K-79
Dialtemp™ Thermometer
INSTRUCTION
SHEET
SECTION 1 INTRODUCTION
The OMEGA
mechanical (non-electronic) thermometer that is accurate, rugged and light
in weight. The clear, easy to read 1" dial has a pointer that is directly driven
by the sensitive bi-metal helix coil located in the shaft. The 0.142" diameter,
5" stainless steel probe has a needle tip for penetrating semi-solid materials
such as fruits and meats. The pointed probe is supplied with a tubular
pocket case complete with a pocket clip and holder loop. (See Figure 1)
M0299/0802
Model K-79 Series Pocket Thermometer is a small,
®
POCKET CLIP
Figure 1 K-79 Thermometer with Pocket Case
POCKET CASE
DIALTEMP
LOOP HOLDER
Advertisement
Table of Contents
Related Manuals for Omega K-79
Summary of Contents for Omega K-79
-
Page 1: Section 1 Introduction
5" stainless steel probe has a needle tip for penetrating semi-solid materials such as fruits and meats. The pointed probe is supplied with a tubular pocket case complete with a pocket clip and holder loop. (See Figure 1) Model K-79 Series Pocket Thermometer is a small, POCKET CLIP POCKET CASE... - Page 2 K-79-3 K-79-4 SECTION 2 UNPACKING Each OMEGA K-79 is packaged with an Operator’s Manual and a removable tubular pocket case with safety pocket clip and holder loop. Remove the packing list and verify that all equipment has been received. If there are any questions about the shipment, please call the OMEGA Customer Service Department at 1-800-622-2378 or (203) 359- 1660.
-
Page 3: Section 5 Specifications
SECTION 4 CALIBRATION OMEGA K-79 Series Pocket Thermometers are factory calibrated. The alloys used in the bi-metal element determine the span calibration and are not adjustable. The dial head itself, however, can be reset. This is done at ambient temperature, where the pointer remains stable, and the dial is adjusted. - Page 4 OMEGAnet ® Online Service www.omega.com Servicing North America: USA: One Omega Drive, Box 4047 ISO 9001 Certified Stamford CT 06907-0047 Tel: (203) 359-1660 e-mail: info@omega.com Canada: 976 Bergar Laval (Quebec) H7L 5A1 Tel: (514) 856-6928 e-mail: info@omega.ca For immediate technical or application assistance: USA and Sales Service: 1-800-826-6342 / 1-800-TC-OMEGA Canada:...
