Summary of Contents for Oppo OPPO DV-970HD
-
Page 1: Dvd Player
DVD PLAYER DV-970HD USER MANUAL READ CAREFULLY BEFORE OPERATION... -
Page 3: Table Of Contents
Table of Contents Table of Contents ... 1 Important Information ... 1 Important Safety Instructions ... 1 Cautions... 2 FCC Statement ... 2 Copyright Protection ... 3 Compatible Disc Types ... 3 INSTALLATION ... 4 Front Panel Controls ... 4 Front Panel Display Window ... - Page 4 Speaker Setup Page ... 28 Audio Setup Page... 30 Video Setup Page... 32 Preference Page... 32 REFERENCES... 34 Useful Notes... 34 Troubleshooting ... 34 Specifications ... 35 Language Code List ... 36 LIMITED WARRANTY ... 37 OPPO Digital, Inc. Limited One Year Warranty... 37...
-
Page 5: Table Of Contents
Important Information CAUTION: TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE THE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. -
Page 6: Cautions
I M P O R T A N T I N F O R M A T I O N Cautions • Please disconnect the power plug from the wall outlet if you are not going to use the player for a long time. -
Page 7: Copyright Protection
I M P O R T A N T I N F O R M A T I O N Any unauthorized changes or modifications to this equipment would void the user’s authority to operate this device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 8: Installation
INSTALLATION Front Panel Controls 1. POWER Button 4. PLAY/PAUSE Button 7. Flash Memory Card Reader Front Panel Display Window 1. DVD Disc 4. Chapter or Track 7. Pause Rear Panel Connectors 2. Disc Tray 5. STOP Button 8. USB Jack 2. -
Page 9: Remote Control
DVD title menu 8. ARROW Buttons – Navigate menu selection 9. SELECT Button – Confirm menu selection 10. SETUP Button – Enter the DVD player setup menu 11. SUBTITLE Button – Change subtitle language / Switch picture display mode 12. AUDIO Button –... -
Page 10: Battery Installation
I N S T A L L A T I O N Battery Installation 1. Remove the battery compartment cover Using the Remote Control When using the remote control, the front window of the remote control should be pointed to the infrared sensor on the front panel within an angle of ±30°... -
Page 11: Connection To A Tv
HDMI Connection • If your TV has an HDMI input, you can use the included HDMI cable to connect the DVD player to the TV. This is the most preferred connection method since it delivers both video and audio in pure digital format via a single cable. -
Page 12: Other Connection Options
Video Connection Depending on the input available on your TV, select one of the following methods to connect the video output of the DVD player to your TV. The video connections are listed in descending order of video quality. BEST If the TV has a DVI input, using an HDMI-DVI Adapter Cable to connect the HDMI output of the DVD player to the TV will result the best pure digital video quality. -
Page 13: Connection To An Audio System
TV. Make sure the audio cables are connected to the same input terminal group on the TV as the video signals. • Please set the down-mix mode of the DVD player to “Stereo” or “V. Surround”. (Refer to page 28 for details.) Connection to an Audio System Connection to a Stereo or Surround Audio System •... -
Page 14: Connection To A Receiver/Amplifier With Dolby Digital Or Dts Decoder
I N S T A L L A T I O N Connection to a Receiver/Amplifier with Dolby Digital or DTS Decoder • Please set the SPDIF Output of the DVD player to “Raw”. (Refer to page 30 for details.) NOTES •... -
Page 15: Connection To A Receiver/Amplifier With 5.1Ch Audio Input
I N S T A L L A T I O N Connection to a Receiver/Amplifier with 5.1ch Audio Input • Please set the audio down-mix mode of the DVD player to “5.1ch”. (Refer to page 28 for details.) •... -
Page 16: Basic Operations
This is to minimize possible burn-in on plasma or CRT screens caused by displaying a static image for a prolonged period of time. 1． Press the POWER button to turn on the DVD player. 2． Press the OPEN/CLOSE (EJECT) button to eject the disc tray. -
Page 17: Dvd Menu Playback
2. The VOL +/- buttons on the DVD remote control is provided as an alternative way of controlling the audio volume. It is recommended that you use this control to make the audio volume from the DVD player the same as from other sources, such as TV programs or a VCR. -
Page 18: Osd (On-Screen Display)
B A S I C O P E R A T I O N S OSD (On-Screen Display) Press the OSD button on the remote control to show disc information and operation function hints on the TV screen. The OSD display includes the followings: DVD disc: Audio Language/Channel Selection To select the audio language or channel, press the AUDIO button on the remote control... -
Page 19: Angle Selection
This function is available only when the discs are recorded with multiple angles. • The angle mark on the screen can be turned off using the setup menu of the DVD player. Zooming the Displayed Frame The feature zooms in or out the displayed frame. -
Page 20: Advanced Operations
2. Turn on the TV. Adjust the TV to use the proper input (HDMI, DVI or Component). 3. Turn on the DVD player with no disc in its tray, or if the DVD player is already on, make sure that playback is completely stopped. -
Page 21: Fast Playback
O P E R A T I O N S • In case you are not able to get a picture using the HDMI output, please connect the DVD player to the TV using either the composite video or S-Video outputs, and then use the setup menu to adjust the DVD player settings. -
Page 22: Repeat The Selected Section
A D V A N C E D O P E R A T I O N S CD disc: SACD disc: Repeat the Selected Section To repeatedly play a specified section, please follow these steps: 1. During normal playback, press the A-B button on the remote at the desired beginning point (Point A) for the repeat play. -
Page 23: Playback From A Specific Location
A D V A N C E D O P E R A T I O N S • Press the +10 button and then the NUMBER buttons 0-9 to directly select the corresponding chapter/track if the chapter/track number is above 10 (including 10). •... -
Page 24: Memory
3. When the next time the disc with a memorized playing position is played back, the DVD player will recognize the saved playing position. When prompted, you may press the STOP button to cancel resuming and start playback from the beginning. If you press a button other than STOP, or do not press any button at all, playback will resume from the saved playing position. -
Page 25: Virtual Keyboard
A D V A N C E D O P E R A T I O N S 1. Press the AUDIO ONLY button on the remote control to turn off video and enter Audio-Only mode. 2. Press the AUDIO ONLY button again to resume video and cancel Audio-Only mode. NOTES Audio-Only mode is cancelled if the unit is switched to STANDBY. -
Page 26: Playing Divx, Digital Audio And Picture Files
A D V A N C E D O P E R A T I O N S 1. Press the INFO button on the remote control. The TV screen displays the following: 2. Press the UP/DOWN ARROW buttons to select an item in the disc information display. If the selected item allows modification, press the SELECT button to make selections or modifications. -
Page 27: Digital Picture Play Operations
A D V A N C E D O P E R A T I O N S 1. Elapsed play time of the current digital audio file 2. Total play time of the current digital audio file 3. The audio bit rate 4. -
Page 28: Digital Music Play Operations
Use of USB Equipment and 4-in-1 Card Reader This DVD player is equipped with a USB port and a 4-in-1 flash memory card reader, which supports Secure Digital (SD), Multi-Media Card (MMC), Memory Stick (MS) and SmartMedia (SM). You may use the USB port and the card reader to play DivX/XviD, digital audio and digital picture files stored on compatible USB drives and flash memory cards. -
Page 29: Playing Flash Memory Card
Use the DVD/CARD button or the ARROW buttons to highlight the “Card Reader” item of the device selection menu, and then press the SELECT or PLAY/PAUSE button to confirm. The DVD player will start reading the files stored in the flash memory card. After correctly reading the files, a disc navigation menu will appear. -
Page 30: Setup Menu Options
SETUP MENU OPTIONS The SETUP menu of the DVD player presents many setup and configuration options. For most users, the default configuration works well enough and there is no need to change the settings. However if you need to configure the DVD player to perfectly match your home theater settings and watching preference, please follow these instructions. -
Page 31: General Setup Page
S E T U P M E N U O P T I O N S General Setup Page 1. TV Display: To set the aspect ratio of the player’s output image to match your TV. The options are : •... -
Page 32: Speaker Setup Page
S E T U P M E N U O P T I O N S 7. DivX VOD: Divx Video on Demand – To display the device registration code for DivX Video on Demand service. To learn more, visit Speaker Setup Page 1. - Page 33 S E T U P M E N U O P T I O N S • Large – Choose if the rear surround speakers are large. Bass frequencies are passed to the rear speakers. • Small – Choose if the rear surround speakers are small. Bass frequencies are not passed to the rear speakers to reduce possible distortion.
-
Page 34: Audio Setup Page
S E T U P M E N U O P T I O N S • Press the LEFT/RIGHT ARROW buttons to select the channel to be adjusted. • Press the UP/DOWN ARROW buttons to raise or lower the volume of the selected channel. •... - Page 35 Down-mix setting in the “Speaker Setup Page” will affect whether and how multi-channel audio content will be down-mixed to stereo. When this option is selected, compressed audio bit streams will decoded by the DVD player. • SPDIF – Digital audio output via HDMI will be the same as the SPDIF (digital coaxial/optical audio) output.
-
Page 36: Video Setup Page
7. Color Space: To select the color space for the HDMI output. The available options are: • Auto – Allows the DVD player to automatically select the best color space based on capability information collected from the TV display. This is the preferred selection. - Page 37 S E T U P M E N U O P T I O N S • Auto – No system conversion is performed. The output video system is the same as that encoded on the disc. Requires TV that supports multi-systems. •...
-
Page 38: References
REFERENCES Useful Notes • In order to prolong the service life of your DVD player, it is recommended to wait at least 30 seconds before you turn it on again after switching it off. • Remove disc and turn off power after operation. -
Page 39: Specifications
R E F E R E N C E S Specifications Designs and specifications are subject to change without notice. Disc Types* DVD-Video, DVD-Audio, SACD, CD, HDCD, Kodak Picture CD DivX (DivX Certified Home Theater Profile Parameters, V2.2. Covers DivX 3.11 – 5.1) CD-R/RW, DVD±R/RW, DVD+R DL Output... -
Page 40: Language Code List
R E F E R E N C E S Language Code List Code Language Name 6565 Afar 6566 Abkhazian 6570 Afrikaans 6577 Ameharic 6582 Arabic 6583 Assamese 6588 Aymara 6590 Azerbaijani 6665 Bashkir 6669 Byelorussian 6671 Bulgarian 6672 Bihari 6678 Bengali, Bangla 6679... -
Page 41: Limited Warranty
This warranty does not apply to products purchased or shipped outside of the U.S.A. and Canada. OPPO Digital, Inc. may at its sole discretion, refuse to honor the warranty of any such unauthorized product that may be presented for service. - Page 42 Send the package postpaid and insured to the OPPO service center to obtain warranty service. Thank you for choosing OPPO. Your satisfaction is our highest priority. 5194138 V1.03 OPPO Digital, Inc. 453 Ravendale Dr. Suite D Mountain View, CA 94043, U.S.A. www.oppodigital.com service@oppodigital.com...
