NN10364-301
Multimedia Communication Portfolio
Multimedia Communication Server
2-server Sun Fire V100 Solaris Installation and Commissioning
Guide
MCS 5100 3.5
Standard
6.0
December 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sun Fire V100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nortel Sun Fire V100

  • Page 1 NN10364-301 Multimedia Communication Portfolio Multimedia Communication Server 2-server Sun Fire V100 Solaris Installation and Commissioning Guide MCS 5100 3.5 Standard December 2006...
  • Page 3: Table Of Contents

    Setting up rack to mount hardware ....... . 27 Connecting the Sun Fire V100 server to the layer-2 switch Connecting the Sun Fire V100 server to the MRV LX terminal server Installing and accessing the MRV LX-4000 series terminal server ..33 Powering on the servers .
  • Page 4 Adding a server ........
  • Page 5 Verifying Server1 (DBSvr/MgmtSvr/AcctMgr) ..... . . 161 Verifying Server2 (application server) ......163 Verifying the database load (imssipdb) deployment Deploying the PC Client .
  • Page 6 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 7: Finding The Latest Updates On The Nortel Web Site

    Link to Latest Software Latest Documentation MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Takes you directly to the Nortel page for MCS 5100 software located at www130.nortelnetworks.com/cgi-bin/eserv/cs/main.js p?cscat=SOFTWARE&resetFilter=1&tranProduct=12 Nortel page for MCS 5100 documentation located at www130.nortelnetworks.com/cgi-bin/eserv/cs/main.js...
  • Page 8 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 9: How To Get Help

    Nortel Solutions Center. In North America, call 1-800-4NORTEL (1-800-466-7835). Outside North America, go to the following web site to obtain the phone number for your region: www.nortel.com/callus MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 10 Copyright © 2006 Nortel Networks Getting help from a specialist by using an Express Routing Code To access some Nortel Technical Solutions Centers, you can use an Express Routing Code (ERC) to quickly route your call to a specialist in your Nortel product or service.
  • Page 11: Overview

    This document describes the installation of the 2-server Sun Fire V100 Solaris system. The 2-server Sun Fire V100 Solaris system must be connected to a 100-MB full-duplex Ethernet switch. The IP configuration consists of one public IP address. The following figures show the possible network configurations.
  • Page 12 Configure the pc you are using for management services with an IP address that is in the same subnet of the IP address range used for the Sun Fire V100. NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 13: Restrictions And Limitations

    Copyright © 2006 Nortel Networks Figure 4 Example of 2-server Sun Fire V100 Solaris system configuration Restrictions and limitations The 2-server V100 Solaris system is non-redundant. Since redundancy is not built into the system, a server failure will result in the loss of services.
  • Page 14: Mcs 5100 Documentation

    Copyright © 2006 Nortel Networks MCS 5100 documentation Refer to the MCS 5100 Network Deployment and Engineering Guide, NN10313-191, that accompanies the MCS 5100 product and to your customer-specific information (CSI) datasheet for your system requirements. For more information on component installation and commissioning tasks, refer to the specific component documentation: •...
  • Page 15 Copyright © 2006 Nortel Networks • MCS 5100 Fault Management: Alarm and Log reference, NN10385-900 • MCS 5100 Performance Management: OM reference , NN10386-700 MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 16 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 17: Before You Start The Installation

    UPS systems for maximum uptime. For power over Ethernet in the closet switches, Nortel Networks recommends use of the Ethernet Switch 460 Power Over LAN layer 2 Ethernet switches. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 18: Acronyms

    Copyright © 2006 Nortel Networks The procedures in this Guide assume that you are using the PuTTY VT100 terminal emulator tool. To set up sessions, download from the web the PuTTY VT100 Emulator, a shareware configurator tool. Download PuTTY from www.chiark.greenend.org.uk/~sgtatham/putty/...
  • Page 19: Key Stroke Symbols

    • Italic type is used for emphasis, for special words, or for reference information; for example, "Log in as root." MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide You must... Press Escape then press 2. Use the arrow keys to move up or down.
  • Page 20: Server Configuration

    Copyright © 2006 Nortel Networks Server configuration The following table shows the basic configuration of the 2-server V100 Solaris system. Table 1 2-server configuration Configuration Server type 2-server V100 Server1 Solaris Server2 Loading disks MCS 5100 Release 3.0 Base Platform System SoftWare Kit NTVW01AJ contains multiple copies of the same CDs to allow simultaneous installation across servers.
  • Page 21 CD7 MCP Element Manager Console 15 minutes Oracle disks 1-6 Total (approximate) time for each server. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Table 2, Mapping of Kit NTVW01BD disks to Approximate time to install 45 minutes...
  • Page 22 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 23: Minimum And Recommended Requirements For Customer-Provided Pc

    In this case, the free 50MB on drive C will not be used, but is required for the installation to complete successfully.) • CD-ROM drive: required MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 24 Copyright © 2006 Nortel Networks • mouse: required • Video Graphics Card: — minimum: 640x480 @8bpp [256 colors] VGA — recommended: 800x600 @16bpp [65,536 colors] VGA or better • sound card: not applicable • operating systems: — minimum: Microsoft Windows 98(SE)/ME/2000/XP, or Microsoft Windows NT 4.x with Service Pack 5 (SP5)
  • Page 25: Setting Up The Baseline Hardware

    If a power outage occurs, bring the server for the Database Module into service before bringing the other servers into service. If other servers do not come up, restart the server for the Management Module. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 26 — internal V.90 modem and AC power — software and documentation on CD-ROM • core servers: 2 Sun Fire V100 servers including — 1 550-MHz UltraSPARC IIi Processor with 512-KB On-Chip L2 Cache — 1-GB Memory — 2 40-GB 7200 RPM IDE Disk (second disk for mirroring) —...
  • Page 27: Setting Up Rack To Mount Hardware

    • • • • Note: All MCS equipment is 19-inch rack mountable. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION WARNING Static electricity could be harmful to the servers. Mount Layer-2 switch. Mount the MRV LX terminal server.
  • Page 28: Connecting The Sun Fire V100 Server To The Layer-2 Switch

    Procedure 2 Connecting the V100 server to the layer-2 switch At the back of the Sun Fire V100 server, Connect the Sun Fire V100 server Net 0 and Net 1 ports to the layer-2 switch using Ethernet, cat-5 cables. Figure 5 Back view of Sun Fire V100 server...
  • Page 29: Connecting The Sun Fire V100 Server To The Mrv Lx Terminal Server

    Plug in the power cords at the back of the V100 server. Do not power up the server at this time. Connecting the Sun Fire V100 server to the MRV LX terminal server The MCS 5100 platform uses the Sun Fire V100 server medium configuration.
  • Page 30 Copyright © 2006 Nortel Networks Figure 7 Sun Fire V100 server network callouts If the network is down, or the server needs to be configured or restarted, use the console port A. By default from manufacturing, serial port A is the only active serial port.
  • Page 31 Copyright © 2006 Nortel Networks Figure 8 P1 and P2 custom cable connections to terminal server See note Note: This cable is only connected to configure the terminal server. Following configuration, remove the cable. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 32 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 33: Installing And Accessing The Mrv Lx-4000 Series Terminal Server

    Procedure 5 Accessing the MRV LX terminal server At the browser address field, Type in the IP address of your MRV LX terminal server. The LX Series Configuration Console page appears, as shown. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 34 Copyright © 2006 Nortel Networks Figure 9 MRV Configuration Console window Make sure you have the Java Plug-in installed. When your browser connects to the terminal server, the Java Security Warning window appears. Figure 10 Java Security Warning pop-up window...
  • Page 35 Cache button and uncheck the Enable Caching checkbox. Click OK. This issue is fixed in JRE 1.4.2. Select Encrypted or Not Encrypted and then select Load. A login window appears. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 36 Copyright © 2006 Nortel Networks Figure 12 Login window Enter your Username and Password, and click Login. Note: By default, authentication is done against the local user database. To start, use the known username InReach and password access. If you log in as a user, the following window appears.
  • Page 37 Superuser password system. You can now configure the unit at the GUI. Click on the menus on the left side of the window. For example, selecting Ports: Async opens the Async ports window. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 38 Copyright © 2006 Nortel Networks Figure 14 Example: selecting Ports: Async a When you click on a port, the following dialog box appears for you to enter your information. Note: In the TCP window (see Figure 15), ensure that both the Telnet CR Filtering radio button, and the Telnet Negotiations radio button are Enabled.
  • Page 39 For details on using the IP Configuration Menu, refer to “Using the IP Configuration Menu” in the LX-Series Configuration Guide. For information on how to boot your unit from defaults, refer to “Booting from Defaults” in the LX-Series Configuration Guide. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 40 At the management pc, MRV Communications recommends that you change the default password for the user’s MRV LX terminal server before you put the unit on a network. For more information, refer to password defaults on page Use the following procedure to access the command line...
  • Page 41 Enter your username: admin [Enter] To change security at the prompt, type set priv [Enter] MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide password: prompt. The password will be displayed as asterisks. your NEW password: prompt. The password will be displayed as asterisks.
  • Page 42 [Enter] Define port:<select port from range 1-18> telnet newline filtering cr [Enter] Note: Type a range [1-18] for every port the Sun Fire V100 server is connected to. Define port for use with SMDI: Define port 19 telnet newline...
  • Page 43 3200. Note 2: Once the connection is established to the target host, the communication between the user and the component is treated exactly like a console connection. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 44 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 45: Powering On The Servers

    PuTTY title bar to access PuTTY’s pull-down menu. Mouse over the telnet command menu item to access additional drop-down menu options. Select Break to send the break command from the PuTTY session. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 46 Copyright © 2006 Nortel Networks The >ok prompt appears. ATTENTION If you do not use PuTTY, use the appropriate key sequence to send a break to the server to get an >ok prompt. NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 47: Installing Disks 1 To 3

    Installing CD1 Approximate time estimate = 45 minutes Procedure 12 Installing CD1 At the management pc, Place CD1 in the CD-ROM drive. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION ATTENTION ATTENTION...
  • Page 48 Copyright © 2006 Nortel Networks Make sure you put spaces before and after the hyphen: boot [space] cdrom [space] - [space] install. At the >ok prompt, boot the system: boot cdrom - install [Enter] Note 1: For instructions on how to get to the >ok prompt, see...
  • Page 49 It must be unique and follow your site’s address conventions. Enter the machine logical IP address. Example: 120.120.13.25 Press Esc+2 to continue. Subnets/System part of a subnet Accept the default Yes by pressing Esc+2 to continue. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 50 Copyright © 2006 Nortel Networks Netmask/Netmask Do not accept the default unless you are sure it is correct for your subnet. Enter the subnet mask, for example: 255.255.255.0. Press Esc+2 to continue. IPv6/Enables IPv6 IPv6 is not supported. Accept the default No.
  • Page 51 2) 4 or 4+ Standard Configuration ********************************************** You will see the message Creating disk profile for standard <number of servers> server system. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION 45. The selection of the number depends Powering...
  • Page 52: Installing Cd2

    Copyright © 2006 Nortel Networks Make the following selection very carefully. If you make a mistake at this point, you will need to start over, beginning with on the servers on page on the server type. You will see the following message:...
  • Page 53: Installing Cd3

    Note 2: The system will reboot and come up requesting that you insert MCS Base Platform System Software CD3. If you are not prompted for CD3, contact support. Installing CD3 Approximate time estimate = 90 minutes MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 54 Copyright © 2006 Nortel Networks Procedure 14 Installing CD3 At the management pc, Wait for the login prompt to appear. The script will execute after you press Enter. Place CD3 in the CD-ROM drive and press Enter at the prompt.
  • Page 55: Installing Disk 4

    You will see the following message: The Management server requires an external clock. Select External Clock for time source external to the Management server. Select Internal Clock for the Managment server MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 56 Copyright © 2006 Nortel Networks to use the local system clock as the time source. Note: Select Time Source • • • Select option from list above [E, I, X] Refer to the CSI for NTP time source IP information.
  • Page 57 IPMP failover reliability. Enter the address "0.0.0.0" to indicate list is complete, if entering less than six targets. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Machine Logical IP address of the database server Machine Logical IP address of the Management server...
  • Page 58 Enter ping target #1: 120.120.13.25 Enter ping target #2: 120.120.13.1 Enter ping target #3: 0.0.0.0 Note: Do NOT use this server's own IP address as a ping target. Press Enter after each IP address. The configuration information will come up as shown in the...
  • Page 59: Application Servers (Sip Application Module, Ipcm, Web Client Manager, Provisioning Module)

    CD4 will eject from the CD-ROM drive when installed. If you are not prompted for CD5, contact support. Application servers (SIP Application Module, IPCM, Web Client Manager, Provisioning Module) Approximate time estimate = 15 minutes MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 60 Copyright © 2006 Nortel Networks Procedure 16 Installing CD4 At the management pc, Place CD4 in the CD-ROM drive and press Enter to continue. WAIT until you see the following statement appear: ”You are now configuring the NTP time source for this server.
  • Page 61 Note: 0.0.0.0 ends the ping target list. You will see the configuration summary appear as shown in the following figure: MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Machine Logical IP address of the database server Machine Logical IP address of the Management server...
  • Page 62 Copyright © 2006 Nortel Networks Figure 17 Application server IPMP configuration summary Is this IPMP group configuration acceptable? (Y/N) Select Y to accept or N to change. The default route IP address should appear. If correct, press Enter. Otherwise, type it in, then press Enter.
  • Page 63: Installing Disk 5 (All Servers)

    B/Serial port) and change the passwords for the sysadmin, root, and nortel users. Change the passwords on the MgmtSvr/AcctMgr server after CD6 (not CD5). MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Installing Disk 6 for instructions. ATTENTION...
  • Page 64 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 65: Enabling Or Disabling The Automatic Mount

    Log in as root from the console and type the following command: /etc/init.d/volmgt start When you finish mounting the additional disk(s), remember to disable the volume manager for better security. To disable it, use the following command: /etc/init.d/volmgt stop MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 66 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 67: Installing Disk 6 (Mgmtsvr/Acctmgr Only)

    Note: CD6 will eject from the CD-ROM when installed. After the reboot, log in (using the B/Serial port) and change the passwords for the sysadmin, root, and nortel users. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 68 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 69: Installing Oracle 9.2.0.4 On The Database Server

    Log in as root to the database server. Enter your <customer-specific password>. Insert Oracle 9.2.0.4 CD 1 into the CD-ROM drive on the server. cd [ space] /cdrom/cdrom0 [Enter] MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION ATTENTION...
  • Page 70 Copyright © 2006 Nortel Networks Make sure you put a space before the ending slash (/) in step 5. cp [ space] Install_CD_to_Disk [ space] / [Enter] cd [ space] / [Enter] ./Install_CD_to_Disk [Enter] Storing data from CDs to the /IMS/ora_cds...
  • Page 71 Accept the default of the local bin directory: [/usr/local/bin]: [Enter] Removing Disk1,Disk2,Disk3,Disk4,Disk5,Disk6 from /IMS/ora_cds [Y]?: Y [Enter] MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Definition Enter There is only one Hostname of the hostname for a...
  • Page 72 Copyright © 2006 Nortel Networks Failing to answer Y will cause the system to raise a disk space alarm on the SysMgr screen for the DBSvr. You will see the message: Removing Disk 1, Disk2, Disk3, Disk4, Disk5, Disk6 from /IMS/ora_cds...
  • Page 73: Deploying The Initial Database Load

    Password: <your new password> Execute the following command: dbdeploy.pl [Enter] Select the correct database load and press Enter. Is this a Replicated Database? Enter N for a non-redundant system. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 74 Copyright © 2006 Nortel Networks You will see the following message: Select the Type of Deployment: [1] Initial Deployment [2] Upgrade of Database [3] Rollback of Database [4] Install Files only to Select 1 for initial deployment, then press Enter.
  • Page 75: Deploying And Starting The Sysmgr

    Procedure 22 Deploying and starting the Sysmgr At the management pc, Log into the management / accounting server: User name: nortel Password: <Enter your new password.> At the prompt, type mgmtdeploy.pl MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 76 Copyright © 2006 Nortel Networks When selecting the management server load, always select the load that contains the word "micro" in it. If the non-micro load is selected, the installer will receive an Out Of Memory error. The server load names are: •...
  • Page 77: Sysmgr Deployment Verification

    The results of the meinit command should display three processes along with their process ids. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide [Y/N] above, the screen will display deployment NTme_pids...
  • Page 78 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 79: Registering Your License Key

    From the main page, under Support, click on Keycode Retrieval. This will take you to the secure login page. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Procedure 25, Console, follow the procedure www.nortel.com...
  • Page 80 Copyright © 2006 Nortel Networks Figure 18 KRS login screen In step 1 (Location) select a login server that matches your region, for example, European Login or North American Login. In step 2 (Product Family) select the product you wish to generate keycodes for;...
  • Page 81 Copyright © 2006 Nortel Networks Figure 19 Keycode Retrieval System, Creating your site Select Create to register a new system. The following screen appears. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 82 Copyright © 2006 Nortel Networks Figure 20 Keycode Retrieval System, Entering your site information Fill in the requested information and press the Continue button. Ensure you choose the correct software version from the dropdown box. Your screen should look like the one in the following figure.
  • Page 83 Figure 21 Keycode Retrieval System, Current Summary Select the server you want to enter MAC addresses for first, then click on Create. Enter the MAC addresses of the CORE servers and click on Add. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 84 Copyright © 2006 Nortel Networks Figure 22 Keycode Retrieval System, Adding MAC address Repeat Step make an error, you can remove one or both and begin again. If you have a second Core that is going to be installed as a redundant server enter all four MAC addresses at this time.
  • Page 85 You will see a summary page of your entries. If the information displayed is correct, click on Save. You will have completed registering your system. If the information is not correct, click on Cancel and begin again. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 86 Copyright © 2006 Nortel Networks Figure 24 Keycode Retrieval System, Current Summary To generate keycodes for this site, click on Gen KC with Auth Code from the side bar, as shown in the following figure. NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 87 Auth code applied to. In this case, the example shows one of the CORE MAC addresses. Select Add. The KRS automatically searches for and pulls up both MAC addresses associated with the CORE. Click on Continue. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 88 Copyright © 2006 Nortel Networks Figure 26 Keycode Retrieval System, Finding the keycode Select the proper Software Version for your system. Then click on Continue. NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 89 Figure 27 Keycode Retrieval System, Adding a MAC address Enter the authcode number for the feature you wish to enable into the Auth Code box. Use the system Authorization codes to build your license key file. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 90 This screen shows the current features enabled and the new features to be added to your server. In a new installation there are no features displayed. If the list is correct, click on Continue.
  • Page 91 Retrieve Keycode page where you can view the features enabled for the server. From this page you will be able to download the keycode (see the figures below). MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Best Customer...
  • Page 92 Copyright © 2006 Nortel Networks Figure 30 Keycode Retrieval System, Retrieving the keycode Best Customer The screens show the features of your keycode and the option to download the keycode to your local PC. To download the keycode click on Download Keycode. From there you will see the screens to download the file and save it where you choose to on your local machine.
  • Page 93 Copyright © 2006 Nortel Networks Figure 31 Keycode Retrieval System, Retrieving your keycode, part 2 Download the new license key file to the MgmtSvr hard drive. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 94 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 95: Installing And Launching The System Management Console

    Enter the <SysMgr service logical IP address>. Example: 120.120.13.22 Click Next. Enter the System Management server port. Keep the default 11111. Click Next. Keep default destination folder. Click Next. Review settings before copying files. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 96: Launching The System Management Console

    Copyright © 2006 Nortel Networks Click Next to begin installation. At the pop-up window that says, Installation successfully completed, click OK. Launching the System Management Console Make sure that the System Management Console application has been successfully installed on the PC.
  • Page 97 After you have selected the Update menu-item, an Update License key/Select License key File dialog box appears, as shown in MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Figure 32, Management Console Key. The System item on the file tree must be...
  • Page 98 Copyright © 2006 Nortel Networks Figure 33 Select License key File Window Once you have entered the new License Key, you will see a dialog box notifying you whether the update is successful or fails. If the system does not find a license key in the database or on the Managements server local disk, a dialog box appear, prompting for a license key file.
  • Page 99 Explorer window with a tree structure on the left, and a general information area on the right. Each folder on the management console tree is represented as a Network Element and each has a different functionality. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 100 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 101: Adding A Server

    Server Name The name that will appear from the management console. Location Optional field. Describes the physical location of the server. Latitude Optional field. Describes the latitudinal coordinates of the location of this server. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Example <servername> default default...
  • Page 102 Copyright © 2006 Nortel Networks System server field Customer defines Longitude Optional field. Describes the longitudinal coordinates of the location of this server. Platform type Drop-down menu with following choices: Sun or Linux. Select Sun. IP address The machine logical IP address of the server.
  • Page 103: Adding And Configuring The Accounting Module

    Enter a label (maximum six [6] characters) in the Service Component Name field at the bottom of the configuration window. The Service Component Name must be unique among all components. Example: acct1 MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide for information on how to add...
  • Page 104 Copyright © 2006 Nortel Networks Procedure 29 Configuring the tabs At the System Management Console, Use the values from the table that follows to complete the Central Accounting Manager tab parameters. Note: The shaded row indicates values that must be addressed by the installer.
  • Page 105 Click Apply. The component will deploy. Wait until you see the dialog box indicating successful installation. The component will appear in the file tree. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Notes Configurable based on your system.
  • Page 106 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 107: Adding And Configuring The Sip Application Module

    Enter a label (maximum six [6] characters) in the Service Component Name field at the bottom of the configuration window. The Service Component Name must be unique among all components. Example: AppSv1 MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide for information on how to add...
  • Page 108 Copyright © 2006 Nortel Networks Procedure 31 Configuring the SIP Application Module tabs Do not click Apply until you have FINISHED configuring all the tabs. At the System Management Console, Use the values from the following table to enter into the Authentication tab parameters.
  • Page 109 Primary CAM Port Recovery CAM IP Address Recovery CAM Port File Rotation Size File Rotation Time Disk Monitor Major Threshold MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes register (initial registration authorization) invite (calls authenticated)
  • Page 110 Copyright © 2006 Nortel Networks Table 3 Local Accounting Manager tab (Sheet 2 of 2) Parameter Disk Monitor Critical Threshold Enable Billing For Instant Message Use the values from the table that follows to complete the Media Portal tab parameters.
  • Page 111 The shaded rows indicate values that must be addressed by the installer. Table 8 In Memory Database tab (Sheet 1 of 2) Parameter Number of domains Update interval for domain information MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Notes Recommended value UDP=192.168.14.31:506 0:optional:name=sipLsc Conduit;TCP=192.168.1 4.31:5060:optional:name...
  • Page 112 Copyright © 2006 Nortel Networks Table 8 In Memory Database tab (Sheet 2 of 2) Parameter Number of users Update interval for presence limits Update interval for admin banned users Update interval for user banned users IMAuthNonce table size IMAuthNonce generation interval...
  • Page 113 Table 14 Server Properties tab (Sheet 1 of 2) Parameter Recommended value Service Public_Service_Address Parameter: Label Value: <machine logical IP address of the application server> MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value 120.120.13.25:5095:8 0:http Recommended value Notes 86400 Recommended value Notes...
  • Page 114 Copyright © 2006 Nortel Networks Table 14 Server Properties tab (Sheet 2 of 2) Parameter Recommended value Service Private_Service_Address Parameter: Label Value: <leave blank> Service CallPark.TokenRange Parameter: Label Value: Use the values from the following table to enter into the Overload Controls tab parameters.
  • Page 115 Sending Interval HeartBeat Timeout Discovery Period Active Pending Period HB Address checked Enabled MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes Notes App1 Server ID=1 App2 Server ID=2 Enter the machine logical IP of the application server you are working on.
  • Page 116 Copyright © 2006 Nortel Networks Table 16 Transport Management tab (Sheet 2 of 3) Parameter Recommended value Remote Server <machine logical IP of Address other application server> Local Server Public_Static_Address Address Parameters: NSD Number NSD Enabled unchecked NSD Enabled: Label Public_Service_Address Value <service logical IP...
  • Page 117 Click Apply. The component will deploy. Wait until you see the dialog box indicating successful installation. The component will appear in the file tree. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Notes Change default qfe0 to dmfe0...
  • Page 118 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 119: Adding And Configuring The Ip Client Manager

    Enter a label (maximum six [6] characters) in the Service Component Name field at the bottom of the configuration window. The Service Component Name must be unique among all components. Example: IPCM1 MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide for information on how to add...
  • Page 120 Copyright © 2006 Nortel Networks Procedure 33 Configuring the IP Client Manager tabs Do not click Apply until you have finished configuring the component. At the System Management Console, Use the values from the table that follows to complete the IP Client Manager tab parameters.
  • Page 121 Connections Secondary Host <blank> Use the values from the table that follows to complete the UNIStim Base tab parameters. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Box is checked. Notes Leave blank Example default...
  • Page 122 Copyright © 2006 Nortel Networks The shaded rows indicate values that must be addressed by the installer. Table 19 UNISTIM Base tab Parameter Recommended value LocalHost <machine logical IP address of the IPCM server> Port 5000 Use the values from the table that follows to complete the SIP TCF Base tab parameters.
  • Page 123 Sync Time Period Click Apply. The component will deploy. Wait until you see the dialog box indicating successful installation. The component will appear in the file tree. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value 100000 1800...
  • Page 124 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 125: Installing The Uftp Basesoftware

    Note: The UFTP BaseSoftware has no configuration items. Once the installer clicks Apply, the deployment of the UFTP BaseSoftware occurs immediately. Once the deployment is complete, UFTP will appear in the System Management Console file tree. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 126 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 127: Configuring The Provisioning Module

    Component Name field in the dialog box that appears. Example: Prov Note: The Provisioning Module will appear under the IPCMProvWCM components folder. Do not click Apply until you have finished configuring the component. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 128: Nn10364-301 Mcs 5100 3.5 Standard 6.0 December

    Copyright © 2006 Nortel Networks Procedure 36 Configuring the Provisioning Module tabs At the System Management Console, Use the values from the table that follows to complete the SIP TCF Base tab parameters. The shaded rows indicate values that must be addressed by the installer.
  • Page 129 Audio RTP Port High Use SSL Keep Alive Ping Ping Time Out Timer Ping Interval Timer Connection Time Out Timer 360 MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes checked <machine logical IP address of the Web Client Manager>...
  • Page 130 Copyright © 2006 Nortel Networks Table 26 Web Client Manager tab (Sheet 2 of 2) Parameter Allow Auto Login Download JRE Version Use the values from the table that follows to complete the Database Base tab parameters. The shaded rows indicate values that must be addressed by the installer.
  • Page 131 The component will deploy. Wait until you see the dialog box indicating successful installation. The component will appear in the file tree. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes <machine logical IP Address of the Provisioning Module>...
  • Page 132 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 133: Adding And Configuring The Web Client Manager

    Enter a label (maximum six [6] characters) in the Service Component Name field at the bottom of the configuration window. The Service Component Name must be unique among all components. Example: WCM1 MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 134 Copyright © 2006 Nortel Networks Procedure 38 Configuring the Web Client Manager tabs Do not click Apply until you have finished configuring the component. At the System Management Console, Use the values from the table that follows to complete the User Agent Server tab parameters.
  • Page 135 Table 33 Web Client Manager tab (Sheet 1 of 2) Parameter WCM Socket Server Active WCM Socket Server Host WCM Socket Server Port MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Notes Replace each instance of 0.0.0.0 in the...
  • Page 136 Copyright © 2006 Nortel Networks Table 33 Web Client Manager tab (Sheet 2 of 2) Parameter Audio RTP Port Low Audio RTP Port High Use SSL Keep Alive Ping Ping Time Out Timer Ping Interval Timer Connection Time Out Timer 360...
  • Page 137 Click Apply. The component will deploy. Wait until you see the dialog box indicating successful installation. The component will appear in the file tree. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended Value Notes <machine logical IP database server>...
  • Page 138 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 139: Installing And Configuring The Oracle Monitor

    Enter a label (maximum six [6] characters) in the Service Component Name field at the bottom of the configuration window. The Service Component Name must be unique among all components. Example: Oramn1 MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 140 Copyright © 2006 Nortel Networks Procedure 40 Configuring the Oracle Monitor tabs Do not click Apply until you have finished configuring the component. At the System Management Console, Use the values from the table that follows to complete the Oracle Server tab parameters.
  • Page 141 Monitoring: Threshold monitors: Negative going threshold value Gauged Component Monitoring: Threshold monitors: Negative going threshold hysteresis MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value 9161 <either the word "localhost" or the machine logical IP address of the...
  • Page 142 Copyright © 2006 Nortel Networks Table 37 IMS Main Database tab (Sheet 2 of 4) Parameter Gauged Component Monitoring: Threshold monitors: Positive going threshold value 1 Gauged Component Monitoring: Threshold monitors: Positive going threshold hysteresis 1 Gauged Component Monitoring: Threshold...
  • Page 143 (min) Monitor functions: Active Monitor functions: Component name Monitor functions: Polling interval (min) Monitor functions: Active Monitor functions: Component name MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value MINOR MAJOR MAJOR MAJOR unchecked BlockGetRate checked...
  • Page 144 Copyright © 2006 Nortel Networks Table 37 IMS Main Database tab (Sheet 4 of 4) Parameter Monitor functions: Polling interval (min) Monitor functions: Active Monitor functions: Component name Monitor functions: Polling interval (min) Monitor functions: Active Trap handlers: Trap handler name...
  • Page 145 Click Apply. The component will deploy. Wait until you see the dialog box indicating successful installation. The component will appear in the file tree. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes 9161 <either the word "localhost"...
  • Page 146 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 147: Installing The Iplanet Monitor

    Enter a label (maximum six [6] characters) in the Service Component Name field at the bottom of the configuration window. The Service Component Name must be unique among all components. Example: iPIMon MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 148 Copyright © 2006 Nortel Networks Procedure 42 Configuring the iPlanet Monitor At the System Management Console, Do not click Apply until you have finished configuring the tab. Use the values from the table that follows to complete the Web Monitor tab parameters.
  • Page 149 Positive going threshold hysteresis 2 Component Monitoring: Threshold monitors: Capacity or max value Component Monitoring: Threshold monitors: Capacity or max hysteresis MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes Example default default default default default default...
  • Page 150 Copyright © 2006 Nortel Networks Table 40 Web Monitor tab (Sheet 3 of 12) Parameter Component Monitoring: Threshold monitors: Alarm Severity on Negative going threshold Component Monitoring: Threshold monitors: Alarm Severity on Positive going threshold 1 Component Monitoring: Threshold monitors:...
  • Page 151 Capacity or max value Component Monitoring: Threshold monitors: Capacity or max hysteresis Component Monitoring: Threshold monitors: Alarm Severity on Negative going threshold MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes NONE Example default default default default default...
  • Page 152 Copyright © 2006 Nortel Networks Table 40 Web Monitor tab (Sheet 5 of 12) Parameter Threshold monitors: Alarm Severity on Positive going threshold 1 Threshold monitors: Alarm Severity on Positive going threshold 2 Component Monitoring: Threshold monitors: Alarm Severity on...
  • Page 153 Maximum Rate Alarm Severity on Upper Limit OverRun Alarm Severity on Lower Limit UnderRun Usage state affected Component Monitoring: Class name MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes NONE WARNING MINOR MAJOR MAJOR MAJOR unchecked com.nortelnetworks.i...
  • Page 154 Copyright © 2006 Nortel Networks Table 40 Web Monitor tab (Sheet 7 of 12) Parameter Component Monitoring: Component name Component Monitoring: Polling interval in minutes Component Monitoring: Active for polling Component Monitoring: Threshold monitors: Gauge name Component Monitoring: Threshold monitors:...
  • Page 155 Component Monitoring: Threshold monitors: Alarm Severity on Upper Limit OverRun Component Monitoring: Threshold monitors: Alarm Severity on Lower Limit UnderRun MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes NONE WARNING MINOR MAJOR MAJOR MAJOR Example...
  • Page 156 Copyright © 2006 Nortel Networks Table 40 Web Monitor tab (Sheet 9 of 12) Parameter Component Monitoring: Threshold monitors: Usage state affected Component Monitoring: Class name Component Monitoring: Component name Component Monitoring: Polling interval in minutes Component Monitoring: Active for polling...
  • Page 157 Component Monitoring: Threshold monitors: Alarm Severity on Positive going threshold 2 Component Monitoring: Threshold monitors: Alarm Severity on Maximum Rate MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes NONE WARNING MINOR MAJOR Example default default...
  • Page 158 Copyright © 2006 Nortel Networks Table 40 Web Monitor tab (Sheet 11 of 12) Parameter Component Monitoring: Threshold monitors: Alarm Severity on Upper Limit OverRun Component Monitoring: Threshold monitors: Alarm Severity on Lower Limit UnderRun Component Monitoring: Threshold monitors: Usage state affected...
  • Page 159 Click Apply. Wait for the component to appear in server list. The iPlanet Monitor is installed on the same server as the Provisioning Module. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Recommended value Notes iPlanet Operation Trap checked...
  • Page 160 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 161: Verification Procedures

    1500 index 3 inet 120.120.13.21 netmask ffffff00 broadcast 120.120.13.255 groupname imspub Look for the entry that starts with ‘dmfe0.’ The parameters that follow show the IP address, subnet mask, and whether the MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide inet 120.120.13.22 netmask ffffff00...
  • Page 162 Copyright © 2006 Nortel Networks interface is ‘UP.’ This example output shows that dmfe0 is assigned to IP address 120.120.13.20, its subnet mask is ffffff00, which translates to 255.255.255.0, and the interface is UP (active). Look for the entry which starts with ‘dmfe1.’ The parameters that follow show the IP address, subnet mask, and whether the interface is ‘UP.’...
  • Page 163: Verifying Server2 (Application Server)

    ‘UP.’ This example output shows that dmfe0 is assigned to IP address 120.120.13.23, its subnet mask is ffffff00 which translates to 255.255.255.0, and the interface is UP (active). MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide inet 120.120.13.25 netmask ffffff00...
  • Page 164 Copyright © 2006 Nortel Networks Look for the entry that starts with ‘dmfe1.’ The parameters that follow show the IP address, subnet mask, and whether the interface is ‘UP.’ This example output shows that dmfe1 is assigned to IP address 120.120.13.24, its subnet mask is ffffff00 which translates to 255.255.255.0, and the interface is UP...
  • Page 165: Verifying The Database Load (Imssipdb) Deployment

    These errors could include statements such as ‘error’, ‘failed’, and so on. If any error condition is encountered, do not continue. Contact support immediately. The imssipdb deployment is successful when the Server1’s dbdeploy.pl script reports ‘deployed successfully.’ MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide ATTENTION...
  • Page 166 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 167: Appendix A Deploying The Pc Client

    Upload the pcclient.jnlp to /IMS/web/data/web/webapps/prov/pcclient.jnlp c Upload the unzipped code resource files to /IMS/web/data/web/webapps/prov/pcclientclode. It is possible to perform steps 1 - 4 directly on the Provisioning servers without FTP. MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 168 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 169: Appendix B Reloading Ip Addresses After System Installation

    MgmtSvr/AcctMgr machines as described earlier in this document. Then re-install the Oracle CDs as described earlier in this document. Once you have completed the Oracle installation, you can unconfigure MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide (Procedure 46, Reloading IP addresses after...
  • Page 170 The system is now ready to re-configure. You can type poweroff at the ok prompt if you wish to power the machine off. To reconfigure the server at this point, if you are at the boot prompt {ok}, enter the boot command. If you are not at the boot prompt, power on the server.
  • Page 171 You will need to provide the Machine Logical IP Address of each server. If running simplex mode, provide the same address twice. Press the Enter Key to Continue -- MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide Networked DHCP Primary Network Interface Hostname (You may have to backspace over the word "unknown"...
  • Page 172 Execute the following steps before deploying any components. To set the SysMgr and AcctMgr Service Logical IP addresses, a Log in as root to the Management server and type in the NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006 in the instructions for installing the DBSvr1 or...
  • Page 173 Copyright © 2006 Nortel Networks b Then log in to the Accounting server and type in the following command: #/usr/local/bin/Interface.pl add acctmgr MCS 2-server Sun Fire V100 Solaris Installation and Commissioning Guide...
  • Page 174 Copyright © 2006 Nortel Networks NN10364-301 MCS 5100 3.5 Standard 6.0 December 2006...
  • Page 176 Users must take full responsibility for their applications of any products specified in this document. The information in this document is proprietary to Nortel Networks. *Nortel, Nortel (logo), and the Globemark, are trademarks of Nortel Networks.

This manual is also suitable for:

Nn10364-301

Table of Contents
