BLU-RAY DISC PLAYER
DV-BD606
Instruction Manual
Thank you for purchasing an Onkyo BLU-RAY DISC
PLAYER. Please read this manual thoroughly before
making connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new BLU-RAY DISC PLAYER.
Please retain this manual for future reference.
Contents
Introduction ............................................................ 2
Connections ............................................................ 12
Playback ..................................................................... 17
Function Setup ..................................................... 31
Others ........................................................................... 43
En
Advertisement
Table of Contents
Related Manuals for Onkyo DV-BD606
Summary of Contents for Onkyo DV-BD606
- Page 1 BLU-RAY DISC PLAYER DV-BD606 Instruction Manual Thank you for purchasing an Onkyo BLU-RAY DISC PLAYER. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new BLU-RAY DISC PLAYER.
-
Page 2: Important Safeguards
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. -
Page 3: Precautions
To maintain the best picture quality, we recommend regular inspection and maintenance (cleaning or worn part replacement). Contact your Onkyo dealer. 11. Moisture Condensation Moisture condensation may damage this unit. - Page 4 • Do not use this unit when there’s the possibility of moisture condensation occurring. Doing so may damage your discs and certain parts inside this unit. If condensation does occur, remove all discs and leave this unit turned on for two to three hours. By this time, the unit will have warmed up and any condensation will have evaporated.
- Page 5 Supplied Accessories remote control with RCA audio / video cables batteries (AAx2) AC cord instruction manual warranty card Instruction Manual Note about Recycling • This unit’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.
-
Page 6: Table Of Contents
Introduction PRECAUTIONS ........2 FEATURES ........7 Features . -
Page 7: Features
About HDMI CEC (consumer electronics control) This unit supports HDMI CEC, which allows integrated system control over HDMI and is part of the HDMI standard. Onkyo does not guarantee 100% interoperability with other brands of HDMI CEC compliant devices. PIP (Picture in Picture) (BONUSVIEW) setting... -
Page 8: Functional Overview
FUNCTIONAL OVERVIEW Front Panel ON / STANDBY The unit can also be turned on by pressing these buttons. 1. STANDBY indicator • This indicator lights up in red in standby mode and turns off when the power is on. 2. y y ON / STANDBY button •... -
Page 9: Remote Control
FUNCTIONAL OVERVIEW Remote Control The unit can also be turned on by pressing these buttons. 1. DISPLAY button • Press to display the on-screen display menu. 2. ON/STANDBY I /y y button • Press to turn the unit on or off. 3. - Page 10 Either side of the center: approx. 16 feet (5m) within 30° Above: approx. 16 feet (5m) within 15° Below: approx. 10 feet (3m) within 30° ON / STANDBY SD CARD BLU-RAY DISC PLAYER 30˚ 16 feet 23 feet (5m) (7m) DV-BD606 30˚ 16 feet (5m)
-
Page 11: Front Panel Display
FUNCTIONAL OVERVIEW Front Panel Display • Brightness of the display can be adjusted. Refer to “Panel Display” in “FUNCTION SETUP” on page 41. 1. Displays playback status icon. Refer to the table below. 2. Displays various kinds of information such as title number, elapsed time, repeat mode, etc. Playback status icon Disc SD Memory Card... -
Page 12: Connections
Connection to the TV • Make one of the following connections, depending on the capabilities of your existing device. AUDIO CONNECTION standard audio AUDIO IN audio cable AUDIO O ANALOG this unit AUDIO OUTPUT DIO OUTPUT ANALOG DIGITAL DIGITAL (PCM//BITSTREAM) (PCM//BITSTREAM) COAXIAL COAXIAL... - Page 13 HDMI Output Mode and Actual Output Signals Press [RESOLUTION] to change the resolution of the video signal being output from HDMI OUT jack. The video resolution changes as follows every time [RESOLUTION] is pressed. Front Panel HDMI Video Resolution Display 480 Progressive Press [RESOLUTION] 720 Progressive...
- Page 14 HDMI Audio Setting When using HDMI connections make “HDMI Audio Out” setting in “Audio” menu according to the specifications of the device to be connected. Device to be connected Device compatible with Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD decoding Device compatible with 3 or more channels of audio inputs (not Dolby...
-
Page 15: Connection To An Audio System
Connection to an Audio System • When you change the connections, all devices should be turned off. • Refer to the manual accompanying external devices for more information. 2-Channel Analog Audio Connection audio RCA audio cable this unit Digital Audio Connection AV receiver / amplifier audio this unit... -
Page 16: Connecting The Ac Cord
■ Audio signals output from AUDIO OUTPUT (DIGITAL COAXIAL/OPTICAL) jacks The audio signals currently output from HDMI OUT jack will be output from AUDIO OUTPUT (DIGITAL COAXIAL / OPTICAL) jacks as well, except that Dolby Digital signal will be output instead of Dolby Digital Plus and Dolby TrueHD, and DTS signal will be output instead of DTS-HD. -
Page 17: Information On Playback
INFORMATION ON PLAYBACK Before you start playing back a disc, read the following information. Playable Discs and Files This unit is compatible to play back the following discs / files. To play back a disc / file, make sure that it meets the requirements for region codes and color systems as described below. - Page 18 INFORMATION ON PLAYBACK Color Systems BD-video and DVD-video are recorded in different color systems throughout the world. The most common color system is NTSC (which is used primarily in the United States and Canada). This unit employs NTSC color system, so the disc you play back must be recorded in the NTSC system.
-
Page 19: Disc Information
INFORMATION ON PLAYBACK ■ Chapter information <Title / Chapter information for BD> 1 / 10 <Chapter information for DVD> 3 / 5 0 : 01 : 02 Current title number Current chapter number / Total number of chapters Current repeat setting (Only when repeat setting is active) (C: Chapter repeat, T: Title repeat, AB : A-B repeat) Indicates that the multi camera angle images are... -
Page 20: Basic Playback
BASIC PLAYBACK Playback BD-V DVD-V Press [ON /STANDBY I /y]. Turn on the TV and select the appropriate input on the TV to which the unit is connected. Press [OPEN / CLOSE A ] to open the disc tray. Place the disc on the disc tray with its label side facing up. -
Page 21: Operations Using Title Menu, Disc Menu
Operations Using Title Menu, Disc Menu, and Pop-up Menu BD-V DVD-V Many of BD-video and DVD-video disc contains title menu (BD-video / DVD-video), disc menu (DVD-video) or pop- up menu (BD-video) which guides you through the available functions in the disc. The contents of the menus may differ depending on the discs. -
Page 22: Playing Back An Audio Cd And A Disc With
Playing Back an audio CD and a Disc with MP3 Files Insert an audio CD or a disc with MP3 files. • The file list will appear on the TV screen. • If file list does not appear automatically, press [POP UP MENU / MENU]. -
Page 23: Reading The Sd Memory Card
SD CARD • This will set the unit to “SD Memory” mode. To SD CARD BLU-RAY DISC PLAYER DV-BD606 play back the contents in any discs, exit “SD Memory” mode by selecting “Disc”. Press [SETUP] to exit. , then press... - Page 24 SD Memory Card. • This unit recognizes up to 8 characters of file name in the SD Memory Card. Characters after 9th will not be displayed. BASIC PLAYBACK SD CARD SD CARD BLU-RAY DISC PLAYER DV-BD606 SD Memory Card...
-
Page 25: Special Playback
SPECIAL PLAYBACK Fast Forward / Fast Reverse BD-V DVD-V During playback, press [FWD D] repeatedly for fast forward. During playback, press [REV E] repeatedly for fast reverse. Every time you press [FWD D] or [REV E], the playback speed will change. Press [PLAY B] to return to normal playback. -
Page 26: A-B Repeat
A-B Repeat BD-V DVD-V You can play back the specific part (between point A and point B) repeatedly. During playback, press [A-B] at the desired starting point A. During playback, press [A-B] at the desired ending point B. As soon as you set the point B, the part between point A and point B will start playback repeatedly. -
Page 27: Random Playback
Random Playback This function shuffles the playback order of tracks / files. In stop mode, press [MODE] twice. • The random screen will appear. Random CD-DA Total Random Program -- no indication -- e.g.) audio CD Press [PLAY B ] to start random playback. -
Page 28: Search
Using [SKIP H / G ] During playback, press [SKIP G] to move to the next track. Press it repeatedly to skip to subsequent tracks. Press [SKIP H ] once to go back to the beginning of the current track. Press it repeatedly to go to the previous tracks. -
Page 29: Special Settings
SPECIAL SETTINGS You can select the format of audio and video as you prefer depending on the contents of the disc you are playing back. Switching Subtitles Some BD and DVD may have subtitles in 1 or more languages. For commercially available discs, the supported languages can be found on the disc case. -
Page 30: Setting The Bd Audio Mode
Setting the BD Audio Mode BD-V There are 2 ways to set “BD Audio Mode” setting; whether to output the secondary and interactive audio accompanied by the primary audio or only the primary audio. Depending on the setting of the mode, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, or DTS-HD output changes between multi LPCM and bitstream. -
Page 31: Function Setup
FUNCTION SETUP Using the Setup Menu In the setup menu you can change the setting for audio, video, language, etc. You cannot change the setting during playback. Quick “Quick” menu contains setting items extracted from “Custom” menu which may be used frequently. In stop mode, press [SETUP]. - Page 32 FUNCTION SETUP Custom “Custom” menu contains all the setting items. In stop mode, press [SETUP]. Use [K / L] to select [ENTER]. Use [K / L] to select your desired setting category, then press [ENTER]. : Language : Video : Audio : Parental : Others •...
- Page 33 ■ Language Language Audio Subtitle Disc Menu Player Menu • For how to select the setting items and options, refer to “Custom” on page 32. Setting items Audio Sets the language for audio. Subtitle Sets the language for subtitle. Disc Menu Sets the language for disc menu or pop-up menu.
- Page 34 ■ Video Video TV Aspect HDMI Video Resolution HDMI Deep Color Component Output Progressive Mode Still Mode • For how to select the setting items and options, refer to “Custom” on page 32. Setting items TV Aspect Sets the picture size according to aspect ratio of the connected TV.
- Page 35 Setting items Still Mode Adjusts picture resolution and quality in still mode. • Settings with (*) are the default. • “Quick” menu consists of the setting menus frequently used, and they are accompanied with • If you set “HDMI Video Resolution” setting to “1080p24” and the contents of the BD are not compatible for 1080p24 frame, 1080p60 frame will be output.
- Page 36 ■ Audio Audio BD Audio Mode HDMI Audio Out Down Sampling Virtual Surround • For how to select the setting items and options, refer to “Custom” on page 32. Setting items BD Audio Mode For BD, selects whether to output the secondary and interactive audio with primary audio if it is available or only the primary...
-
Page 37: Speaker Setting
■ Digital out setting When “Audio Mute” is selected in “HDMI Audio Out” setting, HDMI audio signal will be muted and the audio signals output from AUDIO OUTPUT (DIGITAL COAXIAL / OPTICAL) jacks change depending on “Digital Out” setting. Quick HDMI Audio Out Audio Mute Bitstream*:... - Page 38 How to navigate through “HDMI Multi(LPCM)”. Use [K / L] to select your desired menu item then press [ENTER]. Use [K / L] to select your setting items. • Press [RETURN] to go back to the previous screen. Use [s / B] to select desired options. (Except for “Test Tone”, “Default” and setting options in “Speaker Size”...
- Page 39 Menu Setting items Delay Time Distance This is a parameter for optimizing the timing at which the sound is output from the Front speakers according to their distance from the listening position. Center Surround Surround Back Default • Settings with (*) are the default. •...
- Page 40 ■ Parental Ratings control allows you to set a limit, which prevents your children from viewing inappropriate materials. Playback will be stopped if the ratings exceed the levels you set, and it will require you to enter a password before playing back the disc.
-
Page 41: Others
Selects the media to playback. • HDMI CEC allows integrated system control over HDMI and is part of the HDMI standard. In addition to Onkyo AV components, it allows interoperability with CEC-compatible AV components and TVs made by other manufacturers. •... - Page 42 FUNCTION SETUP Initialize Initialize the setting or SD Memory Card. In stop mode, press [SETUP]. Use [K / L] to select [ENTER]. Use [K / L] to select a desired option, then press [ENTER]. “No”: “Setup”: Resets the setup menu to the default. “Memory Device”: Press [ENTER].
-
Page 43: Troubleshooting
TROUBLESHOOTING If the unit does not perform properly when operated as instructed in this manual, check the unit, consulting the following checklist. Problem No power No sound or picture Distorted picture Completely distorted picture or black / white picture with BD / DVD No sound or distorted sound Picture freezes momentarily during playback... -
Page 44: Glossary
Analog Audio An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. See also “Digital Audio”. Aspect Ratio The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square);... -
Page 45: Language Code
LANGUAGE CODE Language Code Language French [FRE] Abkhazian 4748 Frisian Afar 4747 Galician Afrikaans 4752 Georgian Albanian 6563 German [GER] Amharic 4759 Greek [GRE] Arabic 4764 Greenlandic Armenian 5471 Guarani Assamese 4765 Gujarati Aymara 4771 Hausa Azerbaijani 4772 Hebrew Bashkir 4847 Hindi Basque... -
Page 46: Specifications
General Signal system Power requirements Power consumption Dimensions (width x height x depth) Weight Operating temperature Operating humidity Terminals Audio output (Analog) RCA jack x 2 Video output RCA jack x 1 Component video output RCA jack x 3 Audio output (Digital) RCA jack x 1 Optical jack x 1 HDMI output... - Page 47 MEMO...
- Page 48 Unit 1&12, 9/F, Ever Gain PlazaTower 1, 88, Container Port Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039 http://www.ch.onkyo.com/ SN 29344888 (C) Copyright 2008 ONKYO CORPORATION Japan. All rights reserved. HOMEPAGE http://www.onkyo.com/ Printed in China E5H50UD / 1VMN26319 ★★★★★...
