Page 1 NN42020-310 Multimedia Communication Portfolio Multimedia Communication Server 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide MCS 5100 3.5 Standard June 2006...
Page 3: Table Of Contents
Connecting the Sun Fire V210 server to the MRV LX terminal server Installing and accessing the MRV LX-4000 series terminal server ..33 Powering on the servers ........45 Installing Disks 1 to 3 .
Page 4 Adding a server ........
Page 5 Verifying Server1 (DBSvr/MgmtSvr/AcctMgr) ..... . . 163 Verifying Server2 (application server) ......165 Verifying the database load (imssipdb) deployment Deploying the PC Client .
Page 7: Web Site
Copyright © Nortel Networks Limited 2006 Finding the latest updates on the Nortel Web site The content of this documentation was current at the time the product was released. To check for updates to the latest documentation and software for MCS 5100, click...
Page 9: How To Get Help
Copyright © Nortel Networks Limited 2006 How to get help This section explains how to get help for Nortel products and services. Getting help from the Nortel web site The best way to get technical support for Nortel products is from the Nortel Technical Support web site: www.nortel.com/support...
Page 10 Copyright © Nortel Networks Limited 2006 Getting help from a specialist by using an Express Routing Code To access some Nortel Technical Solutions Centers, you can use an Express Routing Code (ERC) to quickly route your call to a specialist in your Nortel product or service.
Page 11: Overview
This document describes the installation of the 2-server Sun Fire V210 Solaris system. The 2-server Sun Fire V210 Solaris system must be connected to a 100-MB full-duplex Ethernet switch. The IP configuration consists of one public IP address. The following figures show the possible network configurations.
Page 12 Copyright © Nortel Networks Limited 2006 Figure 2 2-server network with single Ethernet switch Figure 3 2-server network MAS Ad hoc audio conferencing with single Ethernet switch Ethernet Switch Ethernet Switch The rest of this document will refer to the example data in the figure that follows.
Page 13: Restrictions And Limitations
Restrictions and limitations The 2-server V210 Solaris system is non-redundant. Since redundancy is not built into the system, a server failure will result in the loss of services. The 2-server V210 Solaris system has a mirrored disk. In the event of a disk failure, the failed disk should be replaced as soon as possible.
Page 14: Mcs 5100 Documentation
Copyright © Nortel Networks Limited 2006 MCS 5100 documentation Refer to the MCS 5100 Network Deployment and Engineering Guide, NN10313-191, that accompanies the MCS 5100 product and to your customer-specific information (CSI) datasheet for your system requirements. For more information on component installation and commissioning tasks, refer to the specific component documentation: •...
Page 15 Copyright © Nortel Networks Limited 2006 • MCS 5100 Fault Management: Alarm and Log reference, NN10385-900 • MCS 5100 Performance Management: OM reference , NN10386-700 MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide...
Page 17: Before You Start The Installation
Network Deployment and Engineering Guide, NN10313-191, which shows how to connect servers to two different UPS systems for maximum uptime. For power over Ethernet in the closet switches, Nortel Networks recommends use of the Ethernet Switch 460 Power Over LAN layer 2 Ethernet switches.
Page 18: Acronyms
Copyright © Nortel Networks Limited 2006 The procedures in this Guide assume that you are using the PuTTY VT100 terminal emulator tool. To set up sessions, download from the web the PuTTY VT100 Emulator, a shareware configurator tool. Download PuTTY from www.chiark.greenend.org.uk/~sgtatham/putty/...
Page 19: Key Stroke Symbols
Copyright © Nortel Networks Limited 2006 Key stroke symbols The following key stroke symbols are used in this document. When you are asked to Press Esc+2 Navigate Select <Value in brackets> [Enter] Text conventions used in this document This document uses the following text conventions: •...
Page 20: Server Configuration
Copyright © Nortel Networks Limited 2006 Server configuration The following table shows the basic configuration of the 2-server V210 Solaris system. Table 1 2-server configuration Configuration Server type 2-server V210 Server1 Solaris Server2 Loading disks MCS 5100 Release 3.0 Base Platform System SoftWare Kit NTVW01AJ contains multiple copies of the same CDs to allow simultaneous installation across servers.
Page 21 Copyright © Nortel Networks Limited 2006 MCS Base Platform System Software disks are loaded on the following servers as indicated in servers (with times) Table 2 Mapping of Kit NTVW01BD disks to servers (with times) MCS Base Platform System Software: Order code NTVW01BD CD1 Disk Partitioning &...
Page 23: Minimum And Recommended Requirements For Customer-Provided Pc
Copyright © Nortel Networks Limited 2006 Minimum and recommended requirements for customer-provided PC Configure your management pc to have an IP address that is in the same subnet of the IP address range used for your servers. Check your pc vendor’s documentation to learn how to configure the PC’s IP address.
Page 24 Copyright © Nortel Networks Limited 2006 • mouse: required • Video Graphics Card: — minimum: 640x480 @8bpp [256 colors] VGA — recommended: 800x600 @16bpp [65,536 colors] VGA or better • sound card: not applicable • operating systems: — minimum: Microsoft Windows 98(SE)/ME/2000/XP, or Microsoft Windows NT 4.x with Service Pack 5 (SP5)
Page 25: Setting Up The Baseline Hardware
If a power outage occurs, bring the server for the Database Module into service before bringing the other servers into service. If other servers do not come up, restart the server for the Management Module. MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide...
Page 26 — 2 10/100-Mbit Ethernet and USB Ports — System configuration card — Solaris* 8 and ALOM v1.5 pre-installed — two (2), cat-5 Ethernet cables for each V210 server (for a total of four (4) ethernet cables) Note: Each V210 server uses two (2) ethernet cables to connect the V210 servers to the layer-2 switch.
Page 27: Setting Up Rack To Mount Hardware
Copyright © Nortel Networks Limited 2006 Make sure you have • Business Policy Switch 2000 (BPS 2000) or Layer-2 switch • vendor documentation for configuring your Layer-2 switch • one (1) additional cat-5 ethernet cable to connect the MRV LX terminal server to the layer-2 switch •...
Page 28: Connecting The Sun Fire V210 Server To The Layer-2 Switch
Procedure 2 Connecting the V210 server to the layer-2 switch At the back of the Sun Fire V210 server, Connect the Sun Fire V210 server Net 0 and Net 1 ports to the layer-2 switch using Ethernet, cat-5 cables. NN42020-310 MCS 5100 3.5 Standard 1.0 June 2006...
Page 29 Note 2: The two Ethernet switches are physically linked together through either cascade modules or Ethernet links. Plug in the power cords at the back of the V210 server. Do not power up the server at this time. MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide...
Page 30: Connecting The Sun Fire V210 Server To The Mrv Lx Terminal Server
Note 1: The cables with part numbers A0500465 or NTVW01IM are serial cables. Note 2: The P1 end goes to the V210 server and the P2 end goes to the MRV LX terminal server. NN42020-310 MCS 5100 3.5 Standard 1.0 June 2006...
Page 31 Copyright © Nortel Networks Limited 2006 Figure 8 P1 and P2 custom cable connections to terminal server See note Note: This cable is only connected to configure the terminal server. Following configuration, remove the cable. MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide...
Page 33: Installing And Accessing The Mrv Lx-4000 Series Terminal Server
Procedure 5 Accessing the MRV LX terminal server At the browser address field, Type in the IP address of your MRV LX terminal server. The LX Series Configuration Console page appears, as shown. MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide...
Page 34 Copyright © Nortel Networks Limited 2006 Figure 9 MRV Configuration Console window Make sure you have the Java Plug-in installed. When your browser connects to the terminal server, the Java Security Warning window appears. Figure 10 Java Security Warning pop-up window...
Page 35 Copyright © Nortel Networks Limited 2006 Click on Grant this session. The Java Security Warning window closes. The LX Series Configuration Console page reappears, now with the green console selection visible. Figure 11 LX Series Configuration Console page Choosing Encrypted Console means the Graphical User Interface (GUI) will run slower, but with security.
Page 36 Copyright © Nortel Networks Limited 2006 Figure 12 Login window Enter your Username and Password, and click Login. Note: By default, authentication is done against the local user database. To start, use the known username InReach and password access. If you log in as a user, the following window appears.
Page 37 Copyright © Nortel Networks Limited 2006 Figure 13 User login window To log in as a superuser, click the Admin button on the tool bar and log in with the default Superuser password system. You can now configure the unit at the GUI.
Page 38 Copyright © Nortel Networks Limited 2006 Figure 14 Example: selecting Ports: Async a When you click on a port, the following dialog box appears for you to enter your information. Note: In the TCP window (see Figure 15), ensure that both the Telnet CR Filtering radio button, and the Telnet Negotiations radio button are Enabled.
Page 39 Copyright © Nortel Networks Limited 2006 Figure 15 Port 19 dialog box For details on using the IP Configuration Menu, refer to “Using the IP Configuration Menu” in the LX-Series Configuration Guide. For information on how to boot your unit from defaults, refer to “Booting from Defaults”...
Page 40 Copyright © Nortel Networks Limited 2006 Procedure 6 Connecting through the server to the MRV LX terminal server At the management pc, MRV Communications recommends that you change the default password for the user’s MRV LX terminal server before you put the unit on a network.
Page 41 Copyright © Nortel Networks Limited 2006 Enter a new user password at the Enter your NEW password: prompt. The password will be displayed as asterisks. Re-enter the new user password at the Re-Enter your NEW password: prompt. The password will be displayed as asterisks.
Page 42 Copyright © Nortel Networks Limited 2006 Enter your password: system [Enter] Define server ip address <IP address of the terminal server> [Enter] Define server ip subnet mask <ip-address of the subnet mask> [Enter] Define server ip primary gateway address <ip address of the primary gateway>...
Page 43 For example, if the target host is connected to port 9 of the MRV LX terminal server, then the port number would be 2900. Port 12 is the port on the back of the MRV LX terminal server that translates to 3200.
Page 45: Powering On The Servers
Procedure 10 Powering on the servers At the server, Do not have any bootp servers on the same subnet of the system. If there is such a server, disconnect the LAN interface cable from the system subnet. Turn power on to the server.
Page 46 Copyright © Nortel Networks Limited 2006 The >ok prompt appears. ATTENTION If you do not use PuTTY, use the appropriate key sequence to send a break to the server to get an >ok prompt. NN42020-310 MCS 5100 3.5 Standard 1.0 June 2006...
Page 47: Installing Disks 1 To 3
Net MGT (LOM) port until after you have installed CD5. Then log out. Log back in through the terminal server to Serial MGT port for the rest of the installation. For installations on machines that have already had a system installed, just remain on the Serial MGT port.
Page 48 Copyright © Nortel Networks Limited 2006 Make sure you put spaces before and after the hyphen: boot [space] cdrom [space] - [space] install. At the >ok prompt, boot the system: boot cdrom - install [Enter] For instructions on how to get to the >ok prompt, see...
Page 49 Copyright © Nortel Networks Limited 2006 Network Connectivity/Networked Accept the default Yes by pressing Esc+2 to continue. DHCP/Use DHCP Accept the default No by pressing Esc+2 to continue. Primary Network Interface /Primary Network Interface Choose bge0 as the primary network interface and press Esc+2 to continue.
Page 50 Copyright © Nortel Networks Limited 2006 Netmask/Netmask Do not accept the default unless you are sure it is correct for your subnet. Enter the subnet mask, for example: 255.255.255.0. Press Esc+2 to continue. IPv6/Enables IPv6 IPv6 is not supported. Accept the default No.
Page 51 1) Application Server 2) Management/Accounting 3) Oracle/DB ********************************************** Select your required server type (1, 2 or 3), then press Enter. MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide ATTENTION 45. The selection of the number depends Powering...
Page 52: Installing Cd2
Copyright © Nortel Networks Limited 2006 Wait until you receive the login prompt. You will be prompted to type in the root password twice. The password will not appear on the screen when you type. If you do not want a root password, press Enter twice. Press Enter to continue.
Page 53: Installing Cd3
Copyright © Nortel Networks Limited 2006 Installing CD3 Approximate time estimate = 90 minutes Procedure 14 Installing CD3 At the management pc, Place CD3 in the CD-ROM drive and press Enter at the prompt. Wait for the login prompt to appear. The script will execute after you press Enter.
Page 55: Installing Disk 4
Copyright © Nortel Networks Limited 2006 Installing Disk 4 The following sections describe installing CD4 according to the specific server type. Please note that there are some small, but very important, differences in the installation of the two types of servers (database/accounting/management or application server).
Page 56 Copyright © Nortel Networks Limited 2006 to use the local system clock as the time source. Note: Select Time Source • • • Select option from list above [E, I, X] Refer to the CSI for NTP time source IP information.
Page 57 Example: 120.120.13.21 Enter the <machine logical IP addresses of the servers> that are the ping targets. Note: Do not enter the IP address of the server you are working on. IP Multipathing needs a set of reliable hosts to ping against.
Page 58 Enter ping target #1: 120.120.13.25 Enter ping target #2: 120.120.13.1 Enter ping target #3: 0.0.0.0 Note: Do NOT use this server's own IP address as a ping target. Press Enter after each IP address. The configuration information will come up as shown in the...
Page 59 Copyright © Nortel Networks Limited 2006 You will see the following message: Obtaining IP Addresses for SysMgr/AcctMgr Failover Operation Note: If you don't have plan to configure the failover service, type in the same primary service logical IP address and primary machine logical IP address or type 0.0.0.0 instead.
Page 60: Application Servers (Sip Application Module, Ipcm, Web Client Manager, Provisioning Module)
Copyright © Nortel Networks Limited 2006 Enter the <IP address for the Physical Ethernet Net Management Port> (Default: Enter the <netmask for the Physical Ethernet Net Management Port> (Default: Enter the <Gateway IP address> (Default: You are asked to confirm the LOM port configuration.
Page 61 Example: 120.120.13.24 Enter the <machine logical IP addresses of the servers> that are the ping targets. Note: Do not enter the IP address of the server you are working on. IP Multipathing needs a set of reliable hosts to ping against.
Page 62 IPMP failover reliability. Enter the address "0.0.0.0" to indicate list is complete, if entering less than six targets. Note: Do NOT use this server's own IP address as a ping target. Press Enter after each IP address, for example: 0.0.0.0 [Enter] (This is the third ping target machine logical IP address.).
Page 63 Copyright © Nortel Networks Limited 2006 Is this IPMP group configuration acceptable? (Y/N) Select Y to accept or N to change. The default route IP address should appear. If correct, press Enter. Otherwise, type it in, then press Enter. Note: If your configuration does not include a router, then enter the machine logical IP address of your server.
Page 65: Installing Disk 5 (All Servers)
Approximate time estimate is 30 minutes. Procedure 17 Installing CD5 At the management pc, Place CD5 in the CD-ROM drive, on the server, and press Enter at the prompt. Note 1: CD5 will eject from the CD-ROM when installed. Note 2: For Management/Accounting servers, you will be prompted for CD6.
Page 67: Enabling Or Disabling The Automatic Mount
Copyright © Nortel Networks Limited 2006 Enabling or disabling the automatic mount Use the following procedure if you need to use the CD-ROM auto-mount after installation of CD5. Execute this procedure on the MgmtSvr (Server1). Keep this procedure for future use.
Page 69: Installing Disk 6 (Mgmtsvr/Acctmgr Only)
Approximate time estimate = 30 minutes Procedure 19 Installing CD 6 At the management pc, Place CD6 in the CD-ROM drive, on the server, and press Enter at the prompt. Note: CD6 will eject from the CD-ROM when installed. After the reboot, log in (using the Serial MGT port) and change the passwords for the sysadmin, root, and nortel users.
Page 71: Installing Oracle 9.2.0.4 On The Database Server
Enable the CD-ROM auto mount by typing the following command: /etc/init.d/volmgt start You will see the message: volume management starting. Insert Oracle 9.2.0.4 CD 1 into the CD-ROM drive on the server. cd [ space] /cdrom/cdrom0 [Enter] MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide...
Page 72 Copyright © Nortel Networks Limited 2006 Make sure you put a space before the ending slash (/) in step 5. cp [ space] Install_CD_to_Disk [ space] / [Enter] cd [ space] / [Enter] ./Install_CD_to_Disk [Enter] Storing data from CDs to the /IMS/ora_cds...
Page 73 Copyright © Nortel Networks Limited 2006 Refer to this table when entering the following command: Prompt pri_db_hostname sec_db_hostname cd [space] /IMS/ora_cds/Disk1 [Enter] ./Oracle_Install PRIMARY <primarydb-hostname> [space] <secondarydb-hostname>[space] | [space] tee [space] /tmp/oracleinstall.log Enter the password oracle at the Oracle prompt. [Enter]...
Page 74 Copyright © Nortel Networks Limited 2006 Failing to answer Y will cause the system to raise a disk space alarm on the SysMgr screen for the DBSvr. You will see the message: Removing Disk 1, Disk2, Disk3, Disk4, Disk5, Disk6 from /IMS/ora_cds...
Page 75: Deploying The Initial Database Load
Copyright © Nortel Networks Limited 2006 Deploying the initial database load Prerequisites Ensure that the MCS Base Platform Software and Oracle 9i have been installed on database servers. Refer to your CSI datasheet to enter the IP addresses that you are prompted for in this section.
Page 76 Copyright © Nortel Networks Limited 2006 You will see the following message: Select the Type of Deployment: [1] Initial Deployment [2] Upgrade of Database [3] Rollback of Database [4] Install Files only to Select 1 for initial deployment, then press Enter.
Page 77: Deploying And Starting The Sysmgr
Deploy the Sysmgr for a non-redundant configuration. The operator logs into the machine logical IP address of the management server. At the UNIX prompt, the operator the uses the script mgmtdeploy.pl to deploy and start the Sysmgr. This process is described in the following section.
Page 78 Copyright © Nortel Networks Limited 2006 When selecting the management server load, always select the load that contains the word "micro" in it. If the non-micro load is selected, the installer will receive an Out Of Memory error. The server load names are: •...
Page 79: Sysmgr Deployment Verification
Copyright © Nortel Networks Limited 2006 Will a Motorola SAM16 server (SIP PriGwy or SIP Audio Svr) be deployed? Always answer N [Enter] even if you have a third-party gateway. Note: Information obtained for deploying the Sysmgr appears. Is the above data correct? [Y]...
Page 81: Registering Your License Key
Copyright © Nortel Networks Limited 2006 Registering your license key Before installing the license key as described in Installing the System Management below to generate and register your license key. Procedure 24 Registering the license key At the management pc, Before you can begin generating keycodes, first “Register”...
Page 82 Copyright © Nortel Networks Limited 2006 Figure 18 KRS login screen In step 1 (Location) select a login server that matches your region, for example, European Login or North American Login. In step 2 (Product Family) select the product you wish to generate keycodes for;...
Page 83 Copyright © Nortel Networks Limited 2006 Figure 19 Keycode Retrieval System, Creating your site Select Create to register a new system. The following screen appears. MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide...
Page 84 Copyright © Nortel Networks Limited 2006 Figure 20 Keycode Retrieval System, Entering your site information Fill in the requested information and press the Continue button. Ensure you choose the correct software version from the dropdown box. Your screen should look like the one in the following figure.
Page 85 Copyright © Nortel Networks Limited 2006 Figure 21 Keycode Retrieval System, Current Summary Select the server you want to enter MAC addresses for first, then click on Create. Enter the MAC addresses of the CORE servers and click on Add.
Page 86 Copyright © Nortel Networks Limited 2006 Figure 22 Keycode Retrieval System, Adding MAC address Repeat Step make an error, you can remove one or both and begin again. If you have a second Core that is going to be installed as a redundant server enter all four MAC addresses at this time.
Page 87 Copyright © Nortel Networks Limited 2006 Server Service Guide applicable to your system (see the Overview chapter for a listing of the service guides). Note: If you have a second Media Application Server for your system, you must select Create a second time as only two MAC addresses can be associated with any one Media Application Server.
Page 88 Copyright © Nortel Networks Limited 2006 Figure 24 Keycode Retrieval System, Current Summary To generate keycodes for this site, click on Gen KC with Auth Code from the side bar, as shown in the following figure. NN42020-310 MCS 5100 3.5 Standard 1.0 June 2006...
Page 89 Figure 25 Keycode Retrieval System, Gen KC with Auth Code To generate your keycodes, enter one of the MAC addresses of the server you want your Auth code applied to. In this case, the example shows one of the CORE MAC addresses. Select Add.
Page 90 Copyright © Nortel Networks Limited 2006 Figure 26 Keycode Retrieval System, Finding the keycode Select the proper Software Version for your system. Then click on Continue. NN42020-310 MCS 5100 3.5 Standard 1.0 June 2006...
Page 91 Copyright © Nortel Networks Limited 2006 Figure 27 Keycode Retrieval System, Adding a MAC address Enter the authcode number for the feature you wish to enable into the Auth Code box. Use the system Authorization codes to build your license key file.
Page 92 This screen shows the current features enabled and the new features to be added to your server. In a new installation there are no features displayed. If the list is correct, click on Continue.
Page 93 After generating the keycodes and saving results in the KRS database, the system shows the Retrieve Keycode page where you can view the features enabled for the server. From this page you will be able to download the keycode (see the figures below).
Page 94 Copyright © Nortel Networks Limited 2006 Figure 30 Keycode Retrieval System, Retrieving the keycode Best Customer The screens show the features of your keycode and the option to download the keycode to your local PC. To download the keycode click on Download Keycode. From there you will see the screens to download the file and save it where you choose to on your local machine.
Page 95 Copyright © Nortel Networks Limited 2006 Figure 31 Keycode Retrieval System, Retrieving your keycode, part 2 Download the new license key file to the MgmtSvr hard drive. MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide...
Page 97: Installing And Launching The System Management Console
Copyright © Nortel Networks Limited 2006 Installing and launching the System Management Console Prerequisites Make sure that • The dbdeploy.pl script has been successfully executed. • The mgmtdeploy.pl script has been successfully executed. • The Sysmgr is started. • The license key is registered.
Page 98: Launching The System Management Console
Copyright © Nortel Networks Limited 2006 Click Next to begin installation. At the pop-up window that says, Installation successfully completed, click OK. Launching the System Management Console Make sure that the System Management Console application has been successfully installed on the PC.
Page 99 Copyright © Nortel Networks Limited 2006 the License Key->Update dropdown menu (You can also select the System=>License Key=>Update menu option from the System tree.) as shown in Update License highlighted. Figure 32 Management Console Update License Key After you have selected the Update menu-item, an Update...
Page 100 Copyright © Nortel Networks Limited 2006 Figure 33 Select License key File Window Once you have entered the new License Key, you will see a dialog box notifying you whether the update is successful or fails. If the system does not find a license key in the database or on the Managements server local disk, a dialog box will appear, prompting for a license key file.
Page 101 Copyright © Nortel Networks Limited 2006 The console screen has the basic look and feel of a Windows Explorer window with a tree structure on the left, and a general information area on the right. Each folder on the management console tree is represented as a Network Element and each has a different functionality.
Page 103: Adding A Server
Copyright © Nortel Networks Limited 2006 Adding a server Prerequisites The System Management Console has been successfully installed and started. Adding a server Use this procedure to add each of your servers. Note: You should view the content of this chapter as reference information.
Page 104 Copyright © Nortel Networks Limited 2006 System server field Customer defines Longitude Optional field. Describes the longitudinal coordinates of the location of this server. Platform type Drop-down menu with following choices: Sun or Linux. Select Sun. IP address The machine logical IP address of the server.
Page 105: Adding And Configuring The Accounting Module
Select Sites->MgmtSite->Servers->Add->General->MgmtSvr. Adding a server on page 103 a server before adding the AcctMgr. Click on the plus sign next to the server to which you are adding the component. Right click on the Components folder. Select Add -> Component.
Page 106 Copyright © Nortel Networks Limited 2006 window. The Service Component Name must be unique among all components. Example: acct1 Procedure 29 Configuring the tabs At the System Management Console, Use the values from the table that follows to complete the Central Accounting Manager tab parameters.
Page 107 Copyright © Nortel Networks Limited 2006 Table 1 Central Accounting Manager tab (Sheet 2 of 2) Parameter Recommended value TCP/IP Enabled unchecked TCP/IP Address 0.0.0.0 TCP/IP Primary 9000 Host Port TCP/IP Recovery 9001 Host Port FTP Push Enabled unchecked Primary FTP...
Page 108 Copyright © Nortel Networks Limited 2006 The component will deploy. Wait until you see the dialog box indicating successful installation. The component will appear in the file tree. NN42020-310 MCS 5100 3.5 Standard 1.0 June 2006...
Page 109: Adding And Configuring The Sip Application Module
Select Sites->MgmtSite->Servers->Add->General->AppSvr. Adding a server on page 103 a server before adding the SIP Application Module. Click on the plus sign next to the server to which you are adding the component. Right click on the Components folder. Select Add -> Component.
Page 110 Copyright © Nortel Networks Limited 2006 Procedure 31 Configuring the SIP Application Module tabs Do not click Apply until you have FINISHED configuring all the tabs. At the System Management Console, Use the values from the following table to enter into the Authentication tab parameters.
Page 111 Copyright © Nortel Networks Limited 2006 Table 2 Authentication tab (Sheet 2 of 2) Parameter Nonce Interval Authorized Method Entries: Authorized Method Use the following values to complete the Local Accounting Manager tab. The shaded rows indicate values that must be addressed by the installer.
Page 112 Copyright © Nortel Networks Limited 2006 Table 3 Local Accounting Manager tab (Sheet 2 of 2) Parameter Disk Monitor Critical Threshold Enable Billing For Instant Message Use the values from the table that follows to complete the Media Portal tab parameters.
Page 113 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 6 Database Base tab Parameter Recommended value Primary Host <machine logical IP of database server> Connections Secondary Host Not applicable Use the values from the table that follows to complete the SIP TCF Base tab parameters.
Page 114 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 8 In Memory Database tab Parameter Number of domains Update interval for domain information Number of users Update interval for presence limits...
Page 115 Use the values from the table that follows to complete the Registrar Service tab parameters. Table 10 Registrar Service tab Parameter Maximum Registration Duration Use the values from the table that follows to complete the Server Subscription tab parameters. Table 11 Server Subscription tab Parameter provServerURL Use the values from the table that follows to complete the Subscription Processing tab parameters.
Page 116 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 14 Server Properties tab Parameter Recommended value Service Public_Service_Address Parameter: Label Value: <machine logical IP address of the application server> Service...
Page 117 Copyright © Nortel Networks Limited 2006 Table 15 Overload Controls tab (Continued) Parameter Call queue high threshold Call queue low threshold Other queue high threshold Other queue low threshold Database queue high threshold Database queue low threshold Protocols Monitored Use the table that follows to modify the fields for the Transport Management tab.
Page 118 Copyright © Nortel Networks Limited 2006 Table 16 Transport Management tab (Sheet 2 of 3) Parameter Recommended value Discovery Period Active Pending Period HB Address checked Enabled Remote Server <machine logical IP of Address other application server> Local Server Public_Static_Address...
Page 119 Copyright © Nortel Networks Limited 2006 Table 16 Transport Management tab (Sheet 3 of 3) Parameter Recommended value Parameters: Service checked Parameter: Transport Enabled Protocol Transport Address Public_Service_Address Port 5060 Params name=sipLscConduit:inte rface=bge0 Click Apply. The component will deploy. Wait until you see the dialog box indicating successful installation.
Page 121: Adding And Configuring The Ip Client Manager
Select Sites->MgmtSite->Servers->Add->General->AppSvr Adding a server on page 103 a server before adding the AppSvr. Click on the plus sign next to the server to which you are adding the component. Right click on the Components folder. Select Add -> Component.
Page 122 Copyright © Nortel Networks Limited 2006 Procedure 33 Configuring the IP Client Manager tabs Do not click Apply until you have finished configuring the component. At the System Management Console, Use the values from the table that follows to complete the IP Client Manager tab parameters.
Page 123 Copyright © Nortel Networks Limited 2006 Table 17 IP Client Manager tab (Sheet 2 of 2) Parameter Recommended Value Notes Phase 1 Firmware ID Phase 2 Firmware ID Use UFTP checked UFTP Server Port 50020 Keep Alive Timer KA Phone Timer...
Page 124 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 19 UNISTIM Base tab Parameter Recommended value LocalHost <machine logical IP address of the IPCM server> Port 5000 Use the values from the table that follows to complete the SIP TCF Base tab parameters.
Page 125 Copyright © Nortel Networks Limited 2006 Use the values from the following table to enter into the In Memory Database tab parameters. The shaded rows indicate values that must be addressed by the installer. Table 22 In Memory Database tab...
Page 127: Installing The Uftp Basesoftware
Copyright © Nortel Networks Limited 2006 Installing the UFTP BaseSoftware You will be installing the UFTP software on the application server. Prerequisites The System Management Console has been successfully installed and started. Note: This procedure also assumes that the IP Client Manager (IPCM) component was deployed successfully;...
Page 129: Configuring The Provisioning Module
Procedure 35 Adding the Provisioning Module (Small SharedMicro) At the System Management Console, Select Sites->MgmtSite->Servers->AppSvr. Click on the plus sign next to the server to which you are adding the component. Right click on the Components folder. Select Add->Component. A list of component loads appears in the Load List window.
Page 130: Nn42020-310 Mcs 5100 3.5 Standard 1.0 June
Copyright © Nortel Networks Limited 2006 Procedure 36 Configuring the Provisioning Module tabs At the System Management Console, Use the values from the table that follows to complete the SIP TCF Base tab parameters. The shaded rows indicate values that must be addressed by the installer.
Page 131 Copyright © Nortel Networks Limited 2006 Use the values from the table that follows to complete the Web Client Manager tab parameters. The shaded rows indicate values that must be addressed by the installer. Table 26 Web Client Manager tab...
Page 132 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 27 Database Base tab Parameter Recommended value Primary Host <machine logical IP database server> Connections Secondary Host <leave blank> Use the values from the table that follows to complete the SIP Personal Agent tab parameters.
Page 133 Copyright © Nortel Networks Limited 2006 Use the values from the table that follows to complete the Conference_Service tab parameters. Table 30 Conference_Service tab Parameter Conf Server URL Click Apply. Note: A progress window will display indicating the status of the deployment.
Page 135: Adding And Configuring The Web Client Manager
Procedure 37 Adding the Web Client Manager (Small SharedMicro) At the System Management Console, Select Sites->MgmtSite->Servers->AppSvr. Click on the plus sign next to the server to which you are adding the component. Right click on the Components folder. Select Add -> Component.
Page 136 Copyright © Nortel Networks Limited 2006 Procedure 38 Configuring the Web Client Manager tabs Do not click Apply until you have finished configuring the component. At the System Management Console, Use the values from the table that follows to complete the User Agent Server tab parameters.
Page 137 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 32 SIP TCF Base tab Recommended Parameter Value Transport Config UDP=<machine logical IP of the WCM Server.>:5080:optiona l;TCP=<machine logical IP of the WCM Server.>:5080:optiona...
Page 138 Copyright © Nortel Networks Limited 2006 Table 33 Web Client Manager tab (Sheet 2 of 2) Parameter Audio RTP Port Low Audio RTP Port High Use SSL Keep Alive Ping Ping Time Out Timer Ping Interval Timer Connection Time Out Timer 360...
Page 139 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 35 Database Base tab Parameter Primary Host Connections Secondary Host Click Apply. The component will deploy. Wait until you see the dialog box indicating successful installation.
Page 141: Installing And Configuring The Oracle Monitor
Procedure 39 Adding the Oracle Monitor (Micro) to the System Management Console At the System Management Console, Select Sites->MgmtSite->Servers->MgmtSvr. Click on the plus sign next to the server to which you are adding the component. Right click on the Components folder. Select Add -> Component.
Page 142 Copyright © Nortel Networks Limited 2006 Procedure 40 Configuring the Oracle Monitor tabs Do not click Apply until you have finished configuring the component. At the System Management Console, Use the values from the table that follows to complete the Oracle Server tab parameters.
Page 143 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 37 IMS Main Database tab (Sheet 1 of 4) Parameter SNMP request port SNMP agent IP address Oracle Server name Oracle Database name...
Page 144 Copyright © Nortel Networks Limited 2006 Table 37 IMS Main Database tab (Sheet 2 of 4) Parameter Gauged Component Monitoring: Threshold monitors: Positive going threshold value 1 Gauged Component Monitoring: Threshold monitors: Positive going threshold hysteresis 1 Gauged Component Monitoring: Threshold...
Page 145 Copyright © Nortel Networks Limited 2006 Table 37 IMS Main Database tab (Sheet 3 of 4) Parameter Gauged Component Monitoring: Threshold monitors: Alarm Severity on Positive Going Threshold2 Gauged Component Monitoring: Threshold monitors: Alarm Severity on Maximum Rate Gauged Component...
Page 146 Copyright © Nortel Networks Limited 2006 Table 37 IMS Main Database tab (Sheet 4 of 4) Parameter Monitor functions: Polling interval (min) Monitor functions: Active Monitor functions: Component name Monitor functions: Polling interval (min) Monitor functions: Active Trap handlers: Trap...
Page 147 Copyright © Nortel Networks Limited 2006 The shaded rows indicate values that must be addressed by the installer. Table 39 Oracle Listeners tab Parameter SNMP request port SNMP agent IP address Active Component Monitoring: Component name Component Monitoring: Polling interval (min) Active Click Apply.
Page 149: Installing The Iplanet Monitor
Procedures Procedure 41 Adding the iPlanet Monitor At the System Management Console, Select Sites->MgmtSite->Servers->AppSvr Click on the plus sign next to the server to which you are adding the component. Right click on the Components folder. Select Add -> Component.
Page 150 Copyright © Nortel Networks Limited 2006 Procedure 42 Configuring the iPlanet Monitor At the System Management Console, Do not click Apply until you have finished configuring the tab. Use the values from the table that follows to complete the Web Monitor tab parameters.
Page 151 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 2 of 12) Parameter Component Monitoring: Threshold monitors: Lower Limit Component Monitoring: Threshold monitors: Negative going threshold value Component Monitoring: Threshold monitors: Negative going threshold hysteresis Component Monitoring:...
Page 152 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 3 of 12) Parameter Component Monitoring: Threshold monitors: Alarm Severity on Negative going threshold Component Monitoring: Threshold monitors: Alarm Severity on Positive going threshold 1 Component Monitoring: Threshold monitors:...
Page 153 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 4 of 12) Parameter Component Monitoring: Threshold monitors: Negative going threshold value Component Monitoring: Threshold monitors: Negative going threshold hysteresis Component Monitoring: Threshold monitors: Positive going threshold value 1...
Page 154 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 5 of 12) Parameter Threshold monitors: Alarm Severity on Positive going threshold 1 Threshold monitors: Alarm Severity on Positive going threshold 2 Component Monitoring: Threshold monitors: Alarm Severity on...
Page 155 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 6 of 12) Parameter Component Monitoring: Positive going threshold value 1 Component Monitoring: Positive going threshold hysteresis 1 Component Monitoring: Positive going threshold value 2 Component Monitoring: Positive going threshold...
Page 156 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 7 of 12) Parameter Component Monitoring: Component name Component Monitoring: Polling interval in minutes Component Monitoring: Active for polling Component Monitoring: Threshold monitors: Gauge name Component Monitoring: Threshold monitors:...
Page 157 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 8 of 12) Parameter Component Monitoring: Threshold monitors: Positive going threshold hysteresis 2 Component Monitoring: Threshold monitors: Capacity or max value Component Monitoring: Threshold monitors: Capacity or max...
Page 158 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 9 of 12) Parameter Component Monitoring: Threshold monitors: Usage state affected Component Monitoring: Class name Component Monitoring: Component name Component Monitoring: Polling interval in minutes Component Monitoring: Active for polling...
Page 159 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 10 of 12) Parameter Component Monitoring: Threshold monitors: Positive going threshold hysteresis 1 Component Monitoring: Threshold monitors: Positive going threshold value 2 Component Monitoring: Threshold monitors: Positive going threshold...
Page 160 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 11 of 12) Parameter Component Monitoring: Threshold monitors: Alarm Severity on Upper Limit OverRun Component Monitoring: Threshold monitors: Alarm Severity on Lower Limit UnderRun Component Monitoring: Threshold monitors:...
Page 161 Copyright © Nortel Networks Limited 2006 Table 40 Web Monitor tab (Sheet 12 of 12) Parameter Trap handlers: Trap handler name Trap handlers: Active Click Apply. Wait for the component to appear in server list. The iPlanet Monitor is installed on the same server as the Provisioning Module.
Page 163: Verification Procedures
Copyright © Nortel Networks Limited 2006 Verification procedures Verifying Server1 (DBSvr/MgmtSvr/AcctMgr) The following commands are executed on the database/management/accounting Sun Fire V210 server using PuTTY SSH into the machine logical IP address. Example: Open a PuTTY SSH session to 120.120.13.22...
Page 164 Copyright © Nortel Networks Limited 2006 interface is ‘UP.’ This example output shows that bge0 is assigned to IP address 120.120.13.20, its subnet mask is ffffff00, which translates to 255.255.255.0, and the interface is UP (active). Look for the entry which starts with ‘bge1.’ The parameters that follow show the IP address, subnet mask, and whether the interface is ‘UP.’...
Page 165: Verifying Server2 (Application Server)
Copyright © Nortel Networks Limited 2006 120.120.13.1 The only address in this file defines your default gateway route (your router). If this file is empty and the machine is rebooted, then you will not have network access to your other servers.
Page 166 Copyright © Nortel Networks Limited 2006 Look for the entry that starts with ‘bge1.’ The parameters that follow show the IP address, subnet mask, and whether the interface is ‘UP.’ This example output shows that bge1 is assigned to IP address 120.120.13.24, its subnet mask is ffffff00 which translates to 255.255.255.0, and the interface is UP...
Page 167: Verifying The Database Load (Imssipdb) Deployment
[@micromgmt] /export/home/nortel:=> tail -f /tmp/*SQL* As the dbdeploy.pl script executes, a temporary log is created in the /tmp directory on the database server. Note that the SQL file in the /tmp directory will not be present until after the dbdeploy.pl script begins.
Page 169: Deploying The Pc Client
Copyright © Nortel Networks Limited 2006 Appendix A Deploying the PC Client Along with the initial load, Nortel Networks delivers the following: • Java Network Launch Protocol (JNLP) file: pcclient.jnlp • Zip file containing latest code resources: pcclientcode.zip System administrators need to perform the following steps to deploy Multimedia PC Client loads.
Page 171: Reloading Ip Addresses After System Installation
Copyright © Nortel Networks Limited 2006 Appendix B Reloading IP addresses after system installation This process prompts you for the hostname, country, time-zone, and IP address to enable movement of the system after the system is installed. You can re-enter the same data that was already in those parameters if they have not changed.
Page 172 The system is now ready to re-configure. You can type poweroff at the ok prompt if you wish to power the machine off. To reconfigure the server at this point, if you are at the boot prompt {ok}, enter the boot command. If you are not at the boot prompt, power on the server.
Page 173 Copyright © Nortel Networks Limited 2006 Type the number of your choice and press Return: Select 2 and press Enter. See the instructions for installing Disk 1 in this document for more information on what to enter for the following items: •...
Page 176 Users must take full responsibility for their applications of any products specified in this document. The information in this document is proprietary to Nortel Networks. Nortel, Nortel (Logo), and the Globemark are trademarks of Nortel Networks.
