Patent Pending
Model No. NTTL11903
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through di-
rect assistance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTTL11903 and is the answer not in the manual?

Questions and answers

Related Manuals for NordicTrack NTTL11903

Summary of Contents for NordicTrack NTTL11903

  • Page 1 Patent Pending Model No. NTTL11903 Serial No. Find the serial number in the location shown below. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction.

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    450 joules. The surge suppressor must be electrically rated for 120 volts AC and 15 amps. To purchase a surge suppressor, see your local NordicTrack dealer or call 1-888- 825-2588 and order part number 146148. 12. Keep the power cord and the surge suppres- sor away from heated surfaces.
  • Page 4 SAVE THESE INSTRUCTIONS The decals shown below have been placed on your treadmill. If the decal is missing or illegible, please call our Customer Service Department, toll-free, to order a free replacement decal (see ORDERING RE- PLACEMENT PARTS on page 31).

  • Page 5: Before You Begin

    The model number of the treadmill is NTTL11903. The serial num- ber can be found on a decal attached to the treadmill (see the front cover of this manual for the location).

  • Page 6: Assembly

    This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 7 Tighten all four Handrail Bolts (78). 7. Make sure that all parts are tightened before you use the treadmill. Note: If there is a thin sheet of clear plastic on the face of the hood decal and the “ComforTrack” decal, remove it. Keep the included allen wrench in a secure place.

  • Page 8: To Plug In Power Cord

    (see drawing 1 at the right). To purchase a surge suppressor, see your local NordicTrack dealer or call 1-888-825-2588 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS).

  • Page 9: Features Of The Console

    When the console is in the manual mode, the speed and incline of the treadmill can be changed with a touch of a button. As you exercise, the console will provide continuous exercise feedback.

  • Page 10: Getting Started

    Insert the key fully into the console. Stand on the foot rails of the treadmill. Make sure that the clip is securely attached to the waistband of your clothes. Next, insert the key into the con- sole.

  • Page 11: How To Use The Manual Mode

    0.5%. The incline range is 1% to 10%. Note: After the buttons are pressed, it may take a moment for the treadmill to reach the selected incline setting. Follow your progress with the LED track and the displays.
  • Page 12 Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to 1%. The incline must be at 1% when the treadmill is raised to the storage position or the treadmill will be damaged.
  • Page 13 When the program has ended, remove the key. Step onto the foot rails and make sure that the in- cline of the treadmill is at 1%. The incline must be at 1% when the treadmill is raised to the storage position. Next, remove the key from the console and put it in a secure place.

  • Page 14: How To Create Custom Programs

    Current Segment Step onto the foot rails and make sure that the in- cline of the treadmill is at 1%. The incline must be at 1% when the treadmill is raised to the storage position. Next, remove the key from the console and put it in a secure place.

  • Page 15: How To Use Custom Programs

    HOW TO USE CUSTOM PROGRAMS Insert the key fully into the console. See GETTING STARTED on page 10. Select one of the custom programs. When the key is in- serted, the manual mode will be selected and the Manual indica- tor will light.

  • Page 16: How To Use The Fitness Test Program

    3.3 mph. At the beginning of each 4-minute segment, the speed and/or incline of the treadmill will automati- cally increase. The fitness test program will con- tinue in this way until your heart rate reaches 70% of your estimated maximum heart rate, and the current 4-minute segment is completed.
  • Page 17 HOW TO USE THE PULSE-DRIVEN PROGRAM The pulse-driven program automatically adjusts the speed and incline of the treadmill to keep your heart rate near a target level during your workout. Note: You must wear the optional chest pulse sensor to use the pulse-driven program (see page 24).
  • Page 18 If your heart rate is not detected during the pro- gram, the speed and incline of the treadmill may automatically decrease until your heart rate is detected. If this occurs, refer to the instructions in- cluded with the optional chest pulse sensor.
  • Page 19 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the LINE OUT jack on your CD player.
  • Page 20 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter. Plug the adapter into the LINE OUT jack on your stereo.
  • Page 21 CONNECT YOUR HOME STEREO on page 20. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter. Plug the adapter into the AUDIO OUT jack on your VCR.
  • Page 22 Stop button or remove the key and go to step 1 on page 18. Note: If the speed or incline of the treadmill does not change when a “chirp” is heard: • Make sure that the iFIT.com indicator is lit and that the Time display is not flashing.
  • Page 23 Our new internet site at www.iFIT.com allows you to access a selection of programs that interactively con- trol your treadmill to help you achieve your specific ex- ercise goals. In addition, you can play iFIT.com audio and video programs directly from the internet. By adding an optional upgrade module to the console, you can use virtually endless features from our internet site.
  • Page 24 THE INFORMATION MODE/DEMO MODE The console features an information mode that keeps track of the total number of hours that the treadmill has been operated and the total number of miles that the walking belt has moved. The information mode also allows you to switch the console from miles per hour to kilometers per hour.

  • Page 25: How To Fold And Move The Treadmill

    1. Refer to drawing 2 above. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the lock knob to the left and hold it. Pivot the treadmill down until the frame is past the pin on the lock knob.

  • Page 26: Troubleshooting

    PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
  • Page 27 SOLUTION: a. With the key in the console, press one of the incline buttons. While the incline is changing, re- move the key. After a few seconds, re-insert the key. The treadmill will automatically rise to the maximum incline level and then return to the minimum level. This will recalibrate the incline system.

  • Page 28: Conditioning Guidelines

    For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”...

  • Page 29: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 30: Part List

    PART LIST—Model No. NTTL11903 To locate the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Foot Rail Insert Foot Rail Foot Rail Cap Screw Left Fait Rail Cap Frame Pivot Bolt...

  • Page 31: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER OF THE PRODUCT (NTTL11903) • The NAME OF THE PRODUCT (NordicTrack • The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual) •...
  • Page 32 EXPLODED DRAWING—Model No. NTTL11903 R0701A...
  • Page 33 EXPLODED DRAWING—Model No. NTTL11903 R0701A...

  • Page 34: Limited Warranty

    LIMITED WARRANTY WHAT IS COVERED—The entire NordicTrack ® EXP2000i treadmill (“Product”) is warranted to be free of all defects in material and workmanship. WHO IS COVERED—The original purchaser or any person receiving the Product as a gift from the original purchaser.
