NTM SERIES
TWIN MOTORS
RANGE HOOD
The NTM Series Twin Motors Range Hood meets the
professional cooking needs of the serious at home
chef. Its rounded edges and sleek design compliments
any modern decor.
FEATURES
• 3-speed control panel with easy push button controls
• Rounded edges for contemporary look
• Smooth surfaces and fully enclosed underside make
cleaning easy
• Enclosed 120 V 40 W appliance bulb illuminates cooking
surface (bulb not included)
• Grease capture design system includes grease pan and
two grease guard cups that remove quickly for cleaning
• Unit has 3-ducting options - 3 1/4" x 10" (83 mm x 254 mm)
horizontal - vertical and 6" (152 mm) round vertical
(dampers and adapters included)
• Triple speed twin fan motors
• Available in 30" width, white and stainless steel
1 year warranty
HVI-2100 CERTIFIED RATINGS comply with new testing technologies and procedures
prescribed by the Home Ventilating Institute, for off-the-shelf products, as they are
available to consumers. Product performance is rated at 0.1 in. (2.54 mm) static
pressure, based on tests conducted in AMCA's state-of-the-art test laboratory. Sones
are a measure of humanly-perceived loudness, based on laboratory measurements.
Broan-NuTone Canada Inc., 1140 Tristar Drive, Mississauga, Ontario, Canada L5T 1H9 (1-888-882-7626)
REFERENCE
QTY.
*
PRODUCT SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
TYPICAL SPECIFICATION
The Range Hood shall be NuTone NTM Series.
It shall be available in a 30" (762 mm) width. The Range
Hood shall be available in a white finish and a stainless
steel finish.
Unit shall have a built-in back draft damper and be ducted to
exterior of dwelling either horizontally or vertically.
Unit shall have three fan speed push-button controls, a light
push-button control and an on/off push-button control.
Unit shall have 2 triple speed fan motors.
Maximum air delivery shall be no less than 500 CFM
(236 L/s) and sound levels no greater than 4.1 Sones (3
1/4" x 10" vertical discharge). All air and sound ratings shall
be certified by HVI.
Units shall be CSA certified.
REMARKS
SPECIFICATION SHEET
Project
Location
Architect
Engineer
Contractor
Submitted by
Date
NTM30WHd050615
