Service Manual
DVD PLAYER
DV-SP406
Instruction Manual
Thank you for purchasing an Onkyo DVD Player.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new DVD Player.
Please retain this manual for future reference.
Contents
Overview .......................................... 2
Connections and Setting up ........ 15
Playback Operation....................... 24
Miscellaneous Information........... 33
E
n
Advertisement
Table of Contents
Related Manuals for Onkyo DV DV-SP406
Summary of Contents for Onkyo DV DV-SP406
-
Page 1: Dvd Player
DVD PLAYER DV-SP406 Instruction Manual Thank you for purchasing an Onkyo DVD Player. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new DVD Player. -
Page 2: Important Safety Instructions
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL. -
Page 3: Precautions
5. Never Touch this Unit with Wet Hands—Never handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer. 6. Handling Notes •... - Page 4 Precautions—Continued This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT”. So, to use this model properly, read this Instruction Manual carefully. In case of any trouble, please contact the store where you purchased the unit. To prevent being exposed to the laser beam, do not try to open the enclosure.
-
Page 5: Supplied Accessories
We, ONKYO EUROPE ELECTRONICS GmbH LIEGNITZERSTRASSE 6, 82194 GROEBENZELL, GERMANY declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3. GROEBENZELL, GERMANY... -
Page 6: Features
• Picture Zoom Function • Disc Navigator for Easy Browsing • Onscreen Display • Available in Black and Silver • Compatible with Onkyo Receiver Remote Control Supplied (On/Standby, Input Up/Down, Volume Up/ Down, Muting) *1 Manufactured under license from Dolby Digital Outputs *2 Manufactured under license under U.S. -
Page 7: Table Of Contents
Precautions ... 3 Supplied Accessories ... 5 Features ... 6 Types of Playable Discs ... 8 Before Using the DVD player ... 10 Installing the Batteries... 10 Using the Remote Controller... 10 Front & Rear Panels ... 11 Front Panel ... 11 Rear Panel ... -
Page 8: Types Of Playable Discs
DVD player. • The DVD player does not support disc types not listed. • The DVD player supports 8 cm and 12 cm discs. • Don’t use discs with an unusual shape, such as those shown below, because you may damage the DVD player. - Page 9 Types of Playable Discs—Continued Handling Discs • Never touch the underside of a disc. Always hold discs by the edge, as shown. Underside • Never attach adhesive tape or sticky labels to discs. Cleaning Discs • For best results, keep your discs clean. Fingerprints and dust can affect the sound and picture quality and should be removed as follows.
-
Page 10: Before Using The Dvd Player
• Flat batteries should be removed as soon as possible to prevent possible leakage and corrosion. Using the Remote Controller To use the remote controller, point it at the DVD player’s remote control sensor, as shown below. Remote control sensor DVD player 30˚... -
Page 11: Front & Rear Panels
For detailed information, refer to the pages in parentheses. ■ North American model ■ European & Other models ON/STANDBY button (20) Sets the DVD player to On or Standby. Disc Tray Discs are loaded here. ] (open/close) button (24) This button is used to open and close the disc tray. -
Page 12: Rear Panel
Front & Rear Panels—Continued Rear Panel ■ North American and Oceanian models ■ European model HDMI OUT This connector can be used to connect a TV, projec- tor, or AV receiver with an HDMI input. This con- nector outputs digital audio and digital video. COAXIAL DIGITAL AUDIO OUT This coaxial digital audio output can be connected to a coaxial digital audio input on a hi-fi... -
Page 13: Remote Control
MARKER button (26) Marks any point during playback. SEARCH button (26) Displays MARKER SEARCH menu. RECEIVER Controls the Onkyo AV receiver. ON/STANDBY button Turns the AV receiver on or off. INPUT +/– button Selects the input source on the AV receiver. - Page 14 Remote control—Continued [ ] (Stop) button (24, 27, 28, 30, 32) Stops playback. MENU button (24, 26) Access the disc’s title menu, if available. ENTER button (21–23, 26, 30, 32) Starts playback of the selected title, chapter, or track, and to confirm settings. RETURN button (32) Exits the onscreen setup.
-
Page 15: Connecting The Dvd Player
• Don’t connect the power cord until you’ve completed all audio and video connections. Optical Digital Outputs The DVD player’s optical digital connectors have a shut- ter-type cover that opens when an optical plug is inserted, and closes when it’s removed. Push the plug in all the way. -
Page 16: Audio And Video Connection
Connect the VIDEO OUT and AUDIO OUTPUT ANALOG L/R jacks to a set of A/V inputs on your TV. The DVD player’s audio/video jacks are colored coded (yellow for video, red for right channel, white for left channel). ■ North American and Oceanian models... - Page 17 RESOLUTION repeatedly unit the picture re- appears. Notes: • Settings changed while the DVD player is On are saved to memory when the DVD player is set to Standby. If the DVD player’s power cord is unplugged while the unit is still On, any changed settings will not be saved.
- Page 18 You can use any of the DVD player’s video outputs. Typ- ically, you must use the same type of video cable to con- nect your DVD player to your AV receiver as you do to connect your AV receiver to your TV.
-
Page 19: Hdmi Connection
- 480i, 480p, 720p, 1080i, 1080p. ■ Note for 1080p resolution The DVD player is able to provide a 1080p full HD image to most 1080p-capable TVs in the market today. However, there are some 1080p TVs available from cer- tain companies that are limited in the types of 1080p images that can be accepted. -
Page 20: Connecting The Power/Turning On The Dvd Player
Press ON/STANDBY on the DVD player or ON/STANDBY on the remote controller. The DVD Player turns on. • To put the DVD player in the standby mode, press ON/STANDBY on the DVD player, or ON/ STANDBY on the remote controller. Be sure to set the volume to minimum before putting the DVD player in the standby mode for the next use to avoid sudden loud sound reproduction. -
Page 21: Adjust The Settings
Adjust the settings TOP MENU MENU 2–6 ENTER RETURN SETUP AUDIO SUBTITLE ANGLE DISPLAY ZOOM RESOLUTION PROGRAM RANDOM A - B MARKER SEARCH REPEAT Display setup menu: SETUP SETUP Select a desired option on the first level: [ ENTER Move to second level: [ ENTER Select a desired option on the second level: [... - Page 22 Adjust the settings—Continued If you selected 16:9, you’ll need to define how you would like widescreen programs and films to be dis- played on your TV screen. [16:9 Widescreen]: Choose this option if you have a widescreen TV (16:9 aspect ratio). Depends on TV, the picture appears stretched when watching programs in 4:3 format.
-
Page 23: Displaying Disc Information
Displaying Disc Information RECEIVER ON/STANDBY OPEN/CLOSE ON/STANDBY INPUT CLEAR MUTING TOP MENU MENU 2, 3 ENTER SETUP RETURN AUDIO SUBTITLE ANGLE DISPLAY ZOOM RESOLUTION PROGRAM RANDOM A - B MARKER SEARCH REPEAT RC-725DV Press DISPLAY: DISPLAY DISPLAY Select a item: [ ENTER Adjust the Display menu set- tings: [... -
Page 24: Playing A Disc
Playing a Disc ON/STANDBY OPEN/CLOSE 1, 3 CLEAR TOP MENU ENTER SETUP Open the disc tray: CLOSE OPEN/CLOSE Insert a Disc: - Load a disc with the label side facing up, using the disc tray guide to align the disc. Close the disc tray: CLOSE OPEN/CLOSE... - Page 25 Playing a Disc—Continued Frame-by-Frame playback DivX Press [ ] repeatedly to play Frame-by-Frame playback. Fast forward or fast reverse DivX Press [ ] or [ ] to play fast forward or fast reverse during playback. You can change the various playback speed by pressing ] or [ ] repeatedly.
- Page 26 Playing a Disc—Continued Watching an enlarged video image DivX During playback or pause mode, press ZOOM repeatedly to select ZOOM zoom mode. You can move through the zoomed picture using [ ] buttons. ENTER CLEAR Press CLEAR to exit. Viewing the title menu Press MENU to display the disc’s title menu, if avail- able.
-
Page 27: Playing A Divx Movie File
Playing a DivX movie file RECEIVER ON/STANDBY OPEN/CLOSE ON/STANDBY 1, 3 INPUT CLEAR MUTING TOP MENU MENU ENTER SETUP RETURN AUDIO SUBTITLE ANGLE DISPLAY ZOOM RESOLUTION PROGRAM RANDOM A - B MARKER SEARCH REPEAT RC-725DV Open the disc tray: CLOSE OPEN/CLOSE Insert a disc: - Close the disc tray:... -
Page 28: Listening To Music Disc Or Files
Listening to Music Disc or files ON/STANDBY OPEN/CLOSE 1, 3 CLEAR MUTING TOP MENU ENTER SETUP AUDIO SUBTITLE ANGLE DISPLAY ZOOM RESOLUTION PROGRAM RANDOM Open the disc tray: CLOSE OPEN/CLOSE Insert a disc: - Close the disc tray: CLOSE OPEN/CLOSE Select a music from the menu: ], TOP MENU ENTER... - Page 29 MP3/WMA compatibility with this unit is limited as fol- lows: • Discs must be finalized. • The DVD player can only recognize the first session on multisession discs. • File extensions: “.mp3”, “.wma” • Sampling frequency: within 8 - 48 kHz (MP3), within 22 - 48kHz (WMA) •...
-
Page 30: Viewing Photo Files
Viewing photo files ON/STANDBY OPEN/CLOSE 1, 3 CLEAR MUTING TOP MENU ENTER SETUP AUDIO SUBTITLE ANGLE DISPLAY ZOOM RESOLUTION PROGRAM RANDOM MARKER SEARCH REPEAT RC-725DV Open the disc tray: CLOSE OPEN/CLOSE Insert a disc: - Close the disc tray: CLOSE OPEN/CLOSE Select a photo file on the menu: ], TOP MENU... - Page 31 JPEG file compatibility with this unit is limited as fol- lows: • Discs must be finalized. • The DVD player can only recognize the first session on multisession discs. • File extensions: “.jpg” • Photo size: Less than 5M recommended •...
-
Page 32: Using An Usb Flash Drive (European & Other Models Only)
• The USB function of this unit does not support all kinds of USB devices. • Digital camera and mobile phone are not supported. • Onkyo cannot be held responsible for damage to the USB device or for loss of data. Select a file: [ ], TOP MENU Play the file:... -
Page 33: Language Codes
Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Afar 6565 French Afrikaans 6570 Frisian Albanian 8381 Galician Ameharic 6577 Georgian Arabic 6582 German Armenian 7289 Greek Assamese... -
Page 34: Glossary
Glossary Analog audio An electrical signal that directly represents sound. Com- pare this to digital audio which can be an electrical signal, but is an indirect representation of sound. See also “Digital audio”. Aspect ratio The width of a TV screen relative to its height. Conven- tional TVs are 4:3 (in other words, the screen is almost square);... - Page 35 Glossary—Continued Progressive scan video All the lines that make up a video picture are updated in one pass (compared to interlace which takes two passes to update the whole picture). Regions (DVD-Video only) These associate discs and players with particular areas of the world.
-
Page 36: Troubleshooting
Troubleshooting If you have any trouble using the DVD player, look for a solution in this section. If you can’t resolve the issue yourself, contact your Onkyo dealer. Symptom No power. The power is on, but the unit does not work. - Page 37 5 seconds, and then plug it back in again. Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings caused by this unit’s malfunction.
-
Page 38: Specifications
Specifications Signal System Composite Video Output/Impedance S-Video Output/Impedance (not European model) Component Video Output/Impedance HDMI Out AV Connector (European model only) DVD Linear Sound Frequency response Audio CD S/N Ratio Audio Dynamic Range THD (Total Harmonic Distortion) Wow and Flutter Audio Output (Digital Optical) Audio Output/Impedance (Digital Coaxial) Audio Output/Impedance (Analog) - Page 39 Memo...
