OPTI-UPS Line Interactive UPS Series PS1000B-RM Specifications

Power Series
For servers and networking environment
PS800B / PS1000B / PS1000B-RM / PS1500B / PS1500B-RM /
PS2200B / PS2200B-RM / PS3000B / PS3000B-RM / PS500C /
PS700C / PS1000C / PS1250C / PS1500C / PS2000C / PS3000C
PS800B / PS1000B / PS1500B / PS2200B / PS3000B
The PSB Series are the only line interactive pure sinewave UPS designed to meet everyone's needs. Our full line
covers every possible application demand. There are five tower models, from PS800B to PS3000B, and four
rack-mount models, from PS1000B-RM to PS3000B-RM.
Every PSB model utilizes digital line interactive technology that incorporates AVR.
AVR: (Automatic Voltage Regulator) Stabilizes all currents from over and under voltages, so that only the most clean
and safe currents feed into your equipment.
Every single model is equipped with our full version of OPTI-SAFE Xtreme, UPS control software.
Sine wave: Represents energy entirely concentrated at a single frequency. The more concentrated the energy is the
cleaner and safer the current will be. Fluctuations in energy called sags, brownouts and spikes, are harmful to
machines and systems.
Features
* Pure sine wave
* LCD display panel
* Software controlled outlets to switch power on/off (PS1000~3000B)
* Higher efficiency
* 4 hours battery recharge time
* 1050 Joules surge energy rating
* Up to 8 battery backup outlets
* RS232 or USB (optional) connectivity
* Cold start from battery
* Smart power management software

Front Panel

PS800B
B
A
C
Normal
D
Battery
A) Test, Silence
B) On/Off
C) Normal
D) Battery
Details
Optional
5-30A
PS1000B / PS1500B / PS2200B /PS3000B
ON/TEST
A
OFF
B
SELECT
C
A) On, Test
B) Off
C) Select
High capacity UPS like PS2200B or PS3000B when working with loads close to
their maximum capacity, would draw high current from the AC source outlets. This is
why these UPS models are equipped with high current power plugs NEMA L5-30P.
Assuming that the user might not have such socket available OPTI-UPS bundles
the NEMA L5-30R receptacles with PS2200B and PS3000B products.
21.
* PS3000B
Backup Time (Typical)
PS800B 1PC+1LCD 26 mins
PS1000B 1PC+1LCD 43 mins
PS1500B
1PC+1LCD 80 mins
PS2200B 1PC+1LCD 240 mins
PS3000B 1PC+1LCD 245 mins
