Semiconductor
VoiceKit2000
Hardware and Software Instruction Manual
Web Link to this product:
http://www.oki.co.jp/semi/english/vk2000.htm
1. PRODUCT DESCRIPTION
VoiceKit2000, hereafter referred to as VK2000, is a printed circuit board designed for the purpose of
demonstrating a selection of OKI Electric's speech LSIs in conjunction with an IBM PC/AT compatible
personal computer running Windows 95/98
strate, a controller circuit and a battery pack case. Connections are provided for a microphone, two
speakers (all
3.5mmØ)
Delivery includes:
• VoiceKit2000 board, battery case attached
• Control software for Windows 95/98
• RS232C cable (a male end to VK2000,
a female end to the host PC)
• This instruction manual
• Loudspeaker x 1
• Microphone x 1
• Four LR6/1.5V alkaline batteries
Mounted Speech LSIs:
• ML2500
Analog storage recorder LSI with internal 1 megacell flash memory
• MSM9888L ADPCM recorder LSI with external 4 megabit Oki Serial Voice Flash
• MSM9841
ADPCM recorder LSI with FIFO buffer and DMA interface
• MSM66P56 ADPCM/PCM speech synthesis LSI with internal 2 megabit OTPROM
• MSM9831
PCM speech synthesis LSI with internal 384 kilobit ROM
• MSM6722
Voice pitch control LSI, within one octave control range
2. NOTICE
The manufacturer of VK2000 assumes that the user is well familiarised with the use of PCs and the
®
Windows 95/98
operating system. It is of further advantage to be familiar with the essential functions of
each speech LSI on the VK2000 board. For details please ask for the latest data sheets or visit our website
product page:
where you will also find updates of the VK2000 control software and its (this) instruction manual in
®
Adobe's Acrobat
format.
and a 9-pin serial interface connector.
®
http://www.oki.co.jp/semi/english/vk2000.htm
homepage:
Specification are subject to change without notice.
®
. The board includes six different speech LSIs to demon-
Board dimensions:
• 120(W) x 130(L)mm
http://www.oki.co.jp/semi/
Version number: 1.10
Issue: October, 1999
Replaces version: n/a
Author Code: J595RB
Advertisement
Related Manuals for Oki VK2000
Summary of Contents for Oki VK2000
- Page 1 Windows 95/98 operating system. It is of further advantage to be familiar with the essential functions of each speech LSI on the VK2000 board. For details please ask for the latest data sheets or visit our website product page: where you will also find updates of the VK2000 control software and its (this) instruction manual in ®...
-
Page 2: System Requirement
MSM9841 mode only. 5. SOFTWARE INSTALLATION AND REMOVAL Control software for VK2000 comes on two floppy disks. Insert disk 1/2 and select SETUP.EXE from the Program Manager. Double click and simply follow the instructions of the setup program. The soft- ware can be uninstalled using the Windows control panel (Add/Remove Programs). -
Page 3: Getting Started
6. GETTING STARTED Connect VK2000 firmly to a free serial port of the PC. Double-click on the program icon to start the control software which will come up with the screen pictured below for the selection of the serial port. - Page 4 7.1. L2500 (Full part number ML2500) Analog storage recorder LSI with internal 1 megacell flash memory. The voice quality of ML2500 is representative for all Oki analog storage recording LSIs. Recording 1. Select the number of phrases (recording channels from 1 to 16) into which you would like to split the recording memory.
- Page 5 VK2000 Semiconductor 7.2. M9888L (Full part number MSM9888L) ADPCM recorder LSI with external 4 megabit Oki Serial Voice Flash. Playback from LSI-internal Mask ROM MSM9888L contains a 512KBit ROM which is programmed with sample sounds. Select a sample from the combo box in the Phrase Address Table frame and click on PLAY. Or click on one of the SAMPLE buttons to listen.
- Page 6 VK2000 Semiconductor 7.3. M9841 (Full part number MSM9841) ADPCM recorder LSI with FIFO buffer and DMA interface. Recording If the device is still unrecorded, the combo box labelled “Phrase No” shows 01. It will automatically increment as the RECORD button is clicked.
- Page 7 VK2000 Semiconductor 7.4. M66P56 (Full part number MSM66P56) ADPCM/PCM speech synthesis LSI with internal 2 megabit OTPROM. Playback 1. Select a Phrase Table 2. Select the desired phrase from the associated combo box. 3. Click on PLAY 4. Click on STOP, if you wish to terminate before playback end automatically.
- Page 8 VK2000 Semiconductor 7.5. M9831 (Full part number MSM9831) PCM speech synthesis LSI with internal 384 kilobit ROM. Playback of pre-recorded samples 1. Select the Phrase Table frame 2. Select the desired phrase from the associated combo box. 3. Click on PLAY 4.
- Page 9 VK2000 Semiconductor 7.6. M6722 (Full part number MSM6722) Voice Pitch Controller LSI within one octave control range. The MSM6722 has no recording and playback function. It shifts your voice coming from the micro- phone in real-time within an octave up or down.
- Page 10 Oki assumes no responsibility or liability whatsoever for any failure or unusual or unexpected operation resulting from misuse, neglect, improper installation, repair, alteration or accident, improper handling, or unusual physical or electrical stress including, but not limited to, exposure to parameters beyond the specified maximum ratings or operation outside the specified operating range.
- Page 11 ADDRESSES & SEMICONDUCTOR WEB SITES OKI Electric Industry Co., Ltd., Device Business Group, 10-3, Shibaura, 4-chome, Minato-ku, Tokyo 108, Japan, Tel.: +81-(0)3-5445-6327, Fax.: +81-(0)3-5445-6328, http://www.oki.co.jp/semi/ OKI Semiconductor Company, 785 North Mary Avenue, Sunnyvale, CA 94086, U.S.A., Tel.: +1-408-720-1900, Fax.: +1-408-720-1918, http://www.okisemi.com/...
