RISER DIAGRAM / LENGTHS (mm)
No. of Cells
Projected Area (m2)
Flat Area (m2)
Projected Span (m)
Flat Span (m)
Projected Aspect Ratio
Flat Aspect Ratio
Root Chord (m)
Glider Weight (Kg)
Max Control Travel (cm)
I
n-Flight Weight Range (Kg)
Certification EN/LTF
Non Accelerated
A 500
B 500
C 500
Accelerated
Pulleys axis - axis
A 350
B 400
C 500

TECHNICAL SPECIFICATIONS

XS S
57 57
18.0 20.1
21.4 23.8
8.55 9.02
10.09 11.51
4.05 4.05
5.55 5.55
2.47 2.61
4.9 5.2
74 74
55-70 65-85
B/B* B/B*
*To be confirmed
57
MS ML L
57 57 57
21.2 22.3 23.7
25.1 26.5 28.1
9.27 9.51 9.78
11.82 12.13 12.48
4.05 4.05 4.05
5.55 5.55 5.55
2.68 2.75 2.83
5.5 5.7 6.0
75 74 74
75-95 85-105 95-115
B/B* B/B* B/B*
XL
57
26
30.8
10.25
13.08
4.05
5.55
2.97
6.3*
75
110-130
B/*
