Omnitron Systems Technology OST iConverter 4Tx Specification Sheet

4-port 10/100base-tx managed ethernet switch

Advertisement

Quick Links

iConverter
iConverter
iConverter
4Tx
®
4-Port 10/100BASE-TX Managed Ethernet Switch
The
iConverter 4Tx 10/100 Ethernet Switch module is a member
of the managed
iConverter product family. The 4Tx provides a
compact 4-Port 10/100 Ethernet switch that is expandable
across the
iConverter 19-Module, 5-Module and 2-Module
chassis backplanes, as well as being supported as a
standalone switch with the
The
iConverter 4Tx UTP ports feature 10/100Mbps, Half or
Full-Duplex and auto-negotiation with both hardware and
software controls. Hardware control is available for two ports
while all four ports are under software control for these features.
RJ-45 crossover support eliminates need for a crossover cable
and facilitates connectivity to different types of network
equipment. The 4Tx crossover switch is supported on Port 1.
Ports 2, 3 and 4 support an automatic crossover detection
mode. The 4Tx also features two Ethernet backplane ports to
provide connectivity to adjacent modules for network expansion
and for in-band connectivity to an
Management Module.
4Tx enhanced features include Port VLAN which allows
complete control of traffic flow between a module's ports, and
Port Access Control which incorporates remote enabling and
disabling of each individual port. The 4Tx supports reporting of
MIB statistics that are available for 32 variables per port, reporting
a wide range of real-time packet statistics to provide
performance and operational monitoring.
iConverter 4Tx modules are hot-swappable and can be mounted
in a 19-Module (2U high) or 5-Module (1U high) rack-mountable
chassis (19-inch or 23-inch) with any combination of redundant
AC, 24VDC or 48VDC power supplies. They can also be mounted
in a 2-Module AC or 18 to 60VDC powered chassis, or in a
1-Module AC/DC powered chassis.
iConverter 1-Module Chassis.
iConverter Network
The
iConverter 4Tx Managed Ethernet Switch supports
10BASE-T or 100BASE-TX on four UTP ports
Enhanced features include Port VLAN, Port Access
Control and MIB Statistics
Multiple 4Tx modules can be installed to expand the
port concentration in a single chassis
Supports Half or Full-Duplex and auto-negotiation
RJ-45 crossover support eliminates need for
different cables in connecting to various devices
Ethernet backplane ports for connectivity to adjacent
modules
Management is available with the addition of a
management module to the chassis
SNMP management via
NetOutlook
port and module information, remote parameter
configuration and trap notification
Conforms to IEEE 802.3, 10BASE-T and 100BASE-TX
specifications
Modules are hot-swappable in 19-Module, 5-Module,
2-Module or 1-Module chassis
Lifetime Warranty and free 24/7 Technical Support
provides real-time

Advertisement

loading
Need help?

Need help?

Do you have a question about the OST iConverter 4Tx and is the answer not in the manual?

Questions and answers

Summary of Contents for Omnitron Systems Technology OST iConverter 4Tx

  • Page 1 RJ-45 crossover support eliminates need for a crossover cable and facilitates connectivity to different types of network equipment. The 4Tx crossover switch is supported on Port 1. Ports 2, 3 and 4 support an automatic crossover detection mode. The 4Tx also features two Ethernet backplane ports to...
  • Page 2 For wide (-40 to +60º C) and extended (-40 to +75º C) temperature range chassis, contact Omnitron for details. Trademarks are owned by their respective companies. iConverter is a registered trademark of Omnitron Systems Technology, Inc. NetOutlook is a trademark of Omnitron Systems Technology, Inc. Specifications subject to change without notice.
