SPECIFICATIONS
n Protocol:
n Terminals:
n Printer's Supported:
n Cable Types:
Fiber Optic:
STP:
UTP:
n Data Rate:
n Supported Distances:
Multi-mode fiber:
Singlemode fiber:
Port STP:
Port UTP:
n Indicators:
Test Mode:
Link:
Port:
n Physical Dimensions:
n Weight:
n Power Supply (External):
n Temperature:
Operating:
Storage:
Humidity:
TECHNICAL SUPPORT
For assistance in installing this product, contact Omnitron's Technical Support
Department.
Phone:
(949) 250-6510
Fax:
(949) 250-6514
Address:
Omnitron Systems Technology, Inc.
27 Mauchly #201
Irvine, CA 92618, USA
Email:
support@omnitron-systems.com
URL:
www.omnitron-systems.com
Omnitron Systems Technology, Inc.
IBM 5250 and 5250 Express for systems AS/400 and
Systems 34/36/38
3179, 3180, 3196, 3197, 3476, 3477, 5250, 5251,
5291, 5292, and compatibles
3262, 3812, 4214, 4224, 4234, 5219, 5224, 5225,
5226, 5262, and compatibles
Multi-mode glass fiber of sizes 50/125, 62.5/125, or
100/140 micron
Twinax female to DB-9 female
3 ft.
OST# 310-00012-000
6 ft.
OST# 310-00013-000
DB-15 female to DB-9 female
3 ft.
OST# 310-00014-000
6 ft.
OST# 310-00015-000
Level 3 (EIA/TIA 568):
24 AWG solid copper 100 +/- 15 Ohms @ 1.0 Mhz;
7db per 1,000 ft. @ 1.0 Mhz (lower grade wiring at
shorter distances)
1 Mbps +4%, -2%
15,000 ft.
30,000 ft.
5,000 ft.
3,000 ft.
Green LED
Red LED
Green-Red LED
Green-Red LED
W:3.46"xD:2.83"xH:0.78"
2 lbs.
9 VDC @ 1.2A
0° to 40°C
-40° to 75°C
Up to 90% (non-condensing)
Omnitron Systems Technology, Inc.
OmniRepeater
Systems AS400/3X
Fiber to Desk Repeater
User's Manual
27 Mauchly #201, Irvine, CA 92618; (949) 250-6510, Fax: (949) 250-6514
Document #040-02900-001
1
TM
400FTD
Advertisement
Table of Contents
Related Manuals for Omnitron Systems Technology OmniRepeater 400FTD
Summary of Contents for Omnitron Systems Technology OmniRepeater 400FTD
- Page 1 Omnitron Systems Technology, Inc. SPECIFICATIONS n Protocol: IBM 5250 and 5250 Express for systems AS/400 and Systems 34/36/38 n Terminals: 3179, 3180, 3196, 3197, 3476, 3477, 5250, 5251, 5291, 5292, and compatibles n Printer’s Supported: 3262, 3812, 4214, 4224, 4234, 5219, 5224, 5225,...
- Page 2 B. Media Converter Application B shows the host computer attached to an OmniRepeater 400FTD, which in turn, is attached to a remote OmniMux 400 which is configured as a star. C. Media Converter to the Desk Application C shows a remote user workstation attached to an OmniMux 400 via two OmniRepeater 400FTD units.
- Page 3 OPERATION Switches & Indicators The OmniRepeater 400FTD has two switches. The switch on the left, switch 1, controls the polarity of the data. Switch 2 turns the fiber test mode on and off.
- Page 4 In addition to the two switches there are four LED indicators in a 2x2 cluster. Refer to the drawings below. The meaning of the LEDs is shown on the cover of the OmniRepeater 400FTD and in the tables below. Self Test Mode Omnitron Systems Technology, Inc.
- Page 5 Fiber Optic Media Test - 2 OmniRepeater 400FTD’s To test the integrity of fiber optic cables that are already installed, use two OmniRepeater 400FTD units connected to each other in TEST mode. If the fiber media is unbroken, the link LEDs on each unit will illuminate green.
- Page 6 (i.e., one end in the transmit port and the other in the receive port). If the fiber is unbroken, the OmniRepeater 400FTD fiber link LED will illuminate green. If the fiber is partially or completely broken the LED will be red or off.
