- Page 1 User’s Guide Shop online at omega.com ® ® www.omega.com e-mail: info@omega.com OS950 SERIES Handheld Infrared Thermometers...
- Page 2 Toll Free in United Kingdom: 0800-488-488 e-mail: sales@omega.co.uk It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing certi- fication of its products to the European New Approach Directives.
-
Page 5: Table Of Contents
Chapter Two - Operation ..... . .2 2.1 OS950 Controls ......2 2.2 To Change Display Measurement Units . -
Page 6: Chapter One - Welcome To Infrared Thermometry
Since the OS950 is NIST traceable, it can function as a pri- mary temperature calibrator for other temperature measur- ing devices, serving your corporate quality instrument cali- bration programs. -
Page 7: Chapter Two - Operation
Sensor window 2.2 To Change Display Measurement Units The OS950 Models come from the factory displaying tem- perature in units of Fahrenheit. To display readings in units of Celsius, perform the following steps: Remove the screw from the underside of the case. -
Page 8: To Change Mode Of Operation
ºF/ºC Switch 2.3 To Change Mode of Operation The OS950 Models come from the factory operating in the MAX mode. To change to the SCAN mode perform the fol- lowing steps: Remove the screw from the underside of the case. -
Page 9: Temperature Measurement Of Moving Targets
Allow a few minutes between readings for the nosepiece to cool down and stabilize. If the OS950 makes contact with a hot surface and an error message [HI] shows on the display remove the instrument from the object immediately. -
Page 10: Scan Mode Temperature Measurements
1 to 1, it is important to properly determine the best measuring distance from the target, to optimize the reading. A field of view of 1 to 1 means that the OS950 viewing area is 1" diameter for 1" distance from target. Optimize optical alignment, so that the OS950 views only the target and does not overlap the measurement area. -
Page 11: Optimizing Aesc Measurements For Nist Traceability
3.3 Optimizing AESC Measurements for NIST Traceablity If you look at the OS950's nosepiece, you will see that it is really a small reflective cup with the sensor's window at its base. When the OS950's nosepiece touches the surface of... -
Page 12: Chapter Four - Maintentance
As long as the ice is not melting, the OS950 will accurately read its temperature. To make an accurate target measurement, remove any ice or moisture before measuring. Chapter Four - Maintenance The high-performance OS950 is a rugged and durable instrument, designed for long term performance reliability. - Page 13 °F (50 °C) [LO A] Ambient < 32 °F (0 °C) [N/A] Battery power [----] Dead battery [E-##] Internal fault or [Err} Remedy Use higher OS950 Use higher OS950 Use higher OS950 Contact Omega Remedy Contact Omega Use lower OS950...
-
Page 14: Troubleshooting Measurement Difficulties
Touch the nosepiece flush to the target's surface and repeat the measurement. If after applying all of the above solutions, the instrument's accuracy is still in question, contact Omega for further help. Chapter Six - OS950™ Specifications Target Temperature Range OS951 -50 to 550°F (-45 to 287°C) -
Page 15: Field Of View
Display Update 10 times/second Measurement Response Time Approximately 0.1 seconds Field of View 1:1 0.63" (15.9 mm) Diameter Spot Area in AECS Mode Spectral Sensitivity 2 to 20 microns Battery One 9 volt Battery Life 5000 readings (10 seconds each) Instrument Ambient Temperature Operating Range: 32 to 122°F (0 to 50°C) Storage Range: -22 to 140°F (-30 to 60°C)*... - Page 17 OMEGA’s Customer Service Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from...
- Page 18 Where Do I Find Everything I Need Process Measurement and Control? OMEGA…Of Course! Shop online at www.omega.com TEMPERATURE Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies Wire: Thermocouple, RTD & Thermistor Calibrators & Ice Point References Recorders, Controllers & Process Monitors...
