OPTI-UPS Reliable Series RS1200 Specifications

Reliable Series
For better equipment protection
RS650 / RS1200 / RS650-RM / RS1200-RM
RS650 / RS1200

Features

* Wide input range (220V±25%)
* Cold start available
* Automatic battery charging in UPS off mode
* Surge protection
* Self-test on startup
* Strong generator compatibility, full protection
against over voltage / low voltage

Specifications

Model Name
VA Rating
Real Power Rating
On-battery Output Waveform

INPUT

Phase
Voltage
Frequency

OUTPUT

Voltage
Frequency
Transfer
Socket

BATTERY

Quantity
Recharge
Backup

GENERAL

Front Panel Display
Surge Protection
Communication
Noise
Temperature
Humidity
Dimension (mm)
(Physical/Packing)
* See VS1000C on page 6

Rear Panel

RS650 / 120V
RJ45/11
USB
Output
Input
Fuse
RS650
650VA
390W
110V / 120V / 220V / 230V / 240V ± 25%*
110V / 120V /220V /230V /240V ± 10%*
50 / 60Hz ±1% On battery
NEMA 5-15R, IEC 320 C13
12V / 7AH x 1
up to 90% Capacity in 8 Hours
10~20 Minutes, Depending on Load and Model
LED or LCD (Optional)
RJ11 & RJ45 for Modem and LAN
RS232 or USB (Optional)
20~90% (Non-condensing)
340 x 95 x 165 / 375 x 145 x 230
RS650 / 230V RS1200 / 120V
RJ45/11
USB
Output
Fuse
Input
9.
* RS650 / RS1200 (LCD/ LED Display)
* Strong EMI filtering
* Software monitoring feature (RS232 & USB)
* Battery is replaceable without power supply interruption
RS1200
1200VA
720W
Step Wave
Single Phase + N
50 / 60Hz ± 10%
6-10 ms (typical)
12V / 7AH x 2
＜ 45db (1 Meter)
o
0~40 C
340 x 125 x 220 / 460 x 180 x 295
RS1200 / 230V
USB
RJ45/11
Output
Fuse
Input
RJ45/11
Output
USB
Fuse
Input
