ES3640e MFP Software Installation Guide
About this Guide
This guide describes the initial printer driver
installation. For more detailed information, refer to
the EFI User Software Installation Guide and EFI
Configuration Guide provided on the User
Documentation CD (CD3).
The general steps for installing the software are as
follows:
• Install the PostScript or PCL printer driver and
corresponding printer driver files.
• Set up the printer driver to communicate with
the Fiery.
• Install Fiery utilities and user software.
• Configure Fiery utilities and user software.
You must also configure either a local connection
for printing directly to your printer or a network
connection for printing over a network.
A full set of user documentation, where
procedures are described in detail, is provided on
the User Documentation CD (CD3).
Service and Support
• Consult the dealer where you purchased your
system.
• Visit our web site: http://my.okidata.com
NOTE
®
TCP/IP Network Installation ..... 2
Novell Installation ...................................... 7
®
Installation .............................. 8
OS 9.1 to 9.2.x ....................................... 8
OS X.1+ to X.3+................................... 10
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Oki ES3640 MFP
Summary of Contents for Oki ES3640 MFP
- Page 1 About this Guide This guide describes the initial printer driver installation. For more detailed information, refer to the EFI User Software Installation Guide and EFI Configuration Guide provided on the User Documentation CD (CD3). The general steps for installing the software are as follows: •...
-
Page 2: Selecting A Printer Driver
CAUTION! Do not connect this product to an uninterruptible power supply (UPS). For further information please contact Oki Data at 1-800-OKIDATA or http://my.okidata.com. Be sure to use the 15A AC power cord supplied with the printer. Use of a power... - Page 3 Network Installation (cont’d) 1 Assign an IP address to the MFP If you are not using DHCP, you need to obtain an IP Address from your network Administrator and enter it using the front panel: 1. Confirm that the printer displays [ Ready to print 2.
- Page 4 The LPR Utility is automatically installed with the network printer driver. To discover the printer, do the following: 1. Click Start → Programs → Oki Data → Oki Data LPR Utility. 2. Click Remote Print. Then, click Add Printer. 3. Select your printer model from the drop-down...
-
Page 5: Activating Options
Two-Way Communication feature to configure the options automatically. To Configure Options Manually 1. Click Start → Settings → Printers. 2. Right-click the OKI ES3640e MFP EFI Fiery icon. 3. Click Properties. 4. Click the Installable Options tab. - Page 6 Network Installation (cont’d) 3. Click Properties. 4. Click the Installable Options tab. 5. Select Two-Way Communications. 6. Type the Fiery IP address or DNS name. 7. To display the printer’s current default settings when opened, select Update Fiery Driver When Opened. 8.
-
Page 7: Install The Utility
Novell 1 Install the Utility This utility installs, configures, and manages Oki network print server devices. 1. Insert the printer driver CD (CD1) into your CD-ROM drive. The CD will autorun. If it doesn’t autorun, click Start Browse. Browse to your CD-ROM drive. -
Page 8: Macintosh Installation
1. Turn the MFP ON, then turn the computer ON. 2. Insert the printer driver CD (CD1) into your CD-ROM drive. 3. Double-click the OKI CD icon that appears on the desktop. 4. Double-click the MAC icon. 5. Double-click Installer for MAC OS 9. - Page 9 OS 9.1 to 9.2.x (cont’d) 4 Install the EFI Fiery Utilities 1. Place EFI Utilities CD (CD2) in the CD-ROM drive. 2. Double-click the OKI CD icon that appears on the desktop. 3. Double-click the MAC icon. 4. Double-click User Software.
-
Page 10: Os X.1+ To X.3
1. Turn the MFP ON, then turn the computer ON. 2. Place the CD supplied with the MFP in the CD-ROM drive. 3. Double-click the OKI CD icon that appears on the desktop. 4. Double-click the MAC icon. 5. Double-click the MAC OS X icon. - Page 11 ® OS X.1+ to X.3+ (cont’d) 4 Install the User Documentation For additional information on using MFP features as well as MFP utilities, see the on-line documentation. Requirements • Microsoft Internet Explorer version 4.0 or higher and Acrobat Reader. To Load In order to open the on-line documentation, you must have Acrobat Reader installed.
- Page 12 Electronics for Imaging, Inc., products or software. Oki Data Americas, Inc., 2000 Bishops Gate Blvd., Mt. Laurel, NJ 08054-4620 Tel: 1-800-654-3282 (856) 235-2600 Fax: (856) 222-5320 http://my.okidata.com ©...
