The Natural Way to Look at a Computer™
Retrofit Kit
Assembly Instructions
Model #
50-0-1818
-22, -24, -27, -28, -30, -33, -34
Step 1
If the worksurface is prepared for Retrofit Kit & Keyboard
Drawer Installation, skip to Step 3. Otherwise, please prepare your
worksurface to the specifications shown in Figure 1a for Viewport &
Side Assembly milling/drilling. If using a 24" Adjustable Keyboard
Drawer, please use separate hole pattern shown below.
The retrofit kit can be installed in almost any work surface. The kit is
designed to attach to a work surface that is 1-1/8" to 2" in thickness.
Thinner work surfaces may require some build-up of material for
proper installation. Glass work surfaces are not recommended. If
your countertop is a solid material such as natural granite or
marble or a fabricated solid surface such as Corian, you should use
a professional fabricator to create the opening and surface
mounting anchors required for your kit. Forward a copy of the
boring pattern and hole size cut out to a professional fabricator.
FIGURE 1a
UNDERSIDE OF TOP
for 24" Adjustable Keyboard Drawer
P.O. Box 725 • 421 W. Industrial Avenue • Effingham, Illinois 62401 • Phone: (800) 730-6682 • Fax: (800) 940-6682 • E-mail: info@novasolutionsinc.com • Website: http://www.novasolutionsinc.com
IIR002
50-0-1818 Asy. Instr. - Rev. 07/21/04, © Nova Solutions, Inc. 2002
3
/
"
.
Dia
16
5
/
"
Deep
8
6 Places
1
/
"(12.7
) R.
2
mm
4 Places
FRONT EDGE
1
18-
/
"(464
)
4
mm
1
21-
/
"(540
)
4
mm
for all other keyboards
1
25-
/
"(637
)
16
mm
ASSEMBLED VIEW
Step 2
Keyboard Drawer holes (as shown in Figure 1b) should be drilled
for the specific keyboard size. Care must be exercised to use the
specifications in Figure 1b regarding drill size and hole depth.
To offset the viewport and keyboard drawer, please call
Customer Support at 1-800-730-6682 for special instructions.
FIGURE 1b
18
22
28
1-1/4"(
32
)
Offset
mm
(Typ.)
3
/
" Dia.
16
5
/
" Deep
8
6 Places
FRONT EDGE
13
/
"(478
) 22" Keyboard
16
mm
19
/
"(574
) 24" Keyboard
32
mm
5
25
/
"(643
) 27" Keyboard
16
mm
1
26
/
"(664
) 28" Keyboard
8
mm
1
/
"(713
) 30" Keyboard
16
mm
1
31
/
"(794
) 33" Keyboard
4
mm
1
32
/
"(816
) 34" Keyboard
8
mm
Page 1
