OWNER'S MANUAL SUPPLEMENT FOR
THE TORQUE
Read this manual carefully before operating your new Torque Kayak. Retain for
future reference. In addition, it is important that you follow all applicable boating
regulations. Make sure you consult your dealer or State for details.
Minn Kota Saltwater Trolling
Motor with 36# Thrust
Can be easily removed for
transport or storage
Back-up Paddle
Storage
Extra-large Rudder
Designed to optimize
steering when motor
is in use
125 Gilman Falls Ave, Bldg B, Old Town, ME 04468 USA
CAUTION
100% Sealed
Connections
Prevents corrosion
and short circuits
www.oceankayak.com • 800-8-KAYAKS
Battery Box
Battery not
included
Kill Switch
Infinitely Variable
Speed Control
Allows you to find the
perfect speed for trolling
Advertisement
Related Manuals for Ocean Kayak TORQUE
Summary of Contents for Ocean Kayak TORQUE
- Page 1 OWNER’S MANUAL SUPPLEMENT FOR THE TORQUE Read this manual carefully before operating your new Torque Kayak. Retain for future reference. In addition, it is important that you follow all applicable boating regulations. Make sure you consult your dealer or State for details.
-
Page 2: Table Of Contents
• Check your equipment prior to use and always make sure you have safety equipment on board (including a spare paddle). • Never consume alcohol or drugs prior to or during use. • Children should only use this kayak under active adult supervision. • Always have a U.S. Coast Guard approved personal flotation device (PFD) while on board. Children must always wear a PFD. • Do not exceed the recommended capacity of this kayak: 350-400 lbs [158.8-181.4 kg]. MoTor safeTy Guidelines • WarninG: avoid running the motor aground. This could cause damage to motor and/or propeller. • Always have motor cut-off (kill switch) bungee attached to operator. • When not in use, leave motor cut-off in place to prevent battery drainage. • Rinse exterior of boat and motor after use in salt water. • The motor features a sacrificial zinc anode to fight galvanic corrosion. The replaceable anode is conveniently mounted on the prop hub and provides for better protection and longer motor life. Replace anode if it is more than 50% consumed. • Avoid contact with propeller when under power. • Do not exit the kayak when in use or use in the vicinity of swimmers. • Avoid use in shallow water as propeller or motor damage can occur. GeTTinG sTarTed sTeP 1: Make sure speed control dial is in the off position before inserting battery or motor. sTeP 2: Place battery into battery box. -
Page 3: Battery Information
• Follow instructions on your battery charger. • It is strongly recommended to remove the battery from the boat during recharging and transport. If you charge the battery while it is in the craft, be sure to have the battery compartment open and the battery well ventilated. • Unplug the charger before connecting the battery to the charger. • WarninG: Be sure that all electrical connections are not in contact with water as this could result in shock or electrocution. MaxiMizer/dePTh finder inTerferenCe The built-in Maximizer’ s solid state electronics create pulse width modulation to provide longer running time and extended battery life. With the Torque’ s Maximizer speed control, you may, in single battery applications, experience some interference in your depth finder display due to RF (radio Frequency) or electrical interference. If interference does occur, call customer service for our document that has a few steps to reduce or eliminate the interference problem or download the file from the Torque’ s website page under the features tab at: http://www.oceankayak.com/kayaks/angler_editions/torque.html. MainTenanCe 1. A fter use, the motor unit should be rinsed with fresh water, then wiped down with a cloth dampened with an aqueous based silicone spray. 2. T he propeller must be cleaned of weeds and fishing line. The line can get behind the prop, wear away the seals and allow water to enter the motor. Check this after every 20 hours of operation. -
Page 4: Replacement Parts
• Tighten motor tie down strap to reduce vibration. • Remove and rotate the prop 180 degrees. See propeller replacement instructions on page 5. • If prop is damaged replace with the MKP- prop kit (see page 5). for all other techincal questions and concerns, contact ocean Kayak customer service at 800-8-KayaKs or service@oceankayak.com. freQuenTly asKed QuesTions i pulled my kill switch and my battery died overnight, what happened? The kill switch is not designed as an on/off switch but as an emergency kill switch. It is recommended to disconnect the battery for any prolonged... -
Page 5: Frequently Asked Questions
What do i do if i experience prop vibration? Props and shafts are not 100% symmetrical. Often times simply removing the prop, rotating it 180 degrees, and reinstalling it will lessen or eliminate the incidence of vibration. how fast can the Torque go? The maximum speed is 5.5 mph. Why is the rudder on the Torque extra large? The rudder is designed to optimize steering when the motor is in use. It allows for precise positioning, a tight turning radius, responsive steering and total hands-free control. Can the Torque be paddled without the motor? Yes, a skeg plug is included with the Torque kayak and can be placed in place of the motor unit. This lowers the weight of the kayak to 75 lbs. and allows it to...
