DVD Player

DV-S535
Instruction Manual
Thank you for purchasing the ONKYO DVD Player.
Please read this manual thoroughly before making
connections and turning on the power.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new DVD Player.
Please retain this manual for future reference.
Contents
Before Using Your DVD Player
Getting Started
Basic Playback
Advanced Playback
Function Setup
Others
2

Advertisement

Table of Contents
loading

Related Manuals for Onkyo DV-S535

Summary of Contents for Onkyo DV-S535

  • Page 1: Dvd Player

    DVD Player DV-S535 Instruction Manual Thank you for purchasing the ONKYO DVD Player. Please read this manual thoroughly before making connections and turning on the power. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new DVD Player.

  • Page 2: Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 3: For Canadian Model

    Precautions This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT.” So, to use this model properly, read this Instruction Manual carefully. In case of any trouble, please contact the store where you purchased the unit. To prevent being exposed to the laser beam, do not try to open the enclosure.
  • Page 4 1. Regional Restriction Codes (Region Number) Regional restriction codes are built into DVD players and DVD videos for each sales region. If the regional code of the DVD Player does not match one of the regional codes on the DVD video, playback is not possible.

  • Page 5: Table Of Contents

    Preparing the Remote Controller ... 7 Connecting to a TV ... 8 Connecting to an Amplifier (To Enjoy the Sound Advantage of the DVD Player) .. 9 Connecting the Power/Turning on the DVD Player ... 10 Notes on Discs ... 11 Basic Playback Playing DVD Videos/VIDEO CDs/Audio CDs ...

  • Page 6: Getting Started

    Full-Function Remote Control Supplied Supplied Accessories Make sure your box contains everything listed below. If any pieces are missing, contact your nearest ONKYO dealer. The number of accessories is indicated in brackets. SCART cable [1] “DTS” and “DTS Digital Surround” are trademarks of Digital Theater Systems, Inc.

  • Page 7: Preparing The Remote Controller

    Point the remote controller toward the remote control sensor. STANDBY indicator (as remote control reception indicator) The STANDBY indicator lights up each time the DVD Player receives a signal from the remote controller. For the other functions of this indicator, see page 10. Remote control sensor 30˚...

  • Page 8: Connecting To A Tv

    Before connecting • Refer also to the instruction manual of the TV. • When you connect the DVD Player to the TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections.

  • Page 9: Connecting To An Amplifier (To Enjoy The Sound Advantage Of The Dvd Player)

    (To Enjoy the Sound Advantage of the DVD Player) Although you can reproduce the DVD Player’s sound from the TV speakers with the connections on the opposite page, connecting with an amplifier and subwoofer provide you high quality dynamic sounds.

  • Page 10: Connecting The Power/Turning On The Dvd Player

    All your selections are set and the First Setup screen disappears. Notes • To turn off the DVD Player, press STANDBY/ON on the DVD Player, or POWER on the remote controller. The DVD Player enters standby mode. Be sure to set the volume to minimum before turning off the DVD Player for the next use to avoid sudden loud sound reproduction.

  • Page 11: Notes On Discs

    You can enjoy two playback variations depending on the type of disc. • VIDEO CD not equipped with PBC function (Version 1.1) Sound and movies can be played on this DVD Player in the same way as an audio CD.

  • Page 12: Basic Playback

    • When playing DVD videos or VIDEO CDs, turn on the TV and set the TV to the DVD Player’s input. • If the audio system is connected to the DVD Player, turn on the audio system and set it to the DVD Player’s input.
  • Page 13 • Do not move the DVD Player during playback. Doing so may damage the disc. • Use the r button on the remote controller or DVD Player to open and close the disc tray. Do not touch the disc tray while it is moving.
  • Page 14 Each time you press the same button, the playback speed alternates with the other as follows: To check the marks on the right while playing a CD, turn on the TV and set the TV to the DVD Player’s input. Note No sound is reproduced and no subtitles appear...
  • Page 15 D I G I T A L Does the amplifier have an MPEG2 decoder?* Select “MPEG2” or “ Is the DVD Player connected to an amplifier with a Dolby Pro Logic Surround decoder? Select “Dolby Pro Logic surround” or “...

  • Page 16: Locating A Specific Title/Chapter/Track/Location

    TV screen, follow those instructions. • If you display the title menu during playback and press TOP MENU again without selecting any title, the DVD Player usually resumes playback from the point where you first pressed TOP MENU.
  • Page 17 Press s. PLAY The DVD Player starts playback from the selected chapter in the selected title. Notes • To enter a number between 10 and 99, you can also use ten button) as follows: + 10 + 10 T i t l e Chapter •...

  • Page 18: Locating A Specific Title

    • When you set “Title Stop” to “Off” (see page 35), you can locate consecutive chapters in another title. If you go back to the preceding title by pressing q, the DVD Player locates the first chapter of the title. When “Title Stop” is set to “On,” you can locate consecutive chapters only within the current title.

  • Page 19: Advanced Playback

    (point A) you want to play repeatedly. A – Press A-B again at the end of the segment (point B). A – B The DVD Player automatically returns to point A and starts repeat playback of the selected segment (A-B). Press CLEAR. OPEN/ CLOSE...

  • Page 20: Playing In A Favorite Order

    You can program up to 28 selections into the memory (Memory playback). Setting Titles, Chapters, or Tracks in a Favorite Order The DVD Player automatically plays titles, chapters, or tracks in the order you program. Insert a disc and press MEMORY MEMORY while the disc is stopped.

  • Page 21: Playing In Random Order

    • Some discs may not permit random playback operation. • You cannot use the random playback function together with the memory playback function. • If you press w during random playback, the DVD Player goes to another title or track and continues random playback. Title : 3...

  • Page 22: Zooming A Picture

    Zooming a Picture You can magnify areas within a picture. Zooming a Picture and Shifting the Zoom Point You can zoom in on a picture. You can also shift the zoom point. Press ZOOM during normal, slow, ZOOM or still playback. If you press ZOOM repeatedly, the magnification level increases.

  • Page 23: Selecting The Camera Angle

    POWER DISPLAY DIMMER MENU ENTER RETURN AUDIO ANGLE SUBTITLE 1, 2 STOP PLAY DOWN REPEAT MEMORY CLEAR RANDOM CLEAR Press CLEAR. ) flashes in the DVD Player’s OPEN/ CLOSE SEARCH TOP MENU SETUP SUBTITLE ON/OFF PAUSE/STEP SLOW ZOOM...

  • Page 24: Turning On/Off Subtitles/Selecting The Subtitle Language

    Good evening! Subtitle : 1 ENG Off Notes • When you turn on the DVD Player or replace a disc, the DVD Player returns to the automatic setting in the setting menu (see pages 28 and 30). When you select a subtitle language which is not included on the disc, the DVD Player plays the prior language programmed on the disc.

  • Page 25: Selecting The Audio Language And Sound System As A Set

    • Some discs may have only one audio language and sound recording system set and you cannot change this selection. • When you turn on the DVD Player or replace a disc, the DVD Player returns to the automatic setting in the setting menu (see page 28).

  • Page 26: Using Information On The On-Screen Display And The Dvd Player's Display

    Checking the Total Number of the Titles/Tracks, Current Title/Chapter/Track, Remaining and Elapsed Time, etc. When the disc is inserted in the DVD Player The following information appears in the DVD Player’s display for about five seconds. DVD video* e.g. Total number of titles Press DISPLAY while the disc is stopped.
  • Page 27 Dimming the DVD Player’s Display Press DIMMER. To resume the original brightness, press the button again. Press DISPLAY during playback. DISPLAY Each time you press DISPLAY, the on-screen display on the TV screen changes as follows. DVD video e.g. Current title number...

  • Page 28: Function Setup

    Customizing the Function Settings When you insert a DVD Video, VIDEO CD, or audio CD, the various functions of the DVD Player will be set (reset) according to the setting menu. You can customize this setting menu according to your preference.
  • Page 29 Reference Table of the Setting Menu Category Symbol Menu item On-Screen Language Disc Menu Language Audio Language Subtitle Language TV Shape Black Level PAL/Auto* Audio Out Select Dynamic Range Control Karaoke Vocal Extended Audio Feature On-Screen Displays OSD Background Color Extended Subtitle Features Screen Saver Pause/Still...

  • Page 30: Subtitle Language Dvd

    Language” in the right column of this page. Note Some DVD videos may not include your pre-selected language. In this case, the DVD Player automatically displays disc menus consistent with the disc’s initial language setting. Audio Language Select an audio language from the following:...

  • Page 31: Black Level

    Select to play PAL discs. Connect a PAL TV to view pictures. Displays widescreen images with masking • Auto: The DVD Player automatically detects PAL bars above and below and NTSC video systems of discs. the picture. Connecting a multisystem TV (PAL/NTSC compatible) is needed to view pictures.

  • Page 32: Output Sound Conversion Table

    “Audio Out Select” –– the sound signal conversion method. This setting is related to the equipment connected to the DVD Player’s DIGITAL OUTPUT connectors/ ANALOG OUTPUT jacks (see pages 8 and 9). For details, see “Output Sound Conversion Table” below.
  • Page 33 The amplifier with a Dolby Digital decoder must be connected to the DVD Player. Extended Audio Feature Some DVD videos contain a narration track for visually impaired persons. The DVD player automatically plays the narration track by setting this item to “On.” • Off: The narration track is not played.

  • Page 34: Parental Lock

    Note DVD videos may or may not respond to the parental lock settings. This is not a defect in the DVD Player. Make sure this function works with your DVD videos. Note To know the factory setting for each item, see the on-screen illustration on the left.

  • Page 35: Pbc Vcd

    The DVD Player continues playback after playback of a title is complete. • On: The DVD Player stops playback after playback of a title is complete. PBC is the abbreviation for Playback Control (see “About VIDEO CDs” on page 11.) •...

  • Page 36: Table Of Languages

    Table of Languages Table of Languages and Their Abbreviations Abbreviation Language of the Language ––– No alternate language CHI (ZH) Chinese DUT (NL) Dutch ENG (EN) English FRE (FR) French GER (DE) German ITA (IT) Italian JPN (JA) Japanese KOR (KO) Korean MAY (MS) Malay SPA (ES) Spanish...

  • Page 37: Others

    • Switch off the main power, then switch it on again. If not recovered, disconnect the power cord, then connect it again. • Contact your nearest ONKYO service center. • Insert a disc. (Check that “DVD,” “VCD,” or “CD” is lit in the DVD Player’s display.) •...

  • Page 38: Specifications

    Specifications DVD Player Power supply Power consumption Weight External dimensions Signal system Regional restriction code Laser Frequency range (digital audio) Signal-to-noise ratio (digital audio) Audio dynamic range (digital audio) Harmonic distortion (digital audio) Wow and flutter Operating conditions Outputs Component video output...

  • Page 39: Index To Parts And Controls

    Index to Parts and Controls For operational instructions, see the page indicated in brackets [ ]. Rear panel COMPONENT VIDEO OUTPUT 1 COMPONENT VIDEO OUTPUT (Y/P 2 VIDEO OUTPUT S VIDEO connector [8] 3 VIDEO OUTPUT VIDEO connector [8] 4 ANALOG OUTPUT DIRECT L/R jacks [9] 5 ANALOG OUTPUT TV (ACOUSTIC CONTROL) L/R jacks [8]...
  • Page 40 Index to Parts and Controls Front panel STANDBY/ON POWER STANDBY 1 Remote control sensor [7] 2 Display [26, 27, 41] 3 DVD/VIDEO CD/CD disc tray [12] 4 CURSOR ( / / / )/ ENTER [10, 15, 28] 5 STANDBY indicator [7, 10] 6 STANDBY/ON button [10] 7 POWER switch [10] 8 DIMMER button [26, 27]...
  • Page 41 Display 1 Operating status indicator 2 Title/track number indicator [26, 27] 3 Chapter number indicator [26, 27] 4 Total playing time/remaining time/elapsed time indicators [26, 27] 5 MEMORY indicator [20] 6 Angle icon indicator [23] 7 Inserted disc indicator [12] 8 Multifunctional indicator (e.g.
  • Page 42 Index to Parts and Controls Remote controller POWER DISPLAY MENU ENTER RETURN AUDIO ANGLE STOP PLAY REPEAT MEMORY CLEAR REMOTE CONTROLLER 1 POWER button [10] 2 Number buttons [16] OPEN/ 3 MENU button [15, 16, 25] DIMMER CLOSE SEARCH 5 RETURN button [20, 22, 28] 6 AUDIO button [25] + 10 7 ANGLE button [23]...
  • Page 43 Memo...
  • Page 44 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8111 Fax: 072-833-5222 http://www.onkyo-intl.com ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.onkyo.net...
