, change the lamp as soon as possible. Make sure the projection display has been cooled for at least 60 minutes before changing the lamp. - Page 27 English 4. Unscrew the 2 screws of the lamp module and pull out the lamp module by the handle. Lamp Handle Lamp Screws 5. Replace the new lamp module by the handle and tighten the screws. Lamp Handle 6. Place the lamp cover back in position and lock the 2 screws. 7.
-
Page 28: Specifications
English Specifications LCD panel Lamp Number of Pixels Displayable Color Projection Lens Image Size Projection Distance Computer Compatibility Video Compatibility H. Frequency V. Frequency Multimedia Audio Power Supply I/O Connectors Weight Dimensions (W x H x D) Environmental Safety Regulation - active matrix TFT color LCD - 0.9”... -
Page 29: Compatibility Modes
Compatibility Modes Mode Resolution & & & & & & & & & & " 3 " 3 " 6 " 9 *: Compression H.Frequency V.Frequency (Hz) (kHz) English...
