Minimum Gauge for Cord Sets
Volts
Total Length of Cord in Feet
120V
0-25
(0-7,6m) (7,6-15,2m) (15,2-30,4m) (30,4-45,7m)
240V
0-50
(0-15,2m) (15,2-30,4m) (30,4-60,9m) (60,9-91,4m)
Ampere Rating
More
Not more
Than
Than
0
-
6
18
6
-
10
18
10
-
12
16
12
-
16
14
8. Use only the supplied charger when charging your tool. The use of any other charger
could damage the drill or create a hazardous condition.
9. Use only one charger when charging.
10. Do not attempt to open the charger. There are no customer serviceable parts inside.
Return to any authorized Black & Decker service center.
11. DO NOT incinerate the tool or batteries even if they are severely damaged or complete-
ly worn out. The batteries can explode in a fire.
12. A small leakage of liquid from the battery cells may occur under extreme usage, charg-
ing or temperature conditions. This does not indicate a failure. However, if the outer
seal is broken and this leakage gets on your skin:
a. Wash quickly with soap and water.
b. Neutralize with a mild acid such as lemon juice or vinegar.
c. If the battery liquid gets in your eyes, flush them with clean water for a minimum of 10
minutes and seek immediate medical attention. MEDICAL NOTE: The liquid is a
25-35% solution of potassium hydroxide.
Charging Procedure
THE BATTERIES IN YOUR TOOL ARE NOT FULLY CHARGED AT THE FACTORY.
BEFORE ATTEMPTING TO CHARGE THEM, THOROUGHLY READ ALL OF THE SAFETY
INSTRUCTIONS.
To charge your screwdriver, follow the steps below.
1. Plug the output cord of the charger into the socket in the top half of the screwdriver handle
as shown in Figure 1.
2. Plug the charger into any standard 120 Volt 60 Hz electrical outlet
3. Let the tool charge initially for 9 hours. After the initial charge, under normal usage, your
tool should be fully charged in 3 to 6 hours.
CAUTION: When disconnecting the tool from the charger, be sure to unplug the charger
from the outlet first then disconnect the charger cord from the tool. Do not use the tool while
it is connected to the charger.
Important Charging Notes
1. After normal usage, your tool should be fully charged in 3 to 6 hours. If the batteries are
run-down completely, it may take up to 6 hours to become fully charged. Your tool was
sent from the factory in an uncharged condition. Before attempting to use it, it must be
charged for at least 9 hours.
2. DO NOT charge the batteries in an air temperature below 40°F (4,5°C) or above 105°F
(+40,5°C). This is important and will prevent serious damage to the batteries. Longest
life and best performance can be obtained if batteries are charged when air tempera-
ture is about 75°F (23,8°C).
3. While charging, the charger may hum and become warm to touch. This is a normal con-
dition and does not indicate a problem.
4. If the batteries do not charge properly—(1) Check current at receptacle by plugging in a
lamp or other appliance. (2) Check to see if receptacle is connected to a light switch
which turns power off when you turn out the lights. (3) Move charger and tool to a sur-
rounding air temperature of 40°F (4,5 °C) to 105°F (+40,5 °C). (4) If the receptacle and
temperature are OK, and you do not get proper charging, take or send the tool and
charger to your local Black & Decker service center. See Tools Electric in yellow pages.
5. The tool should be recharged when it fails to produce sufficient power on jobs which
were easily done previously. DO NOT CONTINUE using product with its batteries in a
depleted condition.
6. To prolong battery life, avoid leaving on charge for extended periods of time (over 30
days without use). Although overcharging is not a safety concern, it can significantly
reduce overall battery life.
7. The batteries will reach optimum performance after being cycled 5 times during normal
usage. There is no need to run the batteries down completely before recharging. Normal
usage is the best method of discharging and recharging the batteries.
Operating Instructions
Inserting an Accessory
To install a bit simply insert it into the cavity in the spindle until it snaps into place as shown in
Figure 2. To remove the bit pull it straight out. If bit does not fit into spindle, rotate the bit and
re-insert it.
Switch
Rotate the collar to the position marked POWER. To turn the tool ON in a forward direction,
press the top section of the rocker switch and the tool will run. Release pressure from the
switch and the tool will stop. To operate in reverse, press the bottom section of the rocker
switch.
Rotate the collar to the position marked MANUAL. With the collar in this position, the
forward/reverse button will not be active. Use the tool in this mode as any conventional
non-powered screwdriver.
Angling the screwdriver
To convert the tool to an angled screwdriver, push in on the release button shown in Figure
3 and rotate the top portion of the tool until it locks into one of the remaining two positions.
Three Position Screwdriver Warnings:
• To avoid being pinched, hold the screwdriver as shown in Figure 3 when changing
positions.
• Do not use screwdriver as a pry bar in any position.
• To avoid screwdriver being turned on accidentally, do not carry in your pocket.
LED Light
To turn the light on, push the slide switch located on the top of the screwdriver toward the
front of the tool.
Drilling
• Use sharp drill bits only.
• Support and secure work properly, as instructed in the safety Instructions.
• Use appropriate and required safety equipment, as instructed in the safety instructions.
• Secure and maintain work area, as instructed in the safety instructions.
• Run the screwdriver very slowly, using light pressure, until the hole is started enough
to keep the drill bit from slipping out of it.
• Apply pressure in a straight line with the bit. Use enough pressure to keep the bit
biting but not so much as to stall the motor or deflect the bit.
• DO NOT CLICK THE TRIGGER OF A STALLED SCREWDRIVER OFF AND ON IN
AN ATTEMPT TO START IT. DAMAGE TO THE SCREWDRIVER CAN RESULT.
• Keep the motor running while pulling the bit out of a drilled hole This will help reduce
jamming.
• Make sure switch turns tool on and off.
WARNING: It is important to support work properly and to hold the tool firmly to prevent
loss of control which could cause personal injury If you have questions on how to operate
tool, call: 1-800-544-6986.
Drilling in Wood
Bits should be sharp and should be pulled out frequently when drilling to clear chips from the
flutes. NOTE: This tool is not recommended for drilling in metal or masonry.
Maintenance
Use only mild soap and damp cloth to clean the tool. Never let any liquid get inside the tool;
never immerse any part of the tool into a liquid.
IMPORTANT: To assure product SAFETY and RELIABILITY, repairs, maintenance and
adjustment (other than those listed in this manual) should be performed by authorized
service centers or other qualified service organizations, always using identical replacement
parts.
26-50
51-100
101-150
51-100
101-200
201-300
American Wire Gauge
16
16
14
16
14
12
16
14
12
12
Not Recommended
Lubrication
Black & Decker tools are properly lubricated at the factory and are ready for use.
Accessories
Recommended accessories for use with your tool are available from your local dealer or
authorized service center. If you need assistance regarding accessories, please call:
1-800-54-HOW-TO. (800-544-6986)
not recommended may be hazardous.
The RBRC™ Seal
The RBRC™ (Rechargeable Battery Recycling Corporation) Seal on the nickel-
cadmium battery (or battery pack) indicates that the costs to recycle the battery
(or battery pack) at the end of its useful life have already been paid by Black &
Decker. In some areas, it is illegal to place spent nickel-cadmium batteries in the
trash or municipal solid waste stream and the RBRC program provides an environmentally
conscious alternative.
RBRC in cooperation with Black & Decker and other battery users, has established
programs in the United States and Canada to facilitate the collection of spent nickel-
cadmium batteries. Help protect our environment and conserve natural resources by
returning the spent nickel-cadmium battery to an authorized Black & Decker service center
or to your local retailer for recycling. You may also contact your local recycling center for
information on where to drop off the spent battery, or call 1-800-8-BATTERY.
Battery Removal
Before attempting to disassemble this tool, turn it on and run it in either direction until it stops
to ensure a complete discharge of the batteries. Using a phillips screwdriver, remove the
screw in the product housing shown in Figure 4 and remove the cap from the end of the
tool. Lift the batteries out and pull off the terminal clips. See "Service Information" for battery
replacement.
SERVICE INFORMATION
All Black & Decker Service Centers are staffed with trained personnel to provide customers
with efficient and reliable power tool service. Whether you need technical advice, repair, or
genuine factory replacement parts, contact the Black & Decker location nearest you. To find
your local service location, refer to the yellow page directory under "Tools—Electric" or call:
1-800-544-6986 or visit www.blackanddecker.com
FULL TWO-YEAR HOME USE WARRANTY
Black & Decker (U.S.) Inc. warrants this product for two years against any defects in material
or workmanship. The defective product will be replaced or repaired at no charge in either of
two ways.
The first, which will result in exchanges only, is to return the product to the retailer from
whom it was purchased (provided that the store is a participating retailer). Returns should be
made within the time period of the retailer's policy for exchanges (usually 30 to 90 days after
the sale). Proof of purchase may be required. Please check with the retailer for their specific
return policy regarding returns that are beyond the time set for exchanges.
The second option is to take or send the product (prepaid) to a Black & Decker owned or
authorized Service Center for repair or replacement at our option. Proof of purchase may be
required.Black & Decker owned and authorized Service Centers are listed under
"Tools-Electric" in the yellow pages of the phone directory.
This warranty does not apply to accessories. This warranty gives you specific legal rights
and you may have other rights which vary from state to state or province to province. Should
you have any questions, contact the manager of your nearest Black & Decker Service
Center. This product is not intended for commercial use.
FREE WARNING LABEL REPLACEMENT: If your warning labels become illegible or are
missing, call 1-800-544-6986 for a free replacement.
LATIN AMERICA: This warranty does not apply to products sold in Latin America. For
products sold in Latin America, check country specific warranty information contained in the
packaging, call the local company or see the website for warranty information.
Imported by
Black & Decker (U.S.) Inc.,
701 E. Joppa Rd.
Towson, MD 21286 U.S.A.
MODE D'EMPLOI
P P
E E
R R
C C
E E
U U
S S
E E
- -
T T
O O
U U
R R
P P
E E
R R
C C
E E
U U
S S
E E
- -
T T
O O
U U
R R
Merci d'avoir choisi Black & Decker!
Consulter le site Web
www.BlackandDecker.com/NewOwner
pour enregistrer votre nouveau produit.
À LIRE AVANT DE RETOURNER CE PRODUIT
POUR QUELQUE RAISON QUE CE SOIT :
Si des questions ou des problèmes surgissent après l'achat d'un produit Black & Decker,
consulter le site Web
HTTP://WWW.BLACKANDDECKER.COM/INSTANTANSWERS
pour obtenir des réponses instantanément 24 heures par jour.
Si la réponse est introuvable ou en l'absence d'accès à Internet, composer le
1-800-544-6986 de 8 h à 17 h HNE, du lundi au vendredi, pour parler avec un agent.
Prière d'avoir le numéro de catalogue sous la main lors de l'appel.
CONSERVER CE MANUEL POUR UN USAGE ULTÉRIEUR.
RÈGLES DE SÉCURITÉ GÉNÉRALES CONCERNANT LES
OUTILS À PILES
AVERTISSEMENT : LIRE, COMPRENDRE ET SUIVRE TOUTES LES DIRECTIVES
précisées ci-dessous afin d'éviter les risques de choc électrique, d'incendie ou de blessure
grave.
CONSERVER CES DIRECTIVES
Aire de travail
• Garder l'aire de travail propre et bien éclairée; les établis encombrés et les endroits
sombres sont propices aux accidents.
• Ne pas utiliser les outils électriques dans une atmosphère explosive, comme à
proxim0ité de liquides, de gaz ou de poussières inflammables; le moteur peut créer
des étincelles et enflammer les vapeurs ou les poussières environnantes.
• Tenir les enfants, les visiteurs ou toute autre personne à l'écart lorsqu'on utilise un
outil électrique; les distractions peuvent faire perdre la maîtrise de ce dernier.
Mesures de sécurité – Électricité
• Un outil à piles intégrées ou à bloc-pile externe doit être rechargé seulement au
moyen du chargeur approprié, car un chargeur destiné à une pile particulière peut
entraîner un risque d'incendie lorsqu'il est utilisé avec une autre.
• N'utiliser l'outil à piles qu'avec le bloc-pile désigné, car l'utilisation d'un autre type de
piles peut entraîner un risque d'incendie.
Sécurité personnelle
• Rester vigilant en tout temps et faire preuve de jugement lorsqu'on utilise un outil
électrique. Ne pas utiliser l'outil lorsqu'on est fatigué ou sous l'influence de
drogues, d'alcool ou de médicaments, car un moment d'inattention pourrait entraîner
des blessures graves.
CAUTION: The use of any accessory or attachment
See 'Tools-
Electric'
– Yellow Pages –
for Service &
Sales
N N
E E
V V
I I
S S
S S
A A
N N
S S
F F
I I
L L
P P
N N
E E
V V
I I
S S
S S
A A
N N
S S
F F
I I
L L
P P
D D
3 3
6 6
0 0
D D
3 3
6 6
0 0

Advertisement

loading
