TY96 and TY97 VHF Radio
Operating Manual
01239-00-AA
18 February 2016
Trig Avionics Limited
Heriot Watt Research Park
Riccarton, Edinburgh
EH14 4AP
Scotland, UK
© Copyright 2016
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the TY96 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for trig TY96

Summary of Contents for trig TY96

  • Page 1 TY96 and TY97 VHF Radio Operating Manual 01239-00-AA 18 February 2016 Trig Avionics Limited Heriot Watt Research Park Riccarton, Edinburgh EH14 4AP Scotland, UK © Copyright 2016 Trig Avionics Limited Tel: +44 (0)131 449 8810 support@trig-avionics.com Heriot Watt Research Park Fax: +44 (0)131 449 8811 www.trig-avionics.com...
  • Page 3 Front Panel Display The display shows the primary and standby frequencies and a series of icons to indicate the operating mode of the radio. The primary frequency is on the left and the standby frequency is on the right half of the screen. The icon shows that the radio is transmitting.
  • Page 4 Pressing the end of the small knob changes the channel spacing that the small knob operates through. If the radio is configured for 8.33 kHz operation, the steps toggle between 8.33 kHz channels and 25 kHz channels. If the radio is configured only for 25 kHz operation, the steps toggle between 25 kHz and 50 kHz channels.
  • Page 5 8.33 kHz channels allows quicker turning Intercom Function of 25 kHz and 50 kHz steps. The TY96/TY97 radio has a built in intercom which can be installed as General Low Temperature Operation permanently engaged or selected via a switch. The intercom is voice activated and the audio is routed through to both of the headsets.
  • Page 6 Flip-Flop button puts the currently selected result into the active frequency To add a new database entry, select ADD NEW, and then press MEM again. Use the large knob to move the highlighted cursor, and use the small knob to instead, and returns to the normal operating screen.
