One for All SV-1100 User Manual

The ONE FOR ALL Remote Control Blaster (SV-1100) converts the Infra-Red (IR) signals from your Remote
Control into Radio-Frequency (RF) allowing you to control your devices through doors, windows, floors
and walls without having to worry about line of sight requirements (up to 30 metres, room to room).
Simply connect the included RECEIVER to the corresponding device to receive the RF signals.
NOTE: this product may not work with remotes with metal housing or displays
A
RF TRANSMITTER
B
2/3 size AAA rechargeable battery
C
AA size sleeve (if your remote control requires AA batteries)
D
RECEIVER
E
IR Eye cord cord (3 IR eyes, 2 Metres long)
F
Power Adaptor
Installing the SV-1100 in 3 easy steps
Simply install the RF transmitter instead of one of the AAA or AA
1
batteries inside your remote control.
NOTE: You may have to change the position of the RF transmitter to have better
RF performance.
Set the Selection Switch (on the back of the RECEIVER) to...
2
A : 58KHz (for few and very specific remotes)
B : 38KHz (most remote controls)
C : Sensitivity lower e.g. other equipment using 433.92MHz (external
interference).
See section: "Interference".
3.1 Place the RECEIVER next to the corresponding device(s) you wish to control.
3
3.2 Connect the IR Eye cord plug to the back of the RECEIVER and place the IR
Eye on the receiving window (IR sensor) of the corresponding device.
NOTE: There are 3 IR Eyes to control 3 separate devices.
NOTE: Remove the adhesive tape on the bottom of the IR Eye to secure it on the
front of the audio/video equipment IR sensor.
3.3 Plug the Power adaptor in the wall socket and connect the DC connector
to the back of the RECEIVER. The POWER LED on the top of the RECEIVER
will illuminate.
WWW.ONEFORALL.COM
Introduction
This Package contains
4
