27X Varifocal Zoom Module Camera w/RS-485
This camera is similar to a c-mount type camera except that the lens is built-in (no
need to purchase separately). It comes with a powerful 27X zoom 3.2 to 86.4mm
varifocal lens. The focus and zoom can be controlled via buttons on the back (see
additional photos) or via RS-485 Pelco-D protocol. The built-in On Screen Display
(OSD) menu lets you adjust the backlight compensation, focus, zoom, and camera
id. It can be used indoors, or outdoors in a housing.
Product Features
•
Built-in 3.9 to 85.8mm Varifocal Lens
•
Day / Night
•
On Screen Display
•
RS-485 control
Specifications
•
1/4" Sony Day/Night CCD
•
480 lines Resolution
•
3.2 to 86.4mm Lens
•
0.1 Lux (Day/Color), 0.01 Lux (Night/BW)
•
Pelco-D protocol
•
SN Ratio: > 48dB (AGC off)
•
Auto White Balance
•
Auto Gain Control
•
On/Off Switchable Electronic Shutter
•
On/Off Switchable Back Light Compensation
•
Power: 12VDC
•
BNC Connection
•
Operation Temp: -10°C - 50°C (14°F - 122°F)
•
Dimensions (WxHxL):58mm x 58mm x 103mm
Model: CM27X
