AV Receiver
HT-R490
Instruction Manual
Thank you for purchasing the Onkyo AV Receiver.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new AV Receiver. Please retain
this manual for future reference.
Contents
Before using
Important Safeguards ....................................... 2
Precautions ........................................................ 3
Features ............................................................. 4
Supplied accessories ......................................... 4
Before using this unit ....................................... 5
Facilities and connections
Front panel facilities ......................................... 6
Remote controller ............................................. 9
Rear panel facilities ........................................ 10
Positioning speakers ....................................... 16
Connecting speakers ....................................... 17
Connecting antennas ....................................... 18
Connecting the power ..................................... 20
Enjoying music or videos
Speaker Setup ................................................. 21
Selecting a sound source ................................ 22
Listening to Radio Broadcasts ........................ 24
To enjoy Surround mode ................................ 26
Recording a source ......................................... 29
Remote controller
Using remote controller .................................. 30
Pre-programming remote controller .................. 32
Appendix
Troubleshooting guide .................................... 34
Specifications ........................... back cover page

Advertisement

Table of Contents
loading

Related Manuals for Onkyo HT-R490

Summary of Contents for Onkyo HT-R490

  • Page 1: Table Of Contents

    AV Receiver HT-R490 Instruction Manual Thank you for purchasing the Onkyo AV Receiver. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new AV Receiver.

  • Page 2: Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 3: Precautions

    3. AC Fuse The fuse is located inside the chassis and is not user-serviceable. If power does not come on, contact your Onkyo authorized service station. 4. Care From time to time you should wipe the front and rear panels and the cabinet with a soft cloth.

  • Page 4: Features

    • Vibration-resistant cover • Brushed aluminum front panel • Powerful preprogrammed remote Supplied accessories Check that the following accessories are supplied with the HT-R490. AM loop antenna × 1 FM indoor antenna × 1 Remote controller × 1 Batteries (AA, R6 or UM-3) × 2 (RC-446M) * Manufactured under license from Dolby Laboratories.

  • Page 5: Before Using This Unit

    • Make sure the audio rack doors do not have colored glass. Placing the unit behind such doors may prevent proper remote controller operation. • If there is any obstacle between the remote controller and the remote control sensor, the remote controller will not operate. HT-R490 Approx. 5 meters (16 feet)

  • Page 6: Front Panel Facilities

    Front panel facilities Here is an explanation of the controls and displays on the front panel of the HT-R490. STANDBY/ON STANDBY POWER SPEAKERS AUDIO SELECTOR SP SEL DISPLAY SP SEL SW MODE DIGITAL INPUT FM MODE CLEAR VIDEO VIDEO SW MODE...
  • Page 7 • Turning on the HT-R490 may cause a momentary power surge that might interfere with other electrical equipment on the same circuit. If this is a problem, plug the HT-R490 into a different electrical circuit. STANDBY indicator Lights when the HT-R490 is in the standby state and flashes when a signal is received from the remote controller.
  • Page 8 Press to select the subwoofer mode. DIGITAL INPUT button When digital components are connected to the DIGITAL INPUT jacks of the HT-R490, use this button to assign the DIGITAL INPUT jacks to them according to their forms of connection. FM MODE button Press to switch the reception mode between stereo and monaural.

  • Page 9: Remote Controller

    For setting the sleep time. This button is provided only on the remote controller (refer to page 23). STANDBY/ON button Turns on the HT-R490 or put it in standby. INPUT SELECTOR buttons For selecting the input source. SUR MODE button Press to select the surround mode.

  • Page 10: Rear Panel Facilities

    Rear panel facilities Here is an explanation of the terminals found on the rear of the HT-R490 and how they are used. Before connecting your audio and video components, be sure to read this section carefully and then proceed to the explanations on how to connect each individual component (refer to page 12).
  • Page 11 • For remote control operation, the audio connection cables must also be connected. • If the connected component has two z connectors, you can use either one to connect to the HT-R490. The other one can be used to daisy chain with another component. AC OUTLETS...

  • Page 12: Example Of How To Connect Your Equipment

    Example of how to connect your equipment Here is explanation of how to connect the main components to the HT-R490 in the standard manner. There are many ways that any one component can be connected, and it is up to you to decide which method best fits your situation.
  • Page 13 Connecting a CD player Using an RCA-type audio connection cable, connect the output terminal on the CD player to the CD L/R jacks on the HT-R490. Make sure that you properly connect the left channel to the L jack and the right channel to the R jack.
  • Page 14 Using an RCA-type audio connection cable, connect the audio output terminal on the video cassette recorder to the same VIDEO 2 IN L/R jacks on the HT-R490 and audio input terminal to the VIDEO 2 OUT L/R jacks. Make sure that you properly connect the left channel to the L jack and the right channel to the R jack.
  • Page 15 Example of how to connect your equipment Example of video equipment connections DVD player or LD player (DVD) AUDIO VIDEO DIGITAL S VIDEO COAXIAL ANTENNA TAPE VIDEO 1 VIDEO 2 S VIDEO AUDIO VIDEO Satellite tuner or TV (VIDEO 1) TV monitor or Projector (MONITOR OUT) S VIDEO...

  • Page 16: Positioning Speakers

    Positioning speakers This unit has two sets of speaker system terminals (for SPEAKERS A and SPEAKERS B). Before connecting the speakers, place them correctly by consulting the instruction manuals that came with them. For surround playback, the configuration and placement of your speakers are very important.

  • Page 17: Connecting Speakers

    Connecting speakers Connecting speakers After installing the speakers, connect them to the HT-R490. CAUTION: SPEAKER IMPEDANCE 6 Ω min. per each speaker terminal. Preparation of speaker cords 1. Strip away 15 mm (5/8 inch) of wire insulation. 2. Twist wire ends very tight.

  • Page 18: Connecting Antennas

    Connecting antennas To the use the tuner of HT-R490, it is necessary to prepare the supplied FM and AM antennas. • Adjustment and placement of the FM and AM antennas for better reception must be done while listening to a station broadcast.
  • Page 19 FM and TV (or VCR) signals can interfere with each other. If you must use a common FM/TV (or VCR) antenna, use a directional linkage type splitter. To HT-R490 Connecting an AM outdoor antenna An outdoor antenna will be more effective if it is stretched horizontally above a window or outside.

  • Page 20: Connecting The Power

    Notes: • The function of turning on the HT-R490 is not available if its POWER switch is set to the off position (— OFF) or the source components is not connected properly. When controlling the...

  • Page 21: Speaker Setup

    CLEAR TAPE TEST TONE BASS TREBLE HT-R490 AV RECEIVER Note: When the subwoofer mode is set to MODE 2 and audio is reproduced in the STEREO mode, the subwoofer may not output audio from certain sources (2 channel-Dolby Digital/DTS source etc.).

  • Page 22: Selecting A Sound Source

    VOLUME RETURN SETUP TEST TONE CH SEL LEVEL TEST TONE HT-R490 AV RECEIVER CH SEL select “MULTI CH”. CHANNEL INPUT port and start playing the desired media. remote controller to select an individual speaker. Then press the LEVEL 5/∞ button to adjust the output level as desired.
  • Page 23 The MUTING indicator will flash and the sound from the speakers will be switched off by the receiver’s audio muting circuits. MUTING Press the MUTING button again to turn the sound back on. Note: The mute function will be cancelled if you turn off the HT-R490.

  • Page 24: Listening To Radio Broadcasts

    RETURN SETUP TEST TONE CH SEL TREBLE HT-R490 AV RECEIVER Tuning into a radio station panel, tune into the station you desire. When you tune into a radio station, TUNED indicator appears in the display. If you tune into an FM station in stereo, then FM STEREO indicator lights up.
  • Page 25 Listening to Radio Broadcasts Presetting a radio station By storing (presetting) frequently received radio stations, they can be received automatically by pressing the PRESET ™/£ button on the front panel or TUNER PRESET 5/∞ buttons on the remote controller. Up to a total of 30 FM and AM stations can be preset. 1.

  • Page 26: To Enjoy Surround Mode

    DTS source, a short noise may be heard. This is not a malfunction. • The DTS indicator on the HT-R490 lights up while it plays the DTS source. When playback concludes and the DTS signal transmission stops, the HT-R490 remains in DTS mode and the DTS indicator remains lit.
  • Page 27 LISTENING MODE DIMMER FM MODE MEMORY TUNING PRESET CLEAR TAPE BASS TREBLE HT-R490 AV RECEIVER PCM* Dolby Digital* CD, Audio DVD, Video DVD, LD, Video DVD Digital satellite broadcast You can adjust the level of each speaker. 1. Press the CH SEL button on the remote controller to select a speaker.
  • Page 28 • The degree of the Late Night effect is already programmed into the source materials. Some materials may produce only small or no effects. Selecting Onkyo’s surround modes 1. Press an input selector button to select the desired sound source.

  • Page 29: Recording A Source

    • You cannot record the surround effects. MASTER VOLUME BASS TREBLE HT-R490 AV RECEIVER 2, 5 FRONT VIDEO 1 Video camera...

  • Page 30: Using Remote Controller

    DVD player with the remote controller provided with the HT-R490. Controlling an Onkyo CD player The z connector of the Onkyo compact disc player must be connected to the HT-R490 (refer to page 11). 1. Press the CD MODE button.
  • Page 31 02 (refer to page 32). When the DVD player is connected with z connecter of the HT-R490, change the code to 01 and point the remote controller toward the HT-R490 (refer to page 32). 1. Press the DVD MODE button.

  • Page 32: Pre-Programming Remote Controller

    RC-446M, the code is set to 03. If it does not operate properly, enter 02. No. 01: This code is for Onkyo DVD players that have an z connector that you are connecting to the HT-R490 with an z cable. You will then operate the DVD player by pointing the remote controller at the remote control sensor on the HT-R490.
  • Page 33 04, 09, 13 MARANTZ — MARTA — MEMOREX — MINOLTA — MITSUBISHI 04, 23 MULTITECH — — OLYMPIC — ONKYO — PANASONIC 16-18, 24 PENTAX — PHILCO 04, 09, 13 PHILIPS PIONEER 10, 18, 25 PORTLAND 04, 26 PRIMESTAR — PROSCAN...

  • Page 34: Troubleshooting Guide

    Troubleshooting guide If a problem occurs while you are using the remote controller, first try to operate the controls on the front panel of the HT-R490 to make sure that it is not due to a malfunction (or worn out batteries) in the remote controller.
  • Page 35 *To reset the surround mode and other settings to the factory default settings, hold down the VIDEO 1 button with the HT-R490 turned on and then press the SPEAKERS A button. “CLEAR” appears in the front display and the HT-R490 enters the standby state.

  • Page 36: Specifications
