OWNER’S MANUAL Safety First! Read and become familiar with this entire manual. 1-888-775-1330 Please retain this manual for reference Tabletop Heater Distributed by: RTA International Youngtown, AZ 85363... -
Page 2: Table Of Contents
OWNER’S MANUAL Read These Safety Instructions... Contents Breakdown... Screw Packing List... Assembly Procedure... Assembly... Safety First... Tabletop Heater Location... Checking For Leaks... Before Operating... Operating... After Operating... Maintenance... Storage... Troubleshooting... All rights reserved No part of this manual may be... -
Page 3: Read These Safety Instructions
OWNER’S MANUAL READ THESE SAFETY INSTRUCTIONS If you smell gas Shut off gas to the appliance Extinguish any open flame Open lid If odor continues immediately call your Gas supplier or your life Department Failure to comply with these instructions could result in a fire or explosion that could cause serious bodily injury death or property damage Only to be used outdoors... -
Page 4: Contents Breakdown
OWNER’S MANUAL CONTENTS BREAKDOWN... -
Page 5: Screw Packing List
OWNER’S MANUAL Item Item M6 Castle nut Reflector Ø6mm Washer Emitter screen Guard Door Plate Base Cast Iron M6×15mm bolt 10 3/16" bolt Item M6 Castle nut Ø6mm Washer M6×15mm bolt 3/16" bolt Tools needed: ( not included) Adjustable opening wrench (2) 20 cm long Slip joint pliers 23 cm long Philips screwdriver w/medium blade Teflon plumbing tape for joints... -
Page 6: Assembly
OWNER’S MANUAL STEP 1 1-1. Take out all the parts of the tabletop Heater. 1-2. Aim the cast iron at the holes on the base. STEP 3 3-1. Put the burner on the tank housing then fix them with 4pcs 3/16” bolts. - Page 7 OWNER’S MANUAL STEP 5 5-1. Fix 3pcs pins of 60mm length to the emitter screen with 3pcs M6 flange nuts then tighten them. STEP 7 7-1. Put the guard on the burner through the emitter screen. 7-2. Put the ends of the guard into the holes of the burner.
- Page 8 OWNER’S MANUAL STEP 9 9-1. Put the reflector through the pins and on the washers. STEP 11 11-1. Turn off the control knob of the burner. 11-2. Fix the 1.02Lbs gas tank (not included) to the regulator (rotate the gas tank clockwise toward the regulator tighten it).
-
Page 9: Safety First
OWNER’S MANUAL Read and become familiar with this entire manual, especially the following precautions . Caution: this appliance is for outdoor use only(outside any enclosure) Always make sure there is fresh air ventilation. Use only outdoors in a well-ventilated space, never use in a building, garage or any other enclosed area. -
Page 10: Tabletop Heater Location
OWNER’S MANUAL TABLETOP HEATER LOCATION ● The tabletop heater is primarily for outdoor use only. Always ensure that adequate fresh air ventilation is provided. ● Always maintain proper clearance to combustible materials, i.e. top 45 cm(18”) and sides 60 cm(24”) minimum. -
Page 11: Operating
OWNER’S MANUAL Heater is on a hard and level surface. There are no signs of spider or insect nests. All burner passages are clear. All air circulation passages clear. Children, pets, clothing, flammable materials and items that can be damaged from radiant heat are away from the heater. Children and adults in the area have been alerted to the high temperature hazards: especially burns and clothing fires. - Page 12 OWNER’S MANUAL Lighting 1. Turn Gas control knob to “Off” position. 2. Push in and rotate the Control Knob to“Pilot”position. Depress igniter button. 3. Once burner is lit, hold Control Knob in for at least 30 seconds and release. 4. If burner does not stay lit, turn to“Off” position and wait 5 minutes and repeat 2 and 3.
-
Page 13: After Operating
Gas control is in OFF position. Disconnect Gas line. Heater is upright in a secure location. To enjoy years of outstanding performance from your heater, make sure you perform the following maintenance activities on a regular basis: Inspect the visible portion of the hose before each use of the appliance. -
Page 14: Troubleshooting
