19.2V 3/8 in. CORDLESS DRILL-DRIVER – MODEL NUMBER 315.116890
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your DRILL-DRIVER or when ordering repair parts.
2
3
1
7
KEY
PART
NO.
NUMBER
1
6612001
2
670743001
3
940045280
4
940114217
5
130279005
6
140107001
7
6782045
6
PARTS LIST
DESCRIPTION
SCREW (SPECIAL) ..........................................................................................1
CHUCK ............................................................................................................1
DATA LABEL ....................................................................................................1
LOGO LABEL ..................................................................................................1
BATTERY PACK (Item No. 911375) .................................................................1
CHARGER .......................................................................................................1
DOUBLE ENDED BIT (#2 PHILLIPS HEAD & #6 SLOTTED) ...........................1
5
2
4
QTY.
