- Page 1 Installing CWDM Gigabit Interface Converters *212256-A* Part No. 212256-A July 2001 4401 Great America Parkway Santa Clara, CA 95054...
- Page 2 Nortel Networks Inc. reserves the right to make changes to the products described in this document without notice. Nortel Networks Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
- Page 3 Caution: Only qualified technicians should install this equipment. Place all printed circuit boards on an antistatic mat until you are ready to install them. If you do not have an antistatic mat, wear a discharge leash to free yourself of static before touching any of the printed circuit boards, or free yourself of static by touching a grounded metal object before handling a printed circuit board.
- Page 4 Avvertenza: Le apparecchiature a fibre ottiche emettono raggi laser o infrarossi che possono risultare dannosi per gli occhi. Non guardare mai direttamente le fibre ottiche o le porte di collegamento. Tenere in considerazione il fatto che i cavi a fibre ottiche sono collegati a una sorgente luminosa.
- Page 5 Introduction This section describes how the Nortel Networks* coarse wavelength division multiplexed Gigabit Interface Converter (CWDM GBIC) works within the optical routing system. It also provides a list of CWDM GBICs by wavelength and shows how they are labeled and color-coded.
- Page 6 Figure 1 CWDM GBIC CWDM GBIC labeling Figure 2 shows how Nortel Networks CWDM GBICs are labeled, including color-coding by wavelength. Figure 2 Nortel Networks CWDM GBIC label Serial number Wavelength Wavelength color code 10292FA Model number Bar code Interface type...
- Page 7 When you contact Nortel Networks about this Note: product, have the following information available: • Nortel Networks serial number • Wavelength • Interface type • CWDM GBIC part number CWDM GBIC model numbers Table 1 lists the CWDM GBIC model numbers by wavelength and matching multiplexers in the CWDM optical routing system.
-
Page 8: Handling, Safety, And Environmental Guidelines
Handling, safety, and environmental guidelines Before installing a CWDM GBIC, read the following handling, safety, and environmental guidelines: • CWDM GBICs are static sensitive. To prevent damage from electrostatic discharge (ESD), follow your normal board and component handling procedures. • CWDM GBICs are dust sensitive. - Page 9 To install a CWDM GBIC in the switching module: Remove the CWDM GBIC from its protective packaging. Verify that the CWDM GBIC is the correct wavelength for your network configuration Remove the dust cover from the CWDM GBIC’s optical bores. To prevent damage during handling, clean the ferrules of the optical connector with an alcohol swab.
- Page 10 Figure 3 Inserting a Removing a CWDM GBIC Use the following procedure to remove a CWDM GBIC. When storing a CWDM GBIC, place a dust cover over the fiber optic bores When disposing of a CWDM GBIC, comply with Note: all national laws and regulations To remove a CWDM GBIC from the switching module: Disconnect the fiber cable from the CWDM GBIC connector.
- Page 11 CWDM GBIC specifications Table 2 CWDM GBIC specifications Item Physical dimensions Connectors Cabling Data rate Average launch power Transmitter extinction ratio Data format Average receive power Power supply Operating temperature range Regulatory Specification 0.39 X 1.18 X 2.56 inches (1 X 3 X 6.5 cm) single mode fiber optic SC SMF, 9 µm Nominal...
-
Page 12: Hard-Copy Technical Manuals
Given a loss budget of 24 dB and assuming fiber loss of .25 dB/km, up to 96 km reach is supported with no intermediate CWDM OADM or CWDM OMUX. Connecting to Nortel Networks online This section describes products, services, and support systems that can be accessed online. -
