Super Audio CD / CD Player
C-S5VL
Instruction Manual
Thank you for purchasing an Onkyo C-S5VL Super
Audio CD / CD Player.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new C-S5VL.
Please retain this manual for future reference.
Contents
Important Safety Instructions
Precations
F
e
a
u t
e r
s
Before Using This Product
Connecting to Other Devices
i D
c s
l P
y a
b
a
k c
Available Actions During Playback
Playback Methods
S
e
u t
p
Troubleshooting
S
p
e
i c
c i f
t a
o i
n
s
2
3
5
6
14
1
7
20
23
2
7
30
3
3
E
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-S5VL and is the answer not in the manual?

Questions and answers

Related Manuals for Onkyo C-S5VL

Summary of Contents for Onkyo C-S5VL

  • Page 1 Super Audio CD / CD Player C-S5VL Instruction Manual Thank you for purchasing an Onkyo C-S5VL Super Audio CD / CD Player. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new C-S5VL.

  • Page 2: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL.

  • Page 3: Precautions

    Never Touch this Unit with Wet Hands handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer. Handling Notes •...
  • Page 4 We, ONKYO EUROPE ELECTRONICS GmbH LIEGNITZERSTRASSE 6, 82194 GROEBENZELL, GERMANY declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3. GROEBENZELL, GERMANY ONKYO EUROPE ELECTRONICS GmbH K.

  • Page 5: Table Of Contents

    Features - Exclusive Onkyo VLSC Technology - High-Grade Wolfson 192 kHz / 24-Bit D/A Converter (WM8742) - Crystal Oscillator Thermal Regulation / Jitter Cleaner Circuitry to Stabilize Clock Frequency - Super Audio CD / Audio CD / CD-R / CD-RW /...

  • Page 6: Before Using This Product

    Before Using This Product This section describes things to check and important information to know before using this product. Check the Supplied Accessories After opening the package, make sure that all the supplied accessories are included. - Remote controller (RC-749C)[1] - AA (R6) batteries...

  • Page 7: Names Of Each Part

    Before Using This Product Names of Each Part Front Panel POWER button This button is used to turn the unit on and off. Disc tray Insert discs into this tray. (See p.17) button Open and close the disc tray. (See p.17) DIGITAL OUT indicator Illuminates when digital output is on.
  • Page 8 AUDIO OUTPUT ANALOG Connect the analog audio in terminal of an amplifier or similar to this terminal, using the supplied audio cable. jack Connect an Onkyo amplifier or similar with an terminal to this jack. —Continued AUDIO OUTPUT DIGITAL (OPTICAL/ COAXIAL) Connect an amplifier or similar with a digital in terminal to this terminal.
  • Page 9 Before Using This Product Display Displayed during playback. Displayed when playback is paused. FOLDER Displayed together with the folder number when a disc containing MP3 or WMA tracks is played. TRACK Displayed together with the track number when a disc is played. TOTAL Displayed when the total and remaining time of the track are shown.

  • Page 10: Remote Controller

    Before Using This Product Remote controller —Continued OPEN/CLOSE buttons Open and close the disc tray. (See p.17) DISPLAY button Use this button to change the information on the unit's display. (See p.22) DIMMER button Use this button to select one of the unit's four display-brightness levels.

  • Page 11: Using The Remote Controller

    - When operating the pre-main amplifer, point the remote controller at the amplifier's sensor. MUTING button When using this unit in combination with an Onkyo pre-main amplifer, temporarily lower the volume using the amplifier. Press it again to return to the previous volume. Notes - Some pre-main amplifers are not supported.

  • Page 12: Supported Cd Types

    Before Using This Product Supported CD Types Discs with the following logos on their labels can be played back. Disc Logo File Format/File Type Type Audio Super Audio CD-R Audio CD, MP3, WMA MP3, WMA CD-RW Audio CD, MP3, WMA MP3, WMA CD Extra Audio CD (Session1)

  • Page 13: Handling Discs

    Before Using This Product Limitations on Playback of WMA Files - WMA is an abbreviation of "Windows Media Audio." It is an audio compression ® technology developed by Microsoft Corporation. This unit supports WMA files encoded using Windows Media Player versions 7, 7.1, and 8. ®...

  • Page 14: Connecting To Other Devices

    Analog Connections Connect the supplied audio cable to the unit's AUDIO OUTPUT ANALOG terminal and the audio component's analog audio in terminal. C-S5VL Caution - Take care of the plug colors and the left and right channels when connecting audio.

  • Page 15: Connecting To Capable Components

    Connecting to Components You can control audiovisual amplifiers and receivers using the supplied remote controller by connecting Onkyo audiovisual amps and receivers with Use a cable to connect the unit's the amp or receiver's Use the supplied audio cable to connect the unit's AUDIO OUTPUT ANALOG terminal with the amp or receiver's analog audio in terminal.

  • Page 16: Connecting The Power Cord

    Connecting to Other Devices Connecting the Power Cord Caution - Before connecting the power cord, connect all the other components. - Turn off the unit before plugging or unplugging the power cord. Connect the other components. (See p.14) Make sure that the unit is turned off. Connect the supplied power cord to the unit's AC INLET.

  • Page 17: Disc Playback

    Disc Playback CD And Super Audio CD Playback Press the POWER button on the front of the unit to turn it on. Notes - When connecting an amplifier, you can reduce the impact on the speakers by first turning on the unit, then the amplifier. - To turn off the unit, press the POWER button again.

  • Page 18: Mp3 And Wma Playback

    Disc Playback —Continued Super Audio CD Hybrid Disc Playback You can select to play back the CD area or Super Audio CD area. Press the CD or SA-CD button on the player, or the SA-CD/CD button on the remote controller. The indicator of the selected area illuminates.
  • Page 19 Disc Playback —Continued Press the to close the disc tray. Notes Numbers are automatically assigned to the folders and tracks. ROOT Folder 002.MP3 File MP3 001 MP3 002 MP3 003 003.MP3 MP3 001 Press the FOLDER / buttons on the remote controller, or the buttons on the player to select the folder in which the track to...

  • Page 20: Available Actions During Playback

    Available Actions During Playback Stop Playback Press the button. Pause Playback Press the button. To resume playback, press the button or again. Fast Reverse/Fast Forward Press and hold the button on the remote controller. To perform this action from the front of the unit, press and hold the button.

  • Page 21: Play A Specific Location On A Track

    Available Actions During Playback Play a Specific Location on a Track When playing a CD or Super Audio CD, you can specify the track number and the start time from which to play back the track. When using a disc containing MP3 or WMA tracks, you can specify the folder number and track number.

  • Page 22: Eject The Disc

    Available Actions During Playback Eject the Disc Press the button to open the disc tray. After removing the disc, press the button again to close the tray. Change the Displayed Information You can change the information on the unit's display. Press the DISPLAY button.

  • Page 23: Playback Methods

    Playback Methods In addition to listening to tracks in the order they were recorded on the disc, there are four other playback methods: Repeat, A-B Repeat, Random, and Memory. You can also mix multiple playback methods (for example, repeat + random or repeat + memory). Repeat (Loop) Repeatedly play the currently playing track, all tracks in the folder in which the current track is located, or all...

  • Page 24: Memory Playback

    Playback Methods —Continued Memory Playback You can use this mode to play any tracks you choose, in any order. Notes You can store up to 32 tracks. Configure CD/Super Audio CD Playback While playback is stopped, press the MEMORY button on the remote controller. Use the number keys to enter the number of a track you wish to play.
  • Page 25 Playback Methods —Continued When TRACK flashes, enter the number of the desired track using the number keys. Example: To enter track 13, press "1" and "3". Press the ENTER button. The track you entered is stored, and the screen for storing the next track appears.
  • Page 26 Playback Methods —Continued Add a New Track to Memory Press the MEMORY button on the remote controller. SACD/CD MP3/WMA Press the TRACK / buttons to select the location to add. MP3/WMA Press the ENTER button. SACD/CD MP3/WMA Use the number keys to enter the number of the folder and track you wish to play.

  • Page 27: Setup

    Setup Setup Menu List PCM FILTER DSD FILTER PHASE AREA PRIORITY * Default setting Available Settings PCM FILTER When using analog output, you can apply a digital filter to the PCM data before it is passed through the D/ A converter. The digital filter can switch the properties in the audible or inaudible frequency ranges.
  • Page 28 Setup —Continued DSD FILTER When using analog output while playing a Super Audio CD, you can apply a digital filter to the DSD data before it is passed through the D/A converter. The digital filter can switch the properties in the audible or inaudible frequency ranges.

  • Page 29: Making Settings

    Setup —Continued Making Settings Caution If this setting is changed during playback, it may not be possible to store the changed settings in memory. If you have changed the settings during playback, stop playback and other actions, and then turn off the power. Press the SETUP button on the remote controller.

  • Page 30: Troubleshooting

    - Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings caused by the unit's malfunction. Before you record important data, make sure that the material will be recorded correctly.

  • Page 31: Playing Music Cds With Copy Control Functions

    Remote Controller Problem Solution The buttons on the CD player work, but the Install two new batteries. buttons on the remote controller do not Make sure that the remote controller is not too far away from the unit, and that there is no obstruction between the unit and the remote controller.

  • Page 32: Devices

    Troubleshooting —Continued Devices Problem system features do not work. Solution Make sure that both the cable and audio cable are connected correctly to the component. The system will not function if only the cable are connected. Check the amplifier and AV receiver input. Also check the manual of each device, because there may be settings that prevent connected devices from operating.

  • Page 33: Specifications

    Specifications Audio Output Frequency Response Signal to Noise Ratio Audio Dynamic Range THD (Total Harmonic Distortion) Output/Impedance General Power Supply Power Consumption Dimensions (WxHxD) Weight Operating Condition Temperature/Humidity : 5 °C - 35 °C (41 °F - 95 °F) / 5 % - 85 % Playable Discs Specifications and features are subject to change without notice.
  • Page 34 Memo...
