1068 / 1035 series recessed mount medicine cabinets

Advertisement

Quick Links

MODEL 1068 / 1035 SERIES
RECESSED MOUNT
MEDICINE CABINETS
Standard builder models - for recessed installation -
Frameless beveled and polished edge swing doors
FEATURES
Recessed installation for standard wall openings
Easy to clean, one piece, heavy gauge steel construction
Full length Interior door mirror
Plate glass exterior mirror with polished or beveled edge
mirror
Rust resistant
Adjustable steel, glass or dimensional shelves
Full piano hinge
Reversible for left-hand or right-hand door opening
Includes mounting hardware
MODEL
WALL OPENING
NO.
A
1068P24WH
14
1068P34WH
14
1035P24WH
14
1035P34WH
14
Add "G" to indicate glass shelves
Add "D" to indicate dimensional shelves
REFERENCE
QTY.
OVERALL SIZE
B
C
D
24
3-1/2
16
34
3-1/2
16
24
3-1/2
16
34
3-1/2
16
Broan-NuTone LLC, 501 S. Wilhite Street, Cleburne, TX 76031 (1-800-325-8351)
REMARKS
TYPICAL SPECIFICATION
Medicine cabinet shall be NuTone 1068/1035 frameless mirror
series.
Recessed medicine cabinet shall be of one-piece, heavy gauge
steel construction finished in Powder Coated white paint after
forming.
Cabinet shall have full piano hinge and an innovative rubber
magnet and body bumper.
Each cabinet shall include three (24") or four (34"), adjustable
metal pre-painted, glass or dimensional series 1/2 shelves.
Cabinet shall be reversible for left-hand or right-hand installation.
Plate glass mirror shall have 1/2" bevel on all sides or all four
edges polished with full length interior door mirror.
MIRROR
TYPE
E
26
Beveled Edge
36
Beveled Edge
26
Polished Edge
36
Polished Edge
Project
Location
Architect
Engineer
Contractor
Submitted by
SPECIFICATION SHEET
Date
80-121-01B
