Hard Disk Drive (HDD)

Installation Instructions

HDD PART NUMBER
70043501

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70043501 and is the answer not in the manual?

Questions and answers

Summary of Contents for Oki 70043501

  • Page 1: Installation Instructions

    Hard Disk Drive (HDD) Installation Instructions HDD PART NUMBER 70043501...
  • Page 2 Every effort has been made to ensure that the information in this document is complete, accurate, and up-to-date. Oki Data assumes no responsibility for the results of errors beyond its control. Oki Data also cannot guarantee that changes in software and equipment made by other manufacturers and referred to in this guide will not affect the applicability of the information in it.
  • Page 3: Prepare The Printer

    Prepare the Printer 1. First: • Turn off the printer (1). • Unplug the power cord (2). • Detach the interface cable—USB, parallel, or Ethernet—from the back of the printer (3).
  • Page 4 2. Open the top cover. 3. Loosen the thumbscrew holding the printer side cover in place.
  • Page 5 4. Open the front cover. 5. Lift up on the ends and remove the side panel from the printer.
  • Page 6: Install The Hard Disk Drive

    Install the Hard Disk Drive (HDD) 1. Locate the drive connector ( 1 ) on the control board: 2. Remove the HDD from its shipping package.
  • Page 7 3. Insert the HDD cable firmly into the connector.
  • Page 8 4. Mount the HDD: place the HDD in the slots on the bracket, then push the handle against the HDD to lock it in place.
  • Page 9: Complete The Installation

    Complete the Installation 1. Replace the side panel on the printer and secure it in place with the thumbscrew. 2. Close the front cover and the top cover. 3. Reattach the interface cable. 4. Plug in the power cord and turn on the printer.
  • Page 10: Check For Proper Installation

    Check for Proper Installation Generate a MenuMap printout: 1. Press one or more times until INFORMATION MENU 2. Press ENTER The MenuMap prints. 3. Check the top section of the MenuMap printout to verify that it shows “HDD: installed.” 4. If “HDD: uninstalled” still appears, remove the printer’s side panel and make sure the connection between the HDD and the printer is secure, then replace the side panel and print...
  • Page 11 Activate the Hard Disk in the Print Driver Windows Postscript Emulation Driver, C5300/C5400n 1. Click Start → Settings → Printers [Printers and Faxes for XP]. 2. Right click the Postscript emulation printer icon, then click Properties. Windows XP, 2000 and NT 4.0: a.
  • Page 12 PCL Driver, C5300/C5400/C5400n 1. Click Start → Settings → Printers [Printers and Faxes for XP]. 2. Right click the PCL printer icon, then click Properties. 3. Click the Device Option tab. 4. Click Printer Hard Disk. 5. Click OK, then close the Printers (Printers and Faxes) dialog box.
  • Page 13 OS X to X.1 No activation is required. OS X.2 1. Activate Print Center from Local Hard Drive → Applications → Utilities → Print Center. 2. Highlight the printer name and select from the menu Printers → Show Info. 3. Click the box next to Hard Disk to enable the option.
  • Page 14: Limited Warranty

    Limited Warranty. Oki Data will repair (or at its option, replace) at no charge, any defective part(s) of the OPTION for one (1) year from the date of purchase. This Limited Warranty extends to the original pur- chaser only.
  • Page 15 YEAR. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. OKI DATA SHALL NOT BE RESPONSIBLE OR LIABLE FOR ANY SPECIAL, INCIDEN- TAL OR CONSEQUENTIAL DAMAGES OR LOSS ARISING FROM THE USE OF THIS PRODUCT.
  • Page 16 Additional information on obtaining service under this Limited Warranty is available by con- tacting the Oki Data dealer from whom the prod- uct was purchased, by contacting Oki Data directly at 1-800-654-3282 (1-800-OKI-DATA, U.S. and Canada) or at 1-856-222-5276 (Spanish only), or by contacting one of the listed service locations.
  • Page 17 2735 Matheson Blvd. East, Unit 1 Mississauga, Ontario Canada L4W 4M8 Tel: 1-800-654-3282 Fax: 1-905-238-4427 Mexico Oki Data de Mexico, S.A. de C.V. Mariano Escobedo No. 748 - 8 Piso Col Anzures, e.p. 11590 Mexico, DF Tel: 52-555-263-8780 Fax: 52-555-250-3501...
  • Page 18 Brazil Oki Data do Brasil, Ltda. Rua Alexandre Dumas, 2220 - 8 andar Chácara Santo Antonio São Paulo 04717-004, Brasil Support Center: 0800-11-55-77 e-mail: okidata@okidata.com.br Tel: 55 11-3444-3500 Fax: 55 11-3444-3501...
  • Page 20 Oki Data Americas, Inc. 2000 Bishops Gate Blvd. Mt. Laurel, NJ 08054-4620 Phone: (800) 654-3282 FAX: (856) 222-5320 www.okidata.com 59359001...
