CONTENTS o’s Page N Section Description 1. GETTING TO KNOW YOUR MACHINE 3 – 4 2. SAFETY REQUIREMENTS 3. SAFETY REGULATIONS 4 – 6 4. ELECTRIC CHAINSAW 6 – 9 5. MACHINE PARTS 6. OPERATING INSTRUCTIONS 10 – 16 7. MAINTENANCE 16 –... -
Page 3: Getting To Know Your Machine
1. GETTING TO KNOW YOUR MACHINE 1.1. How to read the manual. 1.1.1. Certain paragraphs in the manual contain particularly significant information and are marked with various levels of highlighting with the following meaning: Non- observance Indicates a hazard NOTE or Non-observance Read Manual will result in the... -
Page 4: Safety Requirements
1.4.1.1.7. Using the machine while fasten to fixed supports. 1.4.2. Improper use of the machine will invalidate the warranty, relieve the manufacturer from all liabilities, and the user will consequently be liable for all and any damage or injury to himself or others. - Page 5 3.1. GENERAL POWER TOOL SAFETY 3.1.1. Work area safety. 3.1.1.1. Keep work area clean and well lit. Cluttered or dark areas invite accidents. 3.1.1.2. Do not operate power tools in explosive atmospheres’, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
-
Page 6: Electric Chainsaw
3.1.4.4. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. 3.1.4.5. Maintain power tools. - Page 7 4.1.8. Carry the chain saw by the front handle with the chain saw switched off and away you’re your body. When transporting or storing the chain saw always fit the guide bar cover. Proper handling of the chain saw will reduce the likelihood of accidental contact with the moving saw chain.
- Page 8 4.5. Recommendations for first time users. 4.5.1. Before felling or de-limbing for the first time make sure; 4.5.1.1. You have been specifically trained to use this type of equipment; 4.5.1.2. You have carefully read the safety regulations and user instructions contained in this manual;...
-
Page 9: Machine Parts
4.7.1.13. Check the battery charger cable is not damaged on a regular basis. If the cable gets damaged, the whole battery charger must be replaced. 4.7.1.14. Recharge the batteries completely before storing them away in winter. 4.7.1.15. The battery can only be charged by charger comply with EN60335-2-29. 5. -
Page 10: Operating Instructions
6. OPERATING INSTRUCTIONS Mount the components very carefully so as not to impair the safety and efficiency of the machine. If in doubt, contact your dealer. Unpacking and completing the assembly should be done on a flat and stable surface, with enough space for moving the machine and its packaging, always making use of suitable equipment. - Page 11 6.2.1.3. Mount the bar (2) inserting the stud bolt in the bar’s hole using the tension adjuster (2a); move the bar towards the back of the machine body (Fig. 3). 6.2.1.4. Wind the chain around the drive sprocket (Fig. 4) and push the bar forward to achieve an initial tensioning of the chain.
- Page 12 6.3.3.2. When the switch lever is released, a brake is automatically activated that slows and stops chain movement, in order to prevent the risk of injury should the chain continue to turn after it has been switched off? 6.3.3.3. In the event of a kickback while working, following an irregular contact of the tip of the bar, with a brusque upward movement that causes the hand to strike the front guard.
- Page 13 6.4.2. To recharge the battery, 6.4.2.1. Connect the battery charger (1) to a mains power socket; a green power light (3) will come on indicating there is voltage. 6.4.2.2. Insert the battery pack (2) into the battery charger (1), pushing it in completely. Recharging a completely flat battery requires approximately 100 minutes.
- Page 14 6.7.1.2. To start the machine; 6.7.1.2.1. Take off the bar cover. 6.7.1.2.2. Make sure the bar is not touching the ground or any other object. 6.7.1.2.3. Disengage the chain brake (5) by pulling the front hand guard towards the front handgrip. 6.7.1.2.4.
- Page 15 Always remember that an incorrectly used chain-saw may disturb others and have a serious impact on the environment. To respect people and the environment; Avoid using the machine in environments or at times of the day when it may disturb others. You MUST comply with local regulations and provisions for the disposal of waste materials after sawing.
- Page 16 6.10. Directions for use. Always hold the machine with both hands when sawing. Stop the motor immediately if the chain stops during sawing. Beware of kickback, which can occur if the bar contacts an obstacle. Be careful of where the branches are lying on the ground, the risk of them being under tension, the direction the branch may go during cutting and the risk of the tree being unstable after the branch has been cut.
-
Page 17: Maintenance
7. MAINTENANCE During maintenance, remove the battery from its compartment. Use protective gloves when handling the bar and chain. Keep the bar protection devices on, except when intervening directly on the bar or the chain. Never dispose of oils or other polluting materials in unauthorised places. For your safety and that of others you must follow the following instructions. -
Page 18: Maintenance
7.6.2. A specialized centre will sharpen the chain using the right tools to ensure minimum removal of material and even sharpness on all the cutting edges. 7.6.3. If you sharpen the chain yourself, use special round-section files with the right diameter. Depending on the type of chain (see “Chain Maintenance Table”). - Page 19 7.8.2.4. With a flat file, remove burrs from edges and level, off guides. 7.8.3. Replace the bar whenever (Fig. 18); 7.8.3.1. The groove is not as deep as the height of the drive links (which must never touch the bottom); 7.8.3.2.
- Page 20 7.12. Chain sprocket (Fig 19). 7.12.1. Regularly check the condition of the sprocket and replace it when wear exceeds 0.5 mm. 7.12.2. Do not mount a new chain with a worn sprocket or vice-versa. Page 20 Rev 2...
-
Page 21: Troubleshooting
Charger. charge the battery (no red led on). Defective battery charger Replace with original spare part. 9. SPECIFICATION HYC36Li Chainsaw Battery charger supply vac/hz 230/50 Battery type Samsung Lithium ion Battery voltage vdc Battery capacity Ah... -
Page 22: Contact Details
10.3. Reduce – Reuse - Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. 10.4. -
Page 23: Declarations Of Conformity
12. DECLARATIONS OF CONFORMITY 12.1. Genpower Ltd confirms that this Hyundai product conform to the following CE Directives; 12.1.1. 2006/42/EC Machinery Directive 12.1.2. 2004/108/EC EMC Directive 12.1.3. 2000/14/EC, Amended by 2005/88/EC (as amended) Page 23 Rev 2... - Page 24 GENPOWER LTD Isaac Way, London Road Pembroke Dock, UNITED KINGDOM, SA72 4RW T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198 info@hyundaipowerequipment.co.uk www.hyundaipowerequipment.co.uk...
