NuTone 401ADJ Specification Sheet

STYLELINE SERIES
MOLDED BATH
CABINETS
Standard builder models - for recessed and
surface mount installation
FEATURES
•
Easy to clean, one-piece, injection-molded
polystyrene construction
•
Glass Mirror
•
Stainless steel frame
•
Butt hinge
•
Polystyrene shelves (fixed or adjustable)
•
Reversible - for left-hand or right-hand
door opening
•
Includes mounting hardware
RECESSED CABINETS
MODEL OVERALL SIZE
NO. A B C
401ADJ 16 20 3 3 /
407ADJ 16 22 3 3 /
624 16 26 4 1 /
SURFACE MOUNT CABINET
MODEL BODY SIZE
NO. A B
5 5
614 15 / 19 /
8 8
Broan-NuTone Storage Solutions, 501 S. Wilhite Street, Cleburne, TX
REFERENCE
WALL OPENING
D E F SHELVES
14 18 2 1 / 2 (adj)
4 2
14 18 2 1 / 2 (adj)
4 2
13 7 / 23 7 / 2 7 / 3 (fi xed)
2 8 8 8
OVERALL SIZE
C D E F
5 1 1 1
3 / 16 / 22 / 4 /
8 4 4 4
QTY. REMARKS
TYPICAL SPECIFICATION
Bath cabinet shall be NuTone Styleline Series Model
401ADJ, (407ADJ), (614) and (624).
Bath cabinet shall be of one-piece, injection-molded
polystyrene construction.
Glass mirror shall have full surround of stainless steel
frame with spring clip closure (401ADJ & 407ADJ) or
screw closure (614 & 624). Door back shall be fitted
tight within the frame and finished in white.
Cabinet shall have butt hinges.
Cabinet shall be reversible for left-hand or right-hand
installation.
A
B
SHELVES
C
2 (fi xed)
Project
Location
Architect
Engineer
Contractor
Submitted by
SPECIFICATION SHEET
F
RECESSED
E
D
D
SURFACE
E
MOUNT
76031 (1-800-325-8351)
Date
80D
F
C
B
A
A99044182 B
