Oki C 5400 Option Installation Manual

C5150/C5200/C5400/C5400n

Duplex Option

Installation Instructions

Install the Duplexer

1. Unpack the duplexer and remove
the shipping materials.
2. Turn off the printer.
3. Insert the duplexer through the
hinged door in the back of the
printer.
4. Turn on the printer.
5. Print out the Menu Map.
B E
ACK NTER
M
ENU
+
a. Press one or more times until
INFORMATION MENU
on the display.
b. Press twice.
ENTER
The MenuMap prints.
6. Check to be sure that "DUPLEX
installed" shows in the information
at the top of the first page. If it
doesn't, turn off the printer and
push firmly on the duplexer to be
sure it is firmly seated in the
printer, then turn on the printer and
print the MenuMap again.
© 2004 Oki Data Americas, Inc.
Oki 42158411 Duplex Unit
7. If you will always be using duplex
printing, go into the printer menu
and change the default setting for
DUPLEX to ON:
a. Press
MENU
b. Press
c. Press
on the display.
d. Press
e. Press
from
f. Press
setting, then press
save the setting and exit the
menu.
Activate the
Duplexer in the

Printer Driver

Windows
O L
N INE

PCL Driver (C5400, C5400n)

C
ANCEL
Start → Settings → Printers
Click
[
Printers and Faxes
The Printers (Printers and Faxes)
dialog box opens.
appears
8. Right click the PCL printer icon,
then click
9. Click the
10.Click
Duplex Option Unit
11.Click
OK
(Printers and Faxes) dialog box.
Postscript Emulation Driver
(C5400n)
Start → Settings → Printers
1. Click
[
Printers and Faxes
The Printers (Printers and Faxes)
dialog box opens.
+
until you see
PRINT
on the display.
.
ENTER
+
until you see
DUPLEX
.
ENTER
+
to change the setting
to .
OFF ON
to engage the
ENTER
to
ON-LINE
®
for XP].
Properties
tab.
Device Option(s)
.
, then close the Printers
for XP].
2. Right click the Postscript
emulation printer icon, then click
.
Properties
3. Next:
– Windows XP, 2000 and NT 4.0:
click the
Device Settings
– Windows Me and 98: click the
Device Options tab.
4. Under
Installable Options
and select
Duplex Installed
5. Click , then close the Printers
OK
(Printers and Faxes) dialog box.

Hiper-C Driver (C5150, C5200)

Start → Settings → Printers
1. Click
[ for XP].
Printers and Faxes
The Printers (Printers and Faxes)
dialog box opens.
2. Right click the printer icon, then
click .
Properties
3. Next:
– Windows XP, 2000 and NT 4.0:
click the
Device Option(s)
– Windows Me and 98: click the
tab, then click
Printer Properties
the tab.
Device Option
4. Select Duplex Option Unit
5. Click OK , then close the Printers
(Printers and Faxes) dialog box.
®
Macintosh

OS 8.x and 9.x (C5400n)

1. Activate from the Apple
Chooser
menu.
2. Select LaserWriter 8 .
Printer → Setup
3. Click .
4. Click .
Configure
5. Change the
Duplex Unit
Installed .
6. Click twice.
OK
7. Close .
Chooser

OS X to X.1 (C5400n)

No activation is required.
(continued on back)
tab.
, click
.
tab.
.
setting to
58368601
