TABLE OF CONTENTS Safety Warnings Tool Operation Maintenance Accessories Troubleshooting Specifications EMPLOYER’S RESPONSIBILITIES Employer must enforce compliance with the safety warnings and all other instructions contained in this manual. Keep this manual available for use by all people assigned to the use of this tool.
General Safety Rules (For all Battery Operated Tools) Safety Warnings WARNING Read all safety warnings and all instructions Failure to follow the warnings and instructions may result in electric shock, fire and/ or serious injury. Save all warnings and instructions for future reference.
Safety Warnings Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Page 5
Safety Warnings Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. Do not overreach. Keep proper footing and balance at all times.
Page 6
Safety Warnings English Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. Maintain power tools.
Page 7
FOR CHARGER & BATTERY CARTRIDGE SAVE THESE INSTRUCTIONS This manual contains important safety and operating instructions for SENCO battery charger VB0156 (US) and VB0158 (AUS/NZ). Use with approved Senco batteries stated on the charger label. • Before using SENCO battery...
Page 8
Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any way; take it to a SENCO Authorized Service Center. Do not disassemble charger or battery cartridge; take it to a SENCO Authorized Service Center when service or repair is required.
Page 9
The battery car- tridge can explode in a fire. Do not use tool without Warning Label on tool. If label is missing, damaged or unreadable, contact your SENCO representative to obtain a new label at no cost.
Safety Warnings Never attempt to connect two (2) chargers together. Consecutive charging may cause overheating. If you need to recharge batteries consecutively, wait about 15 minutes for the charger to cool. Battery leakage may occur under conditions of extreme usage or temperature. If liquid comes in contact with skin, wash quickly with soap and water, then with lemon juice or...
Release pin ensuring it is fully engaged in selected nosepiece slot for proper operation. Nosepiece has settings; DS215-18V DS212-18V DS312-18V 1" 1" 1" 1 " 1 " 1 " 1 "...
Page 12
Tool Operation Feed the strip into the slide body until the 2nd empty slot is aligned with the bit. The tool will feed the fist screw when depressed against the work surface. To remove the strip pull it through from the top of the nosepiece.
Page 13
Tool Operation Test drive one screw before finalizing the depth to ensure appropriate countersink. This tool has a depth-sensing clutch. When the screw is countersunk to the pre- set depth, it automatically disengages and makes a click or racheting sound. This is normal and signals completion of the drive.
Page 14
Tool Operation Remove fasteners from the tool. (1) Slide bit release button to rear. (2) Tilt tool forward and pulse trigger. Bit will fall out. (1) Hold tool upright. Insert the new bit into the slide body. (2) Slide bit release button to rear.
Page 15
Red light indicates fast charging mode. Red and green light flashing indicates defective battery pack. Return battery pack to your nearest SENCO Authorized Service Center for inspection or replacement. Solid red indicates that the battery is charging. Authorized...
Page 16
Tool Operation Tips for maintaining Maximum battery life Charge the battery pack before it is completely discharged. Always stop tool operation and charge the battery when you notice less tool power. Never recharge a fully charged battery. Overcharging shortens the battery service life.
Do not oil. Wipe tool clean daily and inspect for wear. A c c e s s o r i e s SENCO offers a full line of Du- raSpin screws and accessories for your SENCO tools, including: Bits Batteries...
Tool does not advance fastener Use Senco branded fasteners for optimum performance Defective slide body Replace or return to Senco authorized service center for repair. Screw strip is jammed in guide track Ensure strip slides free in guide track Screw length improperly set See pg.
